ENGINE INJECTION CONTROL of Ferrari Ferrari Daytona SP3 USA

View All

Ferrari Daytona SP3 USA - ENGINE INJECTION CONTROL

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	905971	RH HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	905969	LH HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	268661	SCREW COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	845077	INTAKE LINE AIR FLOW SENSOR HOUSING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	297280	AIR FLOW SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	327132	ADHESIVE FOAM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	841336	SQUARE MESH GRILLE FOR MASS AIR FLOW SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	340691	GPF PRESSURE SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	901815	GPF SENSOR BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	825111	COMPL. GPF PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13432070	HOSE COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13126970	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	825098	RUBBER PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	825100	RUBBER PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	825110	COMPL. GPF PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	913829	THREE WAY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13125470	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	787780	REAR OXYGEN SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	787778	FRONT OXYGEN SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	861912	IGNITION ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	941421	ION ECU CASING	Enquire	To Order
	941421	ION ECU CASING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102741	NUT M6 X 6	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	905971	RH HOSE	905971 RH HOSE	-	1	Enquire
0002	905969	LH HOSE	905969 LH HOSE	-	1	Enquire
0003	268661	SCREW COLLAR	268661 SCREW COLLAR	-	4	Enquire
0004	845077	INTAKE LINE AIR FLOW SENSOR HOUSING	845077 INTAKE LINE AIR FLOW SENSOR HOUSING	-	2	Enquire
0005	85833700	SCREW	85833700 SCREW M5 X 14	-	4	Enquire
0006	297280	AIR FLOW SENSOR	297280 AIR FLOW SENSOR	-	2	Enquire
0007	85833700	SCREW	85833700 SCREW M5 X 14	-	4	Enquire
0008	327132	ADHESIVE FOAM	327132 ADHESIVE FOAM	-	2	Enquire
0009	841336	SQUARE MESH GRILLE FOR MASS AIR FLOW SENSOR	841336 SQUARE MESH GRILLE FOR MASS AIR FLOW SENSOR	-	2	Enquire
0010	340691	GPF PRESSURE SENSOR	340691 GPF PRESSURE SENSOR	-	4	Enquire
0011	231620	SCREW	231620 SCREW M6 X 25	-	4	Enquire
0012	901815	GPF SENSOR BRACKET	901815 GPF SENSOR BRACKET	-	2	Enquire
0013	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM M6 X 16	-	4	Enquire
0014	825111	COMPL. GPF PIPE	825111 COMPL. GPF PIPE	-	2	Enquire
0015	13432070	HOSE COLLAR	13432070 HOSE COLLAR	-	12	Enquire
0016	13126970	COLLAR	13126970 COLLAR	-	2	Enquire
0017	825098	RUBBER PIPE	825098 RUBBER PIPE	-	2	Enquire
0018	825100	RUBBER PIPE	825100 RUBBER PIPE	-	2	Enquire
0019	825110	COMPL. GPF PIPE	825110 COMPL. GPF PIPE	-	2	Enquire
0020	913829	THREE WAY	913829 THREE WAY	-	2	Enquire
0021	13125470	COLLAR	13125470 COLLAR	-	2	Enquire
0022	787780	REAR OXYGEN SENSOR	787780 REAR OXYGEN SENSOR	-	2	Enquire
0023	787778	FRONT OXYGEN SENSOR	787778 FRONT OXYGEN SENSOR	-	2	Enquire
0024	861912	IGNITION ECU	861912 IGNITION ECU Unprogrammed	-	2	Enquire
0025	941421	ION ECU CASING	941421 ION ECU CASING For vehicles up to Ass.ly No. 219959, replace as a pair; Unprogrammed	-	2	Enquire
0025	941421	ION ECU CASING	941421 ION ECU CASING Unprogrammed	-	2	Enquire
0026	102741	NUT M6 X 6	102741 NUT M6 X 6	-	6	Enquire
