Engine Intake Duct

Ferrari Monza SPA1 Europe

Find Your Part

Ferrari Monza SPA1 Europe - ENGINE INTAKE DUCT

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
752419 INTAKE MANIFOLD $7,859.31 To Order
Photo Part No Description Price (each) Stock
329115 ASSEMBLED INTAKE TRUMPETS $388.33 To Order
900749 ASSEMBLED INTAKE TRUMPETS $738.10 To Order
Photo Part No Description Price (each) Stock
316503 GASKET $20.96 IN STOCK
Photo Part No Description Price (each) Stock
816017 RH INTAKE PLENUM $3,871.88 To Order
Photo Part No Description Price (each) Stock
816018 LH INTAKE PLENUM $3,871.88 To Order
Photo Part No Description Price (each) Stock
323493 SCREW $1.09 To Order
Photo Part No Description Price (each) Stock
329629 PLASTIC BUSH $0.16 To Order
Photo Part No Description Price (each) Stock
102725 CENTERING DOWEL $1.09 To Order
Photo Part No Description Price (each) Stock
268875 CONNECTOR $37.65 To Order
Photo Part No Description Price (each) Stock
328743 KAISER PIPE HEAT SHIELD $67.38 To Order
Photo Part No Description Price (each) Stock
198253 CLIP $3.57 To Order
Photo Part No Description Price (each) Stock
268877 CONNECTOR $67.38 To Order
219786 THREADED PLUG $15.85 To Order
Photo Part No Description Price (each) Stock
243207 CONNECTOR $20.84 To Order
Photo Part No Description Price (each) Stock
243208 CONNECTOR $24.05 To Order
Photo Part No Description Price (each) Stock
123475 GASKET $3.81 IN STOCK
Photo Part No Description Price (each) Stock
13432070 HOSE COLLAR $0.57 IN STOCK
Photo Part No Description Price (each) Stock
248334 SCREW $0.68 To Order
Photo Part No Description Price (each) Stock
14305574 SCREW $0.36 To Order
Photo Part No Description Price (each) Stock
11197774 WASHER $0.06 IN STOCK
Photo Part No Description Price (each) Stock
313930 POSITION SENSOR $282.91 IN STOCK
Photo Part No Description Price (each) Stock
14303123 SCREW $0.06 IN STOCK
Photo Part No Description Price (each) Stock
164400 THREADED PLUG $3.55 IN STOCK
Photo Part No Description Price (each) Stock
282755 THREADED PLUG $2.07 To Order
Photo Part No Description Price (each) Stock
900098 RH GASKET $120.33 IN STOCK
900098 RH GASKET $120.33 IN STOCK
Photo Part No Description Price (each) Stock
900099 LH GASKET $120.33 IN STOCK
900099 LH GASKET $120.33 IN STOCK
Photo Part No Description Price (each) Stock
330293 INTAKE TRUMPET GUIDE ROD $136.37 To Order
Photo Part No Description Price (each) Stock
319613 RECIRCULATING BALL BEARING $42.29 To Order
Photo Part No Description Price (each) Stock
327561 KAISER PIPE HEAT SHIELD $46.52 To Order
Photo Part No Description Price (each) Stock
319271 CONNECTOR $56.14 To Order
Photo Part No Description Price (each) Stock
222072 CLIP $3.36 IN STOCK
Photo Part No Description Price (each) Stock
314467 COMPLETE PISTON $208.58 To Order
Photo Part No Description Price (each) Stock
314498 ACTUATOR SLEEVE $67.38 To Order
Photo Part No Description Price (each) Stock
314350 O-RING $0.53 To Order
Photo Part No Description Price (each) Stock
314468 COMPL. PLUG $256.72 To Order
Photo Part No Description Price (each) Stock
80365900 SCREW $0.16 IN STOCK
Photo Part No Description Price (each) Stock
325432 BUSH $6.53 To Order
Photo Part No Description Price (each) Stock
325535 RUBBER CABLE GROMMET $17.63 To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 $1.43 IN STOCK
Photo Part No Description Price (each) Stock
752492 PLENUM COSMETIC COVER $256.72 To Order
Photo Part No Description Price (each) Stock
340224 BUSH $2.46 To Order
Photo Part No Description Price (each) Stock
315930 OIL RETURN PIPE FROM MANIFOLD TO HEAD $272.77 To Order
Photo Part No Description Price (each) Stock
318994 OIL DELIVERY PIPE FROM CRANKCASE TO MANIFOLD $272.77 To Order
Photo Part No Description Price (each) Stock
319473 SCREW $9.81 To Order
