Aston Martin Cygnet - Clutch Assembly and Release Cylinder

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
3121052130 Cover Assy, Clutch Enquire To Order
Photo Part No Description Price (each) Stock
3125052120 Disc Assy, Clutch Enquire To Order
Photo Part No Description Price (each) Stock
9011908079 Screw Seattrack Enquire To Order
Photo Part No Description Price (each) Stock
3140079005 Cylinder Assy, Clutch Release Bearing Enquire To Order
Photo Part No Description Price (each) Stock
9011908C91 Bolt, W/Washer Enquire To Order
Photo Part No Description Price (each) Stock
3140774010 Bleeder Sub-Assy. Clutch Release Enquire To Order
Photo Part No Description Price (each) Stock
3147830010 Cap, Plug, Bleeder, Front Brake Cylinder Enquire To Order
Photo Part No Description Price (each) Stock
90105W0112 Bolt, Flange Enquire To Order
Photo Part No Description Price (each) Stock
3148274030 Tube, Bleeder Clutch Release Enquire To Order
Photo Part No Description Price (each) Stock
3112605010 Boot, Clutch Tube Enquire To Order
View All
Clutch Assembly and Release Cylinder of Aston Martin Aston Martin Cygnet Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 3125052210
Disc Assy, Clutch
*From 10/2010 		- 1 Enquire
- 3140079015
Cylinder Assy, Clutch Release Bearing
*From 05/2010 		- 1 Enquire
- 3148274040
Tube, Bleeder Clutch Release
*From 05/2010 		- 1 Enquire
1 3121052130
Cover Assy, Clutch 		- 1 Enquire
2 3125052120
Disc Assy, Clutch
*05/2009 to 09/2010 		- 1 Enquire
3 9011908079
Screw Seattrack 		- 6 Enquire
4 3140079005
Cylinder Assy, Clutch Release Bearing
*11/2008 to 05/2010 		- 1 Enquire
5 9011908C91
Bolt, W/Washer 		- 3 Enquire
6 3140774010
Bleeder Sub-Assy. Clutch Release 		- 1 Enquire
7 3147830010
Cap, Plug, Bleeder, Front Brake Cylinder 		- 1 Enquire
8 90105W0112
Bolt, Flange 		- 2 Enquire
9 3148274030
Tube, Bleeder Clutch Release
*11/2008 to 05/2010 		- 1 Enquire
10 3112605010
Boot, Clutch Tube 		- 1 Enquire
