Name: A/C COMPRESSOR
Rating: 5.0 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	268408	SPACER	$12.72	To Order

Photo	Part No	Description	Price (each)	Stock
	328455	BRACKET FOR AC PIPE TO COMPRESSOR	$25.79	To Order

Photo	Part No	Description	Price (each)	Stock
	268409	SCREW	$16.65	To Order

Photo	Part No	Description	Price (each)	Stock
	14307124	SCREW	$0.71	To Order

Photo	Part No	Description	Price (each)	Stock
	14302024	SCREW	$1.85	To Order

Photo	Part No	Description	Price (each)	Stock
	84317700	SCREW 8 X 30	$25.30	To Order

Photo	Part No	Description	Price (each)	Stock
	339133	COMPRESSOR HEAT SHIELD	$229.33	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
0001	287339	AC SYSTEM COMPRESSOR	287339 AC SYSTEM COMPRESSOR Applicable up to engine No. 463508	$1,419.94	1
0001	878883	AC SYSTEM COMPRESSOR	878883 AC SYSTEM COMPRESSOR Applies until depletion; Applicable from engine No. 463509	$1,338.48	1
0001	802718	AC SYSTEM COMPRESSOR	802718 AC SYSTEM COMPRESSOR Applicable after depletion of 878883; Applicable from engine No. 463509	$1,298.36	1
0002	895330	BELT	895330 BELT Applies until depletion - Applicable after depletion of 332699	$27.60	1
0002	895330	BELT	895330 BELT	$27.60	1
0002	905873	BELT	905873 BELT Applicable after depletion of 895330	$37.15	1
0003	268408	SPACER	268408 SPACER	$12.72	1
0004	328455	BRACKET FOR AC PIPE TO COMPRESSOR	328455 BRACKET FOR AC PIPE TO COMPRESSOR	$25.79	1
0005	268409	SCREW	268409 SCREW M8 X 145	$16.65	1
0006	14307124	SCREW	14307124 SCREW M8 X 90	$0.71 MSRP: ~~1.75~~ (59.4% off)	1
0007	14302024	SCREW	14302024 SCREW M8 X 95	$1.85	1
0008	284481	BRACKET COMPL. WITH CLIP	284481 BRACKET COMPL. WITH CLIP Applicable up to engine No. 463508	$52.94	1
0008	938134	BRACKET COMPL. WITH CLIP	938134 BRACKET COMPL. WITH CLIP Applicable from engine No. 463509	$53.02	1
0009	84317700	SCREW 8 X 30	84317700 SCREW 8 X 30 M8 X 25	$25.30	1
0010	339133	COMPRESSOR HEAT SHIELD	339133 COMPRESSOR HEAT SHIELD	$229.33	1
