Floor panel trunk wheel housing rear of Rolls Royce Rolls Royce Ghost RR4(2017-2019)

View All

Rolls Royce Ghost RR4(2017-2019) - Floor panel trunk wheel housing rear (1)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	41007242647	Trunk floor	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41117242627	Holder, rear seat, rear outer left	Enquire	To Order
	41117242628	Holder, rear seat, rear outer right	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41117242629	Holder, rear seat, rear inner left	Enquire	To Order
	41117242630	Holder, rear seat, rear inner right	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41007242631	Bracket, seat	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41117242625	Rear seat bench bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41007242633	Rear left wheelhouse	Enquire	To Order
	41007242634	Rear right wheelhouse	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41147204101	Holder,activat.carbon contain.,front	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41147204102	Bracket, activated charcoal filter, rear	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41127242635	Extension for rear left wheel well	Enquire	To Order
	41127242636	Extension for rear right wheel well	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41007242637	Connection, side frame, rear left	Enquire	To Order
	41007242638	Connection, side frame, rear right	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41117204138	Right side member extension	Enquire	To Order
	41117344261	Left side member extension	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41117204117	Support, air supply system rear	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41117204111	Support, air supply unit, left	Enquire	To Order
	41117204112	Support, air supply unit, right	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41007244113	Luggage-compartment floor, rear	Enquire	To Order
	41127310119	Luggage-compartment floor, rear	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41117204113	Left side member	Enquire	To Order
	41117204114	Right side member	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41217282707	Wheelhouse rear, outer half left	Enquire	To Order
	41217282708	Wheelhousing, rear, outer section, right	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	41117314536	Bracket ashtray	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	61217622074	Battery holder	61217622074 Battery holder from 07.2012	-	1	Enquire
-	61139213212	Holding frame with dummy grommet	61139213212 Holding frame with dummy grommet D=70MM; from 07.2012	-	1	Enquire
-	41007242632	Mount, bumper	41007242632 Mount, bumper from 07.2012	-	2	Enquire
-	41007242648	Cross member, trunk floor rear	41007242648 Cross member, trunk floor rear from 07.2012	-	1	Enquire
-	41007242649	Cross member, trunk floor, bottom	41007242649 Cross member, trunk floor, bottom from 07.2012	-	1	Enquire
-	41007279333	Holder, charging socket	41007279333 Holder, charging socket from 07.2012	-	1	Enquire
-	7146975569	Blind rivet nut, flat headed	7146975569 Blind rivet nut, flat headed M10; from 07.2012	-	2	Enquire
-	7147133560	Blind plug	7147133560 Blind plug D=9.0MM; from 07.2012	-	12	Enquire
-	7149174618	Blind rivet nut, flat headed	7149174618 Blind rivet nut, flat headed M6; from 07.2012	-	12	Enquire
-	83425A547B9	Sealant D2	83425A547B9 Sealant D2 290ML; from 07.2012	-	1	Enquire
-	41217203139	Moulded part f column C, interior left	41217203139 Moulded part f column C, interior left	-	1	Enquire
-	41217203140	Moulded part f column C, interior right	41217203140 Moulded part f column C, interior right	-	1	Enquire
1	41007242647	Trunk floor	41007242647 Trunk floor from 07.2012	-	1	Enquire
2	41117242627	Holder, rear seat, rear outer left	41117242627 Holder, rear seat, rear outer left	-	1	Enquire
2	41117242628	Holder, rear seat, rear outer right	41117242628 Holder, rear seat, rear outer right	-	1	Enquire
3	41117242629	Holder, rear seat, rear inner left	41117242629 Holder, rear seat, rear inner left	-	1	Enquire
3	41117242630	Holder, rear seat, rear inner right	41117242630 Holder, rear seat, rear inner right	-	1	Enquire
4	41007242631	Bracket, seat	41007242631 Bracket, seat	-	1	Enquire
5	41117242625	Rear seat bench bracket	41117242625 Rear seat bench bracket	-	5	Enquire
6	41007242633	Rear left wheelhouse	41007242633 Rear left wheelhouse	-	1	Enquire
6	41007242634	Rear right wheelhouse	41007242634 Rear right wheelhouse	-	1	Enquire
7	41147204101	Holder,activat.carbon contain.,front	41147204101 Holder,activat.carbon contain.,front	-	2	Enquire
8	41147204102	Bracket, activated charcoal filter, rear	41147204102 Bracket, activated charcoal filter, rear	-	1	Enquire
9	41127242635	Extension for rear left wheel well	41127242635 Extension for rear left wheel well	-	1	Enquire
9	41127242636	Extension for rear right wheel well	41127242636 Extension for rear right wheel well	-	1	Enquire
10	41007242637	Connection, side frame, rear left	41007242637 Connection, side frame, rear left	-	1	Enquire
10	41007242638	Connection, side frame, rear right	41007242638 Connection, side frame, rear right	-	1	Enquire
11	41117204138	Right side member extension	41117204138 Right side member extension	-	1	Enquire
11	41117344261	Left side member extension	41117344261 Left side member extension	-	1	Enquire
15	41117204117	Support, air supply system rear	41117204117 Support, air supply system rear	-	1	Enquire
16	41117204111	Support, air supply unit, left	41117204111 Support, air supply unit, left	-	1	Enquire
16	41117204112	Support, air supply unit, right	41117204112 Support, air supply unit, right	-	1	Enquire
17	41007244113	Luggage-compartment floor, rear	41007244113 Luggage-compartment floor, rear from 07.2012	-	1	Enquire
17	41127310119	Luggage-compartment floor, rear	41127310119 Luggage-compartment floor, rear	-	1	Enquire
18	41117204113	Left side member	41117204113 Left side member	-	1	Enquire
18	41117204114	Right side member	41117204114 Right side member	-	1	Enquire
20	41217282707	Wheelhouse rear, outer half left	41217282707 Wheelhouse rear, outer half left	-	1	Enquire
20	41217282708	Wheelhousing, rear, outer section, right	41217282708 Wheelhousing, rear, outer section, right	-	1	Enquire
22	41117314536	Bracket ashtray	41117314536 Bracket ashtray to 09.2011	-	1	Enquire