Photo Part No Description Price (each) Stock
752491 SOLENOID VALVE HOLDER COVER $738.10 IN STOCK
Photo Part No Description Price (each) Stock
313960 GASKET $67.38 IN STOCK
Photo Part No Description Price (each) Stock
323489 SCREW $6.05 To Order
Photo Part No Description Price (each) Stock
801187 OIL PRESSURE REGULATOR VALVE $240.67 IN STOCK
801187 OIL PRESSURE REGULATOR VALVE $240.67 IN STOCK
Photo Part No Description Price (each) Stock
16281827 SCREW $0.23 IN STOCK
Photo Part No Description Price (each) Stock
11181574 WASHER $0.02 IN STOCK
Photo Part No Description Price (each) Stock
335473 KAISER PIPE COMPL. WITH VALVES $497.41 To Order
Photo Part No Description Price (each) Stock
287722 O-RING $7.05 IN STOCK
Photo Part No Description Price (each) Stock
287722 O-RING $7.05 IN STOCK
View All
ENGINE INTAKE DUCT of Ferrari Ferrari Monza SPA1 Europe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 752419
INTAKE MANIFOLD 		$7,859.31 1
0002 329115
ASSEMBLED INTAKE TRUMPETS
Applies until depletion; Aluminium 		$388.33 2
0002 900749
ASSEMBLED INTAKE TRUMPETS
Applicable after depletion of 329115; Aluminium 		$738.10 2
0003 316503
GASKET
Also included in engine gasket set
IN STOCK 		$20.96 2
0004 816017
RH INTAKE PLENUM 		$3,871.88 1
0005 816018
LH INTAKE PLENUM 		$3,871.88 1
0006 323493
SCREW
M6 X 26 X 1 		$1.09 36
0007 329629
PLASTIC BUSH 		$0.16 14
0008 102725
CENTERING DOWEL 		$1.09 (51.6% off) 4
0009 268875
CONNECTOR 		$37.65 2
0010 328743
KAISER PIPE HEAT SHIELD 		$67.38 2
0011 198253
CLIP 		$3.57 (7.3% off) 2
0012 268877
CONNECTOR
Not for vehicles with USA type approval 		$67.38 2
0012 219786
THREADED PLUG
Applicable only for vehicles with USA type approval, see circular 2935 - Applicable for USA 		$15.85 2
0013 243207
CONNECTOR 		$20.84 1
0014 243208
CONNECTOR 		$24.05 1
0015 123475
GASKET
IN STOCK 		$3.81 (8.9% off) 2
0016 13432070
HOSE COLLAR
16.2 mm
IN STOCK 		$0.57 (46.7% off) 2
0017 248334
SCREW
M6 X 14 		$0.68 2
0018 14305574
SCREW
M6 X 30 		$0.36 24
0019 11197774
WASHER
IN STOCK 		$0.06 (80% off) 24
0020 313930
POSITION SENSOR
IN STOCK 		$282.91 2
0021 14303123
SCREW
M4 X 12
IN STOCK 		$0.06 4
0022 164400
THREADED PLUG
IN STOCK 		$3.55 1
0023 282755
THREADED PLUG
D. 10 X 1.25 		$2.07 6
0024 900098
RH GASKET
Also included in engine gasket set; Applicable after depletion of 326439
IN STOCK 		$120.33 1
0024 900098
RH GASKET
IN STOCK 		$120.33 1
0025 900099
LH GASKET
Also included in engine gasket set; Applicable after depletion of 326440
IN STOCK 		$120.33 1
0025 900099
LH GASKET
IN STOCK 		$120.33 1
0026 330293
INTAKE TRUMPET GUIDE ROD 		$136.37 4
0027 319613
RECIRCULATING BALL BEARING 		$42.29 4
0028 327561
KAISER PIPE HEAT SHIELD 		$46.52 1
0029 319271
CONNECTOR 		$56.14 1
0030 222072
CLIP
D. 18
IN STOCK 		$3.36 1
0031 314467
COMPLETE PISTON 		$208.58 4
0032 314498
ACTUATOR SLEEVE 		$67.38 4
0033 314350
O-RING 		$0.53 4
0034 314468
COMPL. PLUG 		$256.72 4
0035 80365900
SCREW
M4 X 10
IN STOCK 		$0.16 (68% off) 8
0036 325432
BUSH 		$6.53 4
0037 325535
RUBBER CABLE GROMMET 		$17.63 8
0038 14059290
FLANGED NUT M6
IN STOCK 		$1.43 4
0039 752492
PLENUM COSMETIC COVER 		$256.72 1
0040 340224
BUSH 		$2.46 8
0041 315930
OIL RETURN PIPE FROM MANIFOLD TO HEAD 		$272.77 1
0042 318994
OIL DELIVERY PIPE FROM CRANKCASE TO MANIFOLD 		$272.77 1
0043 319473
SCREW 		$9.81 2
0044 752491
SOLENOID VALVE HOLDER COVER
IN STOCK 		$738.10 1
0045 313960
GASKET
IN STOCK 		$67.38 1
0046 323489
SCREW 		$6.05 5
0047 801187
OIL PRESSURE REGULATOR VALVE
Applicable after depletion of 296017
IN STOCK 		$240.67 2
0047 801187
OIL PRESSURE REGULATOR VALVE
IN STOCK 		$240.67 2
0048 16281827
SCREW
M5 X 14
IN STOCK 		$0.23 2
0049 11181574
WASHER
IN STOCK 		$0.02 2
0050 335473
KAISER PIPE COMPL. WITH VALVES 		$497.41 1
0051 287722
O-RING
IN STOCK 		$7.05 4
0052 287722
O-RING
IN STOCK 		$7.05 4
