Ferrari FF - AIR INTAKE

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	271139	COMPL. AIR DUCT	Enquire	To Order
	265703	COMPL. AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	223039	Air Filter	Enquire	ARRIVING SOON
	271145	AIR FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81591700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	275476	COILED PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	270296	MEMBRANE HOLDER PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	275474	COILED PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	296781	COLLAR 30-45MM	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	275478	COILED PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	107002	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	249164	AIR FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	290083	AIR DUCT	Enquire	To Order
	265704	AIR DUCT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	265497	FILTER BOX COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	288354	HOLE BLANKING PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	296781	COLLAR 30-45MM	Enquire	ARRIVING SOON

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	271139	COMPL. AIR DUCT	271139 COMPL. AIR DUCT Applicable for USA, CDN, USA LIGHT; No longer supplied	-	1	Enquire
1	265703	COMPL. AIR DUCT	265703 COMPL. AIR DUCT Not for USA, CDN, USA LIGHT; No longer supplied	-	1	Enquire
2	223039	Air Filter ARRIVING SOON	223039 Air Filter Not for USA, CDN, USA LIGHT ARRIVING SOON	-	2	Enquire
2	271145	AIR FILTER	271145 AIR FILTER Applicable for USA, CDN, USA LIGHT	-	2	Enquire
3	81591700	SCREW	81591700 SCREW M5 X 20	-	14	Enquire
4	275476	COILED PIPE	275476 COILED PIPE D. 38; L. 450 mm; Applicable up to Ass. No. 105816	-	2	Enquire
5	270296	MEMBRANE HOLDER PIPE	270296 MEMBRANE HOLDER PIPE D. 38; Applicable up to Ass. No. 105816	-	4	Enquire
6	275474	COILED PIPE	275474 COILED PIPE D. 38; L. 370 mm; Applicable up to Ass. No. 105816	-	2	Enquire
7	296781	COLLAR 30-45MM ARRIVING SOON	296781 COLLAR 30-45MM Applicable up to Ass. No. 105816 ARRIVING SOON	-	12	Enquire
8	275478	COILED PIPE	275478 COILED PIPE D. 38; L. 1070 mm; Applicable up to Ass. No. 105816	-	2	Enquire
9	107002	BRACKET WITH SHEATH	107002 BRACKET WITH SHEATH	-	10	Enquire
10	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6 Applicable up to Ass. No. 105816	-	10	Enquire
11	249164	AIR FILTER	249164 AIR FILTER After depletion, order compl. 271145 pos. 2; Applicable for USA, CDN, USA LIGHT; Applicable until depletion	-	2	Enquire
12	290083	AIR DUCT	290083 AIR DUCT Applicable from Ass. No. 110521	-	1	Enquire
12	265704	AIR DUCT	265704 AIR DUCT Applicable up to Ass. No. 110520	-	1	Enquire
13	265497	FILTER BOX COVER	265497 FILTER BOX COVER	-	2	Enquire
14	288354	HOLE BLANKING PLUG	288354 HOLE BLANKING PLUG Applicable from Ass. No. 105817 up to Ass. No. 110520	-	4	Enquire
15	296781	COLLAR 30-45MM ARRIVING SOON	296781 COLLAR 30-45MM Applicable from Ass. No. 105817 up to Ass. No. 110520 ARRIVING SOON	-	4	Enquire
