CERAMIC BRAKE DISC of Lamborghini Lamborghini Huracan Evo Coupe

View All

Lamborghini Huracan Evo Coupe - CERAMIC BRAKE DISC

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4S0615601C	CERAMIC BRAKE DISC (VENTED)	Enquire	To Order
	4S0615602A	Rear Ceramic Rotor RIGHT HAND SIDE	Enquire	To Order
	4T0615601	CERAMIC BRAKE DISC (VENTED)	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	N10648301	HEX SOCKET COUNTERSUNK BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	420615437B	Brake Pad Wear Sensor	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0611847J	RETAINER FOR BRAKE HOSE	Enquire	To Order
	4S0611848J	RETAINER FOR BRAKE HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	420611775A	BRAKE HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0971845D	HOLDER FOR WIRING HARNESS	Enquire	To Order
	4S0971846A	HOLDER FOR WIRING HARNESS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8K0611715	RETAINING SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0698451AF	1 SET OF BRAKE PADS FOR DISK BRAKE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10406504	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91042302	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0611847D	RETAINER FOR BRAKE HOSE	Enquire	To Order
	4S0611848D	RETAINER FOR BRAKE HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4E0927803F	SPEED SENSOR	Enquire	To Order
	4E0927804F	SPEED SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91141801	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10406504	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0615611A	COVER PLATE FOR BRAKE DISC	Enquire	To Order
	4S0615612A	COVER PLATE FOR BRAKE DISC	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N01474011	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		FLOATING CALIPER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		SUSPENSION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	211611483	DUST CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8A0615273	1 SET BLEEDER VALVES WITH DUST CAP	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4S0615601C	CERAMIC BRAKE DISC (VENTED)	4S0615601C CERAMIC BRAKE DISC (VENTED) LEFT REAR	-	1	Enquire
1	4S0615602A	Rear Ceramic Rotor RIGHT HAND SIDE	4S0615602A Rear Ceramic Rotor RIGHT HAND SIDE RIGHT REAR	-	1	Enquire
1	4T0615601	CERAMIC BRAKE DISC (VENTED)	4T0615601 CERAMIC BRAKE DISC (VENTED) MONOLOCK WHEELS-LEFT REAR	-	1	Enquire
1	4T0615602	CERAMIC BRAKE DISC (VENTED)	4T0615602 CERAMIC BRAKE DISC (VENTED) MONOLOCK WHEELS-RIGHT REAR	-	1	Enquire
2	N10648301	HEX SOCKET COUNTERSUNK BOLT	N10648301 HEX SOCKET COUNTERSUNK BOLT M6X16	-	2	Enquire
4	420615437B	Brake Pad Wear Sensor	420615437B Brake Pad Wear Sensor REAR	-	2	Enquire
5	4S0611847J	RETAINER FOR BRAKE HOSE	4S0611847J RETAINER FOR BRAKE HOSE LEFT REAR	-	1	Enquire
5	4S0611848J	RETAINER FOR BRAKE HOSE	4S0611848J RETAINER FOR BRAKE HOSE RIGHT REAR	-	1	Enquire
6	420611775A	BRAKE HOSE	420611775A BRAKE HOSE REAR	-	2	Enquire
7	4S0971845D	HOLDER FOR WIRING HARNESS	4S0971845D HOLDER FOR WIRING HARNESS LEFT REAR	-	1	Enquire
7	4S0971846A	HOLDER FOR WIRING HARNESS	4S0971846A HOLDER FOR WIRING HARNESS RIGHT REAR	-	1	Enquire
8	8K0611715	RETAINING SPRING	8K0611715 RETAINING SPRING	-	2	Enquire
9	4S0698451AF	1 SET OF BRAKE PADS FOR DISK BRAKE	4S0698451AF 1 SET OF BRAKE PADS FOR DISK BRAKE 356X32MM	-	1	Enquire
10	N10406504	OVAL HEXAGON SOCKET HEAD BOLT	N10406504 OVAL HEXAGON SOCKET HEAD BOLT M6X12	-	2	Enquire
11	N91042302	OVAL HEXAGON SOCKET HEAD BOLT	N91042302 OVAL HEXAGON SOCKET HEAD BOLT M6X16	-	1	Enquire
12	4S0611847D	RETAINER FOR BRAKE HOSE	4S0611847D RETAINER FOR BRAKE HOSE LEFT REAR	-	1	Enquire
12	4S0611848D	RETAINER FOR BRAKE HOSE	4S0611848D RETAINER FOR BRAKE HOSE RIGHT REAR	-	1	Enquire
13	4E0927803F	SPEED SENSOR	4E0927803F SPEED SENSOR LEFT	-	1	Enquire
13	4E0927804F	SPEED SENSOR	4E0927804F SPEED SENSOR RIGHT	-	1	Enquire
14	N91141801	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	N91141801 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD M12X1,5X105X90	-	4	Enquire
15	N10406504	OVAL HEXAGON SOCKET HEAD BOLT	N10406504 OVAL HEXAGON SOCKET HEAD BOLT M6X12	-	4	Enquire
16	4S0615611A	COVER PLATE FOR BRAKE DISC	4S0615611A COVER PLATE FOR BRAKE DISC LEFT	-	1	Enquire
16	4S0615612A	COVER PLATE FOR BRAKE DISC	4S0615612A COVER PLATE FOR BRAKE DISC RIGHT	-	1	Enquire
17	N01474011	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	N01474011 SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD M6X16	-	2	Enquire
18	-	FLOATING CALIPER	FLOATING CALIPER SEE ILLUSTRATION :- 609-010	-	-	Enquire
19	-	SUSPENSION	SUSPENSION SEE ILLUSTRATION :-REAR 505-010	-	-	Enquire
20	211611483	DUST CAP	211611483 DUST CAP	-	2	Enquire
21	8A0615273	1 SET BLEEDER VALVES WITH DUST CAP	8A0615273 1 SET BLEEDER VALVES WITH DUST CAP	-	2	Enquire
22	420698269C	1 SET ATTACHMENT PARTS	420698269C 1 SET ATTACHMENT PARTS	-	2	Enquire
