FRONT BUMPER of Ferrari Ferrari California (2012-2014)

View All

Ferrari California (2012-2014) - FRONT BUMPER

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	82955110	COMPLETE FRONT BUMPER	Enquire	To Order
	82954710	COMPLETE FRONT BUMPER	Enquire	To Order
	82433410	COMPLETE FRONT BUMPER	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	81866900	FRONT SPOILER	Enquire	To Order
	80867100	Front Spoiler	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84753700	FRONT BUMPER GRILLE	Enquire	To Order
	69830700	FRONT BUMPER GRILL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67165200	PRANCING HORSE MOTIF	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16101714	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228119	R.H. BRAKE AIR INTAKE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228118	L.H. BRAKE AIR INTAKE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84505000	IMPACT BEAM FOR USA	Enquire	To Order
	69758200	SIDE COLLISION BEAM, USA	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84399100	FRONT UPPER CENTRAL ABSORBER	Enquire	To Order
	80221600	UPPER CENTRAL FRONT ABSORBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	69830900	LOWER CENTRAL FRONT ABSORBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82660000	INSTALLING FRONT LICENSE PLATE	Enquire	To Order
	82660100	INSTALLING FRONT LICENSE PLATE	Enquire	To Order
	82660200	INSTALLING FRONT LICENSE PLATE	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	80909100	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15784004	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80909200	TOW HOOK BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16286121	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	251303	FRONT PARKING SENSOR CABLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	239082	Parking Sensor	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	770452	SILICONE RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	232578	OUTER RH SENSOR BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	232579	OUTER LH SENSOR BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	217832	PARKING SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	223516	GASKET FOR PARKING SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	232580	Inner RH Sensor Bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	232581	Inner LH Sensor Bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81078400	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16296934	SCREW 6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14215480	BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15687275	Screw	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14296196	RIVET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	880041	Allen Head Bolt M6 X 26	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	105864	SPACER WASHER D.6.5-24X1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80874900	SCREW M6 X 22MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	83453100	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	82955110	COMPLETE FRONT BUMPER	82955110 COMPLETE FRONT BUMPER Optional; Parking sensors; Does not contain sensors; Applicable for USA, CDN, USA LIGHT	-	1	Enquire
1	82954710	COMPLETE FRONT BUMPER	82954710 COMPLETE FRONT BUMPER Optional; Parking sensors; Does not contain sensors; Not for USA, CDN, USA LIGHT	-	1	Enquire
1	82433410	COMPLETE FRONT BUMPER	82433410 COMPLETE FRONT BUMPER Applicable for USA, CDN, USA LIGHT	-	1	Enquire
1	81961810	COMPLETE FRONT BUMPER	81961810 COMPLETE FRONT BUMPER Not for USA, CDN, USA LIGHT	-	1	Enquire
2	81866900	FRONT SPOILER	81866900 FRONT SPOILER Carbon version	-	1	Enquire
2	80867100	Front Spoiler	80867100 Front Spoiler Standard	-	1	Enquire
3	84753700	FRONT BUMPER GRILLE	84753700 FRONT BUMPER GRILLE Matte Nürburgring Silver	-	1	Enquire
