CERAMIC BRAKE DISC of Lamborghini Lamborghini Huracan Evo Coupe

View All

Lamborghini Huracan Evo Coupe - CERAMIC BRAKE DISC

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4S0615301A	Front Ceramic Rotor Left Hand Side	Enquire	To Order
	4S0615302A	Front Ceramic Rotor RIGHT HAND SIDE	Enquire	To Order
	4T0615301	CERAMIC BRAKE DISC (VENTED)	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	N10648301	HEX SOCKET COUNTERSUNK BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T0615106CA	Brake Caliper Housing (right Black)	Enquire	To Order
	4T0615105CA	Brake Caliper Housing (left Black)	Enquire	To Order
	4T0615106DC	BRAKE CALIPER KERAMIK GELB	Enquire	To Order

...and 9 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	4S0611845H	BRACKET	Enquire	To Order
	4S0611846H	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0611707F	BRAKE HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0611841H	BRACKET	Enquire	To Order
	4S0611842H	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0611847K	RETAINER FOR BRAKE HOSE	Enquire	To Order
	4S0611848K	RETAINER FOR BRAKE HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0698151AA	1 SET OF BRAKE PADS FOR DISK BRAKE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10572403	SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK.	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N0902619	HEXAGON HEAD BOLT (COMBI)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90692402	POP RIVET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4E0927804F	SPEED SENSOR	Enquire	To Order
	4E0927803F	SPEED SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT001330A	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10406504	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0615311	COVER PLATE FOR BRAKE DISC	Enquire	To Order
	4S0615312	COVER PLATE FOR BRAKE DISC	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N01474011	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	R1400210	1 SET SPRINGS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T0698010	1 SET DOUBLE-SIDED ADHESIVE TAPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	211611483	DUST CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8A0615273	1 SET BLEEDER VALVES WITH DUST CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0698269A	1 SET ATTACHMENT PARTS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		AXLE SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4E0698507	SET OF GASKETS FOR BRAKE CALIPER HOUSING	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4S0615301A	Front Ceramic Rotor Left Hand Side	4S0615301A Front Ceramic Rotor Left Hand Side 380X38MM 5/112 LEFT FRONT	-	1	Enquire
1	4S0615302A	Front Ceramic Rotor RIGHT HAND SIDE	4S0615302A Front Ceramic Rotor RIGHT HAND SIDE RIGHT FRONT	-	1	Enquire
1	4T0615301	CERAMIC BRAKE DISC (VENTED)	4T0615301 CERAMIC BRAKE DISC (VENTED) MONOLOCK WHEELS-LEFT FRONT	-	1	Enquire
1	4T0615302	CERAMIC BRAKE DISC (VENTED)	4T0615302 CERAMIC BRAKE DISC (VENTED) MONOLOCK WHEELS-RIGHT FRONT	-	1	Enquire
2	N10648301	HEX SOCKET COUNTERSUNK BOLT	N10648301 HEX SOCKET COUNTERSUNK BOLT M6X16	-	2	Enquire
3	4T0615106CA	Brake Caliper Housing (right Black)	4T0615106CA Brake Caliper Housing (right Black) UNTIL VIN ZHWUR2ZF8HLA 07423 ORDER ALSO LEFT 4T0615105CA-RIGHT BLACK	-	1	Enquire
3	4T0615105CA	Brake Caliper Housing (left Black)	4T0615105CA Brake Caliper Housing (left Black) UNTIL VIN ZHWUR2ZF8HLA 07423 ORDER ALSO RIGHT 4T0615106CA-LEFT BLACK	-	1	Enquire
3	4T0615106DC	BRAKE CALIPER KERAMIK GELB	4T0615106DC BRAKE CALIPER KERAMIK GELB UNTIL VIN ZHWEC1ZF7HLA 07428 ORDER ALSO LEFT 4T0615105CB-RIGHT YELLOW	-	1	Enquire
3	4T0615105DC	BRAKE CALIPER HOUSING	4T0615105DC BRAKE CALIPER HOUSING UNTIL VIN ZHWEC1ZF7HLA 07428 ORDER ALSO RIGHT 4T0615106CB-LEFT YELLOW	-	1	Enquire
