Ferrari 456 M GT/GTA - FUEL COOLING SYSTEM -Valid for USA M.Y. 2000, USA M.Y. 2001, CDN M.Y. 2000 and CDN M.Y. 2001-

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
181255 PETROL/FREON HEAT EXCHANGER Enquire To Order
Photo Part No Description Price (each) Stock
182187 LOWER INSULATION Enquire To Order
Photo Part No Description Price (each) Stock
182186 LOWER PLATE Enquire To Order
Photo Part No Description Price (each) Stock
182158 UPPER BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
81591700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
127494 WASHER Enquire IN STOCK
Photo Part No Description Price (each) Stock
182157 L.H. FUEL TUBE Enquire To Order
Photo Part No Description Price (each) Stock
182152 THREADED PIN Enquire To Order
Photo Part No Description Price (each) Stock
319201 FUEL FILLER PIPE ASSEMBLY Enquire IN STOCK
Photo Part No Description Price (each) Stock
12637824 WASHER Enquire IN STOCK
Photo Part No Description Price (each) Stock
65990100 PIPE FROM EXCHANGER TO FLEXIBLE PIPE Enquire To Order
Photo Part No Description Price (each) Stock
65990200 CAPILLAR PIPE FROM EXCHANGER TO SOLENOID VALVE EXHAUST PIPE Enquire To Order
Photo Part No Description Price (each) Stock
65990300 PIPE FROM EXHAUST VALVE TO CAPILLAR PIPE Enquire To Order
Photo Part No Description Price (each) Stock
65990600 PIPE FROM SOLENOID VALVE TO FILTER PIPE Enquire To Order
Photo Part No Description Price (each) Stock
65990700 COMPLETE SOLENOID VALVE Enquire To Order
Photo Part No Description Price (each) Stock
231625 SCREW Enquire IN STOCK
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire IN STOCK
Photo Part No Description Price (each) Stock
127494 WASHER Enquire IN STOCK
Photo Part No Description Price (each) Stock
12643724 WASHER Enquire IN STOCK
Photo Part No Description Price (each) Stock
138478 BRACKET WITH SHEATH Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire IN STOCK
Photo Part No Description Price (each) Stock
12643724 WASHER Enquire IN STOCK
View All
FUEL COOLING SYSTEM -Valid for USA M.Y. 2000, USA M.Y. 2001, CDN M.Y. 2000 and CDN M.Y. 2001- of Ferrari Ferrari 456 M GT/GTA Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 182155
R.H. FUEL TUBE 		- 1 Enquire
1 181255
PETROL/FREON HEAT EXCHANGER
EXCHANGER 		- 2 Enquire
2 182187
LOWER INSULATION 		- 1 Enquire
3 182186
LOWER PLATE 		- 1 Enquire
4 182158
UPPER BRACKET 		- 2 Enquire
5 81591700
SCREW 		- 1 Enquire
6 127494
WASHER
IN STOCK 		- 1 Enquire
7 182157
L.H. FUEL TUBE 		- 1 Enquire
8 182152
THREADED PIN 		- 4 Enquire
9 319201
FUEL FILLER PIPE ASSEMBLY
IN STOCK 		- 4 Enquire
10 12637824
WASHER
IN STOCK 		- 4 Enquire
11 65990100
PIPE FROM EXCHANGER TO FLEXIBLE PIPE
FLEXIBLE PIPE 		- 1 Enquire
12 65990200
CAPILLAR PIPE FROM EXCHANGER TO SOLENOID VALVE EXHAUST PIPE
SOLENOID VALVE EXHAUST PIPE 		- 1 Enquire
13 65990300
PIPE FROM EXHAUST VALVE TO CAPILLAR PIPE
TO CAPILLAR PIPE 		- 1 Enquire
14 65990600
PIPE FROM SOLENOID VALVE TO FILTER PIPE
TO FILTER PIPE 		- 1 Enquire
15 65990700
COMPLETE SOLENOID VALVE 		- 1 Enquire
16 231625
SCREW
IN STOCK 		- 2 Enquire
17 14059290
FLANGED NUT M6
IN STOCK 		- 2 Enquire
18 127494
WASHER
IN STOCK 		- 2 Enquire
19 12643724
WASHER
IN STOCK 		- 4 Enquire
20 138478
BRACKET WITH SHEATH 		- 1 Enquire
21 14059290
FLANGED NUT M6
IN STOCK 		- 1 Enquire
22 12643724
WASHER
IN STOCK 		- 1 Enquire
