Curtains In The Rear

Rolls Royce Phantom Extended Wheelbase

Find Your Part

Rolls Royce Phantom Extended Wheelbase - Curtains in the rear

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
51466959905 Guide rail, curtain, top Enquire To Order
Photo Part No Description Price (each) Stock
51717065987 Hex nut Enquire To Order
Photo Part No Description Price (each) Stock
7147120341 Fillister head screw Enquire To Order
Photo Part No Description Price (each) Stock
11727559515 Rubber mounting Enquire To Order
Photo Part No Description Price (each) Stock
7146981606 Hex nut with plate Enquire To Order
Photo Part No Description Price (each) Stock
51466986101 Set, electric motor Enquire To Order
Photo Part No Description Price (each) Stock
51427144938 Rubber mounting Enquire To Order
Photo Part No Description Price (each) Stock
51466959908 Guide rail, curtain, bottom Enquire To Order
Photo Part No Description Price (each) Stock
51426988859 Curtain rail, lower left Enquire To Order
51426988860 Curtain rail, lower right Enquire To Order
Photo Part No Description Price (each) Stock
51427272727 Cover, window frame, door rear left Enquire To Order
51427272728 Cover, window frame, door rear right Enquire To Order
51427272737 Cover, window frame, door rear left Enquire To Order
...and 3 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
51426988559 Drive, curtain door left Enquire To Order
51426988560 Drive, curtain door right Enquire To Order
Photo Part No Description Price (each) Stock
51477074999 Connection piece Enquire To Order
Photo Part No Description Price (each) Stock
51467157306 Screw Enquire To Order
Photo Part No Description Price (each) Stock
11119157031 Cheese-head screw Enquire To Order
51718203903 Cheese-head screw Enquire To Order
Photo Part No Description Price (each) Stock
51467151509 Plug Enquire To Order
Photo Part No Description Price (each) Stock
51467157307 Plug Enquire To Order
Photo Part No Description Price (each) Stock
7119905269 Screw Enquire To Order
Photo Part No Description Price (each) Stock
51427157308 Bracket, motor, left Enquire To Order
51446958584 Bracket, motor, right Enquire To Order
Photo Part No Description Price (each) Stock
51467152688 Brackets, upper rails, rear curtain Enquire To Order
Photo Part No Description Price (each) Stock
51467135310 Brackets, lower rails, rear curtain Enquire To Order
Photo Part No Description Price (each) Stock
51477111438 ISA screw Enquire To Order
Photo Part No Description Price (each) Stock
63259128043 Hex nut with plate Enquire To Order
Photo Part No Description Price (each) Stock
51467133588 Tubing guide Enquire To Order
Photo Part No Description Price (each) Stock
51429182315 Engine support, left Enquire To Order
51429182316 Engine support, right Enquire To Order
Photo Part No Description Price (each) Stock
7129904319 Hex nut Enquire To Order
Photo Part No Description Price (each) Stock
51168223113 Hex nut Enquire To Order
View All
Curtains in the rear of Rolls Royce Rolls Royce Phantom Extended Wheelbase Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 7147135145
Washer 		- - Enquire
1 51466959905
Guide rail, curtain, top 		- - Enquire
2 51717065987
Hex nut
M6 		- - Enquire
3 7147120341
Fillister head screw 		- - Enquire
4 11727559515
Rubber mounting
M6 		- - Enquire
5 7146981606
Hex nut with plate 		- - Enquire
7 51466986101
Set, electric motor 		- - Enquire
8 51427144938
Rubber mounting
M5 		- - Enquire
9 51466959908
Guide rail, curtain, bottom 		- - Enquire
10 51426988859
Curtain rail, lower left 		- - Enquire
10 51426988860
Curtain rail, lower right 		- - Enquire
11 51427272727
Cover, window frame, door rear left
INC RAIL 		- - Enquire
11 51427272728
Cover, window frame, door rear right
INC RAIL 		- - Enquire
11 51427272737
Cover, window frame, door rear left
INC RAIL 		- - Enquire
11 51427272738
Cover, window frame, door rear right
INC RAIL 		- - Enquire
11 51446988117
Cover, window frame, door rear left
INC RAIL 		- - Enquire
11 51446988118
Cover, window frame, door rear right
INC RAIL 		- - Enquire
12 51426988559
Drive, curtain door left 		- - Enquire
12 51426988560
Drive, curtain door right 		- - Enquire
13 51477074999
Connection piece
BOWDENZUG 		- - Enquire
14 51467157306
Screw 		- - Enquire
15 11119157031
Cheese-head screw 		- - Enquire
15 51718203903
Cheese-head screw 		- - Enquire
16 51467151509
Plug
SCHIENE 		- - Enquire
17 51467157307
Plug
VORHANG.C-SДULE 		- - Enquire
18 7119905269
Screw 		- - Enquire
19 51427157308
Bracket, motor, left 		- - Enquire
19 51446958584
Bracket, motor, right 		- - Enquire
20 51467152688
Brackets, upper rails, rear curtain 		- - Enquire
21 51467135310
Brackets, lower rails, rear curtain 		- - Enquire
22 51477111438
ISA screw
M6X30-8.8-CR 		- - Enquire
23 63259128043
Hex nut with plate
M5 		- - Enquire
24 51467133588
Tubing guide
PAIR 		- - Enquire
25 51429182315
Engine support, left 		- - Enquire
25 51429182316
Engine support, right 		- - Enquire
26 7129904319
Hex nut
AM5-8-ZNNIV SI 		- - Enquire
27 51168223113
Hex nut
M4 		- - Enquire