3	69830700	FRONT BUMPER GRILL	69830700 FRONT BUMPER GRILL	-	1	Enquire
4	67165200	PRANCING HORSE MOTIF	67165200 PRANCING HORSE MOTIF	-	1	Enquire
5	16101714	NUT	16101714 NUT	-	2	Enquire
6	228119	R.H. BRAKE AIR INTAKE	228119 R.H. BRAKE AIR INTAKE	-	1	Enquire
7	228118	L.H. BRAKE AIR INTAKE	228118 L.H. BRAKE AIR INTAKE	-	1	Enquire
9	84505000	IMPACT BEAM FOR USA	84505000 IMPACT BEAM FOR USA not affected by modification; Applicable for CINA, USA, CDN, GOLFO, USA LIGHT; Applicable from Ass. No. 103179	-	1	Enquire
9	69758200	SIDE COLLISION BEAM, USA	69758200 SIDE COLLISION BEAM, USA Applicable for CINA, USA, CDN, GOLFO, USA LIGHT; Applicable up to Ass. No. 103178	-	1	Enquire
10	84399100	FRONT UPPER CENTRAL ABSORBER	84399100 FRONT UPPER CENTRAL ABSORBER not affected by modification; Applicable for CINA, USA, CDN, GOLFO, USA LIGHT; Applicable from Ass. No. 103179	-	1	Enquire
10	80221600	UPPER CENTRAL FRONT ABSORBER	80221600 UPPER CENTRAL FRONT ABSORBER Applicable for CINA, USA, CDN, GOLFO, USA LIGHT; Applicable up to Ass. No. 103178	-	1	Enquire
11	69830900	LOWER CENTRAL FRONT ABSORBER	69830900 LOWER CENTRAL FRONT ABSORBER Applicable for CINA, USA, CDN, GOLFO, USA LIGHT	-	1	Enquire
12	82660000	INSTALLING FRONT LICENSE PLATE	82660000 INSTALLING FRONT LICENSE PLATE Applicable for CINA	-	1	Enquire
12	82660100	INSTALLING FRONT LICENSE PLATE	82660100 INSTALLING FRONT LICENSE PLATE Applicable for USA, CDN, GOLFO, USA LIGHT	-	1	Enquire
12	82660200	INSTALLING FRONT LICENSE PLATE	82660200 INSTALLING FRONT LICENSE PLATE Applicable for J	-	1	Enquire
12	82660300	INSTALLING FRONT LICENSE PLATE	82660300 INSTALLING FRONT LICENSE PLATE Applicable for AUS	-	1	Enquire
12	69769500	Front License Plate Installation	69769500 Front License Plate Installation Not for AUS, CINA, USA, CDN, GOLFO, J, USA LIGHT	-	1	Enquire
13	80909100	BRACKET	80909100 BRACKET Not for AUS, CINA, USA, CDN, GOLFO, J, USA LIGHT	-	1	Enquire
14	15784004	SCREW	15784004 SCREW Not for AUS, CINA, USA, CDN, GOLFO, J, USA LIGHT	-	4	Enquire
15	80909200	TOW HOOK BRACKET	80909200 TOW HOOK BRACKET Applicable for CINA, USA, CDN, GOLFO, USA LIGHT	-	1	Enquire
16	16286121	SCREW	16286121 SCREW M6 X 20; Applicable for CINA, USA, CDN, GOLFO, USA LIGHT	-	2	Enquire
17	251303	FRONT PARKING SENSOR CABLE	251303 FRONT PARKING SENSOR CABLE Optional; Parking sensors; Applicable up to Ass. No. 91188	-	1	Enquire
18	239082	Parking Sensor	239082 Parking Sensor Optional; Parking sensors	-	2	Enquire
19	770452	SILICONE RING	770452 SILICONE RING Optional; Parking sensors	-	2	Enquire
20	232578	OUTER RH SENSOR BRACKET	232578 OUTER RH SENSOR BRACKET Optional; Parking sensors	-	1	Enquire
21	232579	OUTER LH SENSOR BRACKET	232579 OUTER LH SENSOR BRACKET Optional; Parking sensors	-	1	Enquire
22	217832	PARKING SENSOR	217832 PARKING SENSOR Optional; Parking sensors	-	2	Enquire
23	223516	GASKET FOR PARKING SENSOR	223516 GASKET FOR PARKING SENSOR Optional; Parking sensors	-	2	Enquire
24	232580	Inner RH Sensor Bracket	232580 Inner RH Sensor Bracket Optional; Parking sensors	-	1	Enquire
25	232581	Inner LH Sensor Bracket	232581 Inner LH Sensor Bracket Optional; Parking sensors	-	1	Enquire
26	81078400	CLIP	81078400 CLIP	-	16	Enquire
27	16296934	SCREW 6 X 14MM	16296934 SCREW 6 X 14MM	-	2	Enquire
28	14215480	BLOCK	14215480 BLOCK Applicable for AUS, USA, CDN, GOLFO, J, USA LIGHT	-	6	Enquire
29	15687275	Screw	15687275 Screw Not for AUS, USA, CDN, GOLFO, J, USA LIGHT	-	6	Enquire
30	14296196	RIVET	14296196 RIVET Not for AUS, USA, CDN, GOLFO, J, USA LIGHT	-	1	Enquire
31	880041	Allen Head Bolt M6 X 26	880041 Allen Head Bolt M6 X 26 M6 X 17	-	7	Enquire
32	105864	SPACER WASHER D.6.5-24X1.5	105864 SPACER WASHER D.6.5-24X1.5 not affected by modification; Applicable from Ass. No. 103179	-	30	Enquire
33	80874900	SCREW M6 X 22MM	80874900 SCREW M6 X 22MM	-	6	Enquire
34	83453100	SCREW	83453100 SCREW	-	2	Enquire
