ADDITIONAL AIR SYSTEM of Maserati Maserati GranSport Spyder (2005-2007)

View All

Maserati GranSport Spyder (2005-2007) - ADDITIONAL AIR SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	210189	VACUUM TANK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208281	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14040614	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	195066	VALVE AIR DELIVERY TUBE	Enquire	To Order
	195065	VALVE AIR DELIVERY TUBE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	171175	Secondary Air Valve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	186274	SECONDARY AIR VALVE PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	186781	Gasket for Manifold	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231617	SCREW M6 X 18	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155116	SLEEVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	262111	SLEEVE FASTENING COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147121	L.H. RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	300100803	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	257691	3-WAY UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	315769	On/Off Solenoid Valve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14304124	SCREW TCEI M5 x 12	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	181197	SECONDARY AIR PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	184837	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16296924	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	190992	PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	262111	SLEEVE FASTENING COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	162606	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159740	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	388100423	RUBBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	152630	THREADED UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150595	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	194436	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	194437	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	219456	VIBRATION-DAMPING MOUNT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	219457	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14498801	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	253896	NONRETURN VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	257691	3-WAY UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159541	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	211475	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	118502	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	277185	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10418601	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059214	Nut Flanged M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	214008	RIGID PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	215411	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	289103	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	315769	On/Off Solenoid Valve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13283217	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	216140	SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	225102	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	257691	3-WAY UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208461	R.H. RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208460	L.H. RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10441390	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208039	SOLENOID VALVE AND POTENTIOMETER LINKING CABLE	Enquire	To Order
	208038	SOLENOID VALVE CABLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12637824	WASHER	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	210189	VACUUM TANK	210189 VACUUM TANK	-	1	Enquire
2	208281	BRACKET	208281 BRACKET	-	1	Enquire
3	14040614	NUT	14040614 NUT	-	4	Enquire
4	195066	VALVE AIR DELIVERY TUBE	195066 VALVE AIR DELIVERY TUBE Not for RHD	-	1	Enquire
4	195065	VALVE AIR DELIVERY TUBE	195065 VALVE AIR DELIVERY TUBE Valid for RHD	-	1	Enquire
5	171175	Secondary Air Valve	171175 Secondary Air Valve	-	2	Enquire
6	186274	SECONDARY AIR VALVE PIPE	186274 SECONDARY AIR VALVE PIPE	-	2	Enquire
7	186781	Gasket for Manifold ARRIVING SOON	186781 Gasket for Manifold ARRIVING SOON	-	4	Enquire
8	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM	-	4	Enquire
9	127494	WASHER	127494 WASHER	-	4	Enquire
10	231617	SCREW M6 X 18	231617 SCREW M6 X 18	-	4	Enquire
11	127494	WASHER	127494 WASHER	-	4	Enquire
12	155116	SLEEVE	155116 SLEEVE	-	2	Enquire
13	262111	SLEEVE FASTENING COLLAR	262111 SLEEVE FASTENING COLLAR	-	4	Enquire
14	147121	L.H. RUBBER HOSE	147121 L.H. RUBBER HOSE	-	1	Enquire
15	300100803	RUBBER HOSE	300100803 RUBBER HOSE Supplied in meters- -(Minimum quantity 1m. or multiples)	-	-	Enquire
16	257691	3-WAY UNION	257691 3-WAY UNION	-	1	Enquire
17	315769	On/Off Solenoid Valve	315769 On/Off Solenoid Valve	-	1	Enquire
18	14304124	SCREW TCEI M5 x 12	14304124 SCREW TCEI M5 x 12	-	2	Enquire
19	12604178	WASHER	12604178 WASHER D.5.3-11X0.5	-	2	Enquire
20	181197	SECONDARY AIR PUMP	181197 SECONDARY AIR PUMP	-	1	Enquire
21	184837	BRACKET	184837 BRACKET	-	1	Enquire
22	16296924	SCREW	16296924 SCREW	-	2	Enquire
23	190992	PIPE	190992 PIPE	-	1	Enquire
24	262111	SLEEVE FASTENING COLLAR	262111 SLEEVE FASTENING COLLAR	-	2	Enquire
25	14039614	NUT	14039614 NUT	-	3	Enquire
26	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D. 6,40-12X 0,5	-	3	Enquire
27	162606	CLIP	162606 CLIP	-	1	Enquire
28	159740	CLIP	159740 CLIP	-	1	Enquire
29	388100423	RUBBER	388100423 RUBBER	-	1	Enquire
30	152630	THREADED UNION	152630 THREADED UNION	-	2	Enquire
31	150595	NUT	150595 NUT	-	2	Enquire
32	194436	STUD	194436 STUD	-	1	Enquire
33	194437	STUD	194437 STUD	-	1	Enquire
34	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D.6.4-12X2.4	-	2	Enquire
35	14039614	NUT	14039614 NUT	-	2	Enquire
36	219456	VIBRATION-DAMPING MOUNT	219456 VIBRATION-DAMPING MOUNT Valid after stock exhaustion of 315520375	-	2	Enquire
37	219457	SPACER	219457 SPACER	-	2	Enquire
38	14498801	Washer	14498801 Washer	-	4	Enquire
39	253896	NONRETURN VALVE	253896 NONRETURN VALVE	-	1	Enquire
40	257691	3-WAY UNION	257691 3-WAY UNION	-	1	Enquire
41	159541	RUBBER HOSE	159541 RUBBER HOSE	-	1	Enquire
42	211475	RUBBER HOSE	211475 RUBBER HOSE	-	1	Enquire
43	118502	RUBBER HOSE	118502 RUBBER HOSE	-	1	Enquire
44	277185	RUBBER HOSE	277185 RUBBER HOSE	-	1	Enquire
45	10418601	BRACKET WITH SHEATH	10418601 BRACKET WITH SHEATH	-	1	Enquire
46	14059214	Nut Flanged M6	14059214 Nut Flanged M6 M6	-	1	Enquire
47	214008	RIGID PIPE	214008 RIGID PIPE	-	1	Enquire
48	215411	CLIP	215411 CLIP	-	8	Enquire
49	289103	RUBBER HOSE	289103 RUBBER HOSE	-	1	Enquire
50	315769	On/Off Solenoid Valve	315769 On/Off Solenoid Valve	-	1	Enquire
51	13283217	SCREW	13283217 SCREW	-	4	Enquire
52	216140	SHIELD	216140 SHIELD	-	1	Enquire
53	225102	RUBBER HOSE	225102 RUBBER HOSE	-	1	Enquire
54	257691	3-WAY UNION	257691 3-WAY UNION	-	1	Enquire
55	208461	R.H. RUBBER HOSE	208461 R.H. RUBBER HOSE	-	1	Enquire
56	208460	L.H. RUBBER HOSE	208460 L.H. RUBBER HOSE	-	1	Enquire
57	10441390	BRACKET WITH SHEATH	10441390 BRACKET WITH SHEATH	-	2	Enquire
58	208039	SOLENOID VALVE AND POTENTIOMETER LINKING CABLE	208039 SOLENOID VALVE AND POTENTIOMETER LINKING CABLE Valid for cars with opt. Xeno Headlights and Headligts Washer- -Not for USA and CDN	-	1	Enquire
58	208038	SOLENOID VALVE CABLE	208038 SOLENOID VALVE CABLE Not for cars with opt. Xeno Headlights and Headligts Washer- -Valid for cars USA and CDN with opt. Xeno Headlights and Headligts Washer	-	1	Enquire
59	12637824	WASHER	12637824 WASHER	-	4	Enquire