3	4T0615106CC	Brake Caliper Housing (left Grey)	4T0615106CC Brake Caliper Housing (left Grey) UNTIL VIN ZHWEC1ZF1HLA 07425 ORDER ALSO LEFT 4T0615105CC-LEFT GREY	-	1	Enquire
3	4T0615105CC	Brake Caliper Housing (left Grey)	4T0615105CC Brake Caliper Housing (left Grey) UNTIL VIN ZHWEC1ZF1HLA 07425 ORDER ALSO RIGHT 4T0615106CC-LEFT GREY	-	1	Enquire
3	4T0615106CD	Brake Caliper Housing (right Orange)	4T0615106CD Brake Caliper Housing (right Orange) UNTIL VIN ZHWUR1ZF7HLA 07424 ORDER ALSO LEFT 4T0615105CD-RIGHT ORANGE	-	1	Enquire
3	4T0615105CD	Brake Caliper Housing (left Orange)	4T0615105CD Brake Caliper Housing (left Orange) UNTIL VIN ZHWUR1ZF7HLA 07424 ORDER ALSO RIGHT 4T0615106CD-LEFT ORANGE	-	1	Enquire
3	4T0615106CE	Brake Caliper Housing (right Red)	4T0615106CE Brake Caliper Housing (right Red) UNTIL VIN ZHWEC1ZF6HLA 07422 ORDER ALSO LEFT 4T0615105CE-RIGHT RED	-	1	Enquire
3	4T0615105CE	Brake Caliper Housing (left Red)	4T0615105CE Brake Caliper Housing (left Red) UNTIL VIN ZHWEC1ZF6HLA 07422 ORDER ALSO RIGHT 4T0615106CE-LEFT RED	-	1	Enquire
3	4T0615106CF	Brake Caliper Housing (right Green)	4T0615106CF Brake Caliper Housing (right Green) UNTIL VIN ZHWER1ZF9HLA 07459 ORDER ALSO LEFT 4T0615105CF-RIGHT 'VERDE MANTIS'	-	1	Enquire
3	4T0615105CF	Brake Caliper Housing (left Green)	4T0615105CF Brake Caliper Housing (left Green) UNTIL VIN ZHWER1ZF9HLA 07459 ORDER ALSO RIGHT 4T0615106CF-LEFT 'VERDE MANTIS'	-	1	Enquire
5	4S0611845H	BRACKET	4S0611845H BRACKET LEFT	-	1	Enquire
5	4S0611846H	BRACKET	4S0611846H BRACKET RIGHT	-	1	Enquire
6	4S0611707F	BRAKE HOSE	4S0611707F BRAKE HOSE FRONT	-	2	Enquire
7	4S0611841H	BRACKET	4S0611841H BRACKET LEFT FRONT	-	1	Enquire
7	4S0611842H	BRACKET	4S0611842H BRACKET RIGHT FRONT	-	1	Enquire
8	4S0611847K	RETAINER FOR BRAKE HOSE	4S0611847K RETAINER FOR BRAKE HOSE LEFT FRONT	-	1	Enquire
8	4S0611848K	RETAINER FOR BRAKE HOSE	4S0611848K RETAINER FOR BRAKE HOSE RIGHT FRONT	-	1	Enquire
9	4S0698151AA	1 SET OF BRAKE PADS FOR DISK BRAKE	4S0698151AA 1 SET OF BRAKE PADS FOR DISK BRAKE 380X38MM FRONT	-	1	Enquire
10	N10572403	SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK.	N10572403 SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK. M8X16	-	4	Enquire
11	N0902619	HEXAGON HEAD BOLT (COMBI)	N0902619 HEXAGON HEAD BOLT (COMBI) M6X20	-	1	Enquire
12	N90692402	POP RIVET	N90692402 POP RIVET 4,8X10	-	1	Enquire
13	4E0927804F	SPEED SENSOR	4E0927804F SPEED SENSOR LEFT	-	1	Enquire
13	4E0927803F	SPEED SENSOR	4E0927803F SPEED SENSOR RIGHT	-	1	Enquire
14	WHT001330A	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	WHT001330A SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD M12X1,5X77X30	-	4	Enquire
15	N10406504	OVAL HEXAGON SOCKET HEAD BOLT	N10406504 OVAL HEXAGON SOCKET HEAD BOLT M6X12	-	2	Enquire
16	4S0615311	COVER PLATE FOR BRAKE DISC	4S0615311 COVER PLATE FOR BRAKE DISC LEFT	-	1	Enquire
16	4S0615312	COVER PLATE FOR BRAKE DISC	4S0615312 COVER PLATE FOR BRAKE DISC RIGHT	-	1	Enquire
17	N01474011	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	N01474011 SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD M6X16	-	2	Enquire
18	R1400210	1 SET SPRINGS	R1400210 1 SET SPRINGS 4 SPRINGS FOR KIT	-	1	Enquire
19	4T0698010	1 SET DOUBLE-SIDED ADHESIVE TAPE	4T0698010 1 SET DOUBLE-SIDED ADHESIVE TAPE	-	1	Enquire
20	211611483	DUST CAP	211611483 DUST CAP	-	2	Enquire
21	8A0615273	1 SET BLEEDER VALVES WITH DUST CAP	8A0615273 1 SET BLEEDER VALVES WITH DUST CAP	-	2	Enquire
22	4S0698269A	1 SET ATTACHMENT PARTS	4S0698269A 1 SET ATTACHMENT PARTS	-	2	Enquire
23	-	AXLE SHAFT	AXLE SHAFT SEE ILLUSTRATION :- 407-010	-	-	Enquire
24	4E0698507	SET OF GASKETS FOR BRAKE CALIPER HOUSING	4E0698507 SET OF GASKETS FOR BRAKE CALIPER HOUSING	-	2	Enquire
