ENGINE OIL PUMP of Ferrari Ferrari 296 GTB Europe

View All

Ferrari 296 GTB Europe - ENGINE OIL PUMP

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	968943	COMPL. OIL PUMP	Enquire	To Order
	864150	COMPL. OIL PUMP	Enquire	To Order
	762665	COMPL. OIL PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	965552	OIL RECOVERY PUMP FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14302124	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	986899	WASHER	Enquire	To Order
	986899	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	285494	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	804067	CHECK VALVE	Enquire	To Order
	834674	CHECK VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	949381	HEXAGONAL OIL PUMP DRIVE ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	804074	CALIBRATED SCREW	Enquire	To Order
	864151	CALIBRATED SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	910598	OIL PUMP BUSHING MOUNTING BRACKET	Enquire	To Order
	866272	OIL PUMP BUSHING MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282391	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	335148	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	335150	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	986899	WASHER	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	968943	COMPL. OIL PUMP	968943 COMPL. OIL PUMP Applicable up to engine No. 535543	-	1	Enquire
1	864150	COMPL. OIL PUMP	864150 COMPL. OIL PUMP No longer supplied - Replaced by 762665; Applicable from engine No. 535544	-	1	Enquire
1	762665	COMPL. OIL PUMP	762665 COMPL. OIL PUMP Applicable from engine No. 535544	-	1	Enquire
2	965552	OIL RECOVERY PUMP FILTER	965552 OIL RECOVERY PUMP FILTER	-	1	Enquire
3	14302124	SCREW	14302124 SCREW M8 X 100	-	2	Enquire
4	986899	WASHER	986899 WASHER	-	2	Enquire
4	986899	WASHER	986899 WASHER	-	2	Enquire
5	285494	SCREW	285494 SCREW M8 X 50	-	2	Enquire
6	804067	CHECK VALVE	804067 CHECK VALVE Applies until depletion	-	1	Enquire
6	834674	CHECK VALVE	834674 CHECK VALVE Applicable after depletion of 804067	-	1	Enquire
7	949381	HEXAGONAL OIL PUMP DRIVE ROD	949381 HEXAGONAL OIL PUMP DRIVE ROD	-	1	Enquire
8	804074	CALIBRATED SCREW	804074 CALIBRATED SCREW Applicable up to engine No. 535543	-	2	Enquire
8	864151	CALIBRATED SCREW	864151 CALIBRATED SCREW Applicable from engine No. 535544	-	2	Enquire
9	910598	OIL PUMP BUSHING MOUNTING BRACKET	910598 OIL PUMP BUSHING MOUNTING BRACKET Applicable up to engine No. 535543	-	1	Enquire
9	866272	OIL PUMP BUSHING MOUNTING BRACKET	866272 OIL PUMP BUSHING MOUNTING BRACKET Applicable from engine No. 535544	-	1	Enquire
10	282391	SCREW	282391 SCREW M6 X 12	-	1	Enquire
11	335148	O-RING	335148 O-RING	-	1	Enquire
12	335150	O-RING	335150 O-RING	-	1	Enquire
13	986899	WASHER	986899 WASHER	-	2	Enquire
