Steering 3

Lamborghini Murcielago LP640

Find Your Part

Lamborghini Murcielago LP640 - Steering 3

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Steering 3 of Lamborghini Lamborghini Murcielago LP640 Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 410953515A
COVERING (E-GEAR) 		- 1 Enquire
001 410953515
COVERING (MANUAL GEARBOX) 		- 1 Enquire
003 WHT001187
WASHER 		- 2 Enquire
004 N0447347
SCREW M5X16 		- 2 Enquire
005 410953513
Column Switch 		- 1 Enquire
006 N10656302
HEXAGON SOCKET OVAL HEAD BOLT 		- 4 Enquire
008 N01396626
SCREW 		- 4 Enquire
009 410422167A
BRACKET (MANUAL GEARBOX) 		- 1 Enquire
009 410951269A
BRACKET (E-GEAR) 		- 1 Enquire
010 N10612001
WASHER 		- 4 Enquire
011 N10648502
SCREW M5X10 		- 4 Enquire
012 N0154487
SPEED NUT 		- 4 Enquire
013 410953516
COVERING (MANUAL GEARBOX) 		- 1 Enquire
013 410953516A
COVERING (E-GEAR) 		- 1 Enquire
014 410422168A
BRACKET 		- 1 Enquire
016 410951523A
E-GEAR PAD ASSEMBLY 		- 1 Enquire
016 410951523B
E-GEAR PAD ASSEMBLY (CARBON INTERIOR DARK) 		- 1 Enquire
017 N10544302
SCREW M5X25 		- 3 Enquire
018 410951527B
LEFT LEVER (CARBON INTERIOR DARK) 		- 1 Enquire
018 410951527
LEFT LEVER 		- 1 Enquire
019 410951528B
RIGHT LEVER (CARBON INTERIOR DARK) 		- 1 Enquire
019 410951528
RIGHT LEVER 		- 1 Enquire
020 WHT003067
SCREW M4X10 (CARBON INTERIOR) 		- 4 Enquire
020 WHT003308
SCREW M4X8 (STANDARD) 		- 4 Enquire
