Lamborghini Huracan LP580 Coupe - Electrical System 1

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	4T2941531D	MULTIPLE SWITCH	4T2941531D MULTIPLE SWITCH RHD	-	1	Enquire
001	4T1941531D	MULTIPLE SWITCH	4T1941531D MULTIPLE SWITCH RHD	-	1	Enquire
002	4T0905217A	START/STOP SWITCH	4T0905217A START/STOP SWITCH	-	1	Enquire
003	4T0858197G	TAG FOR KEY NUMBER	4T0858197G TAG FOR KEY NUMBER	-	1	Enquire
003	4T0858197F	TAG FOR KEY NUMBER	4T0858197F TAG FOR KEY NUMBER	-	1	Enquire
004	4T0919657D	TAG FOR KEY NUMBER	4T0919657D TAG FOR KEY NUMBER	-	1	Enquire
005	N90455205	SCREW M4X10	N90455205 SCREW M4X10	-	4	Enquire
006	4T8863347E	MULTIPLE SWITCH - E-GEAR - RM (OPT - HIGH GLOSS BLACK)	4T8863347E MULTIPLE SWITCH - E-GEAR - RM (OPT - HIGH GLOSS BLACK)	-	1	Enquire
006	4T8863347D	MULTIPLE SWITCH - E-GEAR - RM	4T8863347D MULTIPLE SWITCH - E-GEAR - RM	-	1	Enquire
007	4T0927225B	SWITCH FOR ELECTROMECHANICAL PARKING BRAKE -EPB-	4T0927225B SWITCH FOR ELECTROMECHANICAL PARKING BRAKE -EPB-	-	1	Enquire
008	N90944603	OVAL HEXAGON SOCKET HEAD BOLT	N90944603 OVAL HEXAGON SOCKET HEAD BOLT	-	4	Enquire
009	4T0919727A	BRACKET	4T0919727A BRACKET	-	1	Enquire
010	4T0919604B	DISPLAY UNIT FOR MULTIMEDIA INTERFACE MMI	4T0919604B DISPLAY UNIT FOR MULTIMEDIA INTERFACE MMI	-	1	Enquire
010	4T0919604C	DISPLAY UNIT FOR MULTIMEDIA INTERFACE MMI	4T0919604C DISPLAY UNIT FOR MULTIMEDIA INTERFACE MMI	-	1	Enquire
011	4T0919132B	COVER	4T0919132B COVER	-	1	Enquire
012	4T0941567N	MULTIPLE SWITCH	4T0941567N MULTIPLE SWITCH	-	1	Enquire
012	4T0941567M	MULTIPLE SWITCH (REAR VIEW CAMERA - PARK SENSOR)	4T0941567M MULTIPLE SWITCH (REAR VIEW CAMERA - PARK SENSOR)	-	1	Enquire
012	4T0941567AF	MULTIPLE SWITCH (ONLY FOR SOUTH KOREA, BRASIL MARKET)	4T0941567AF MULTIPLE SWITCH (ONLY FOR SOUTH KOREA, BRASIL MARKET)	-	1	Enquire
012	4T0941567AG	MULTIPLE SWITCH (ONLY FOR SOUTH KOREA, BRASIL MARKET)	4T0941567AG MULTIPLE SWITCH (ONLY FOR SOUTH KOREA, BRASIL MARKET)	-	1	Enquire
012	4T0941567CN	SWITCH BRACKET	4T0941567CN SWITCH BRACKET	-	1	Enquire
012	4T0941567Q	MULTIPLE SWITCH (DRIVE SELECT)	4T0941567Q MULTIPLE SWITCH (DRIVE SELECT)	-	1	Enquire
012	4T0941567P	MULTIPLE SWITCH	4T0941567P MULTIPLE SWITCH	-	1	Enquire
012	4T0941567AH	MULTIPLE SWITCH (ONLY FOR SOUTH KOREA, BRASIL MARKET)	4T0941567AH MULTIPLE SWITCH (ONLY FOR SOUTH KOREA, BRASIL MARKET)	-	1	Enquire
013	4T0820043E	DISPLAY AND CONTROL PANEL FOR ELECTRONICALLY CONTROLLED AIR CONDITIONING (WITH HEATED SEATS)	4T0820043E DISPLAY AND CONTROL PANEL FOR ELECTRONICALLY CONTROLLED AIR CONDITIONING (WITH HEATED SEATS)	-	1	Enquire
013	4T0820043L	DISPLAY AND CONTROL PANEL FOR ELECTRONICALLY CONTROLLED	4T0820043L DISPLAY AND CONTROL PANEL FOR ELECTRONICALLY CONTROLLED	-	1	Enquire
013	4T0820043H	DISPLAY AND CONTROL PANEL FOR ELECTRONICALLY CONTROLLED	4T0820043H DISPLAY AND CONTROL PANEL FOR ELECTRONICALLY CONTROLLED	-	1	Enquire
013	4T0820043D	DISPLAY AND CONTROL PANEL FOR ELECTRONICALLY CONTROLLED AIR CONDITIONING (WITHOUT HEATED SEATS)	4T0820043D DISPLAY AND CONTROL PANEL FOR ELECTRONICALLY CONTROLLED AIR CONDITIONING (WITHOUT HEATED SEATS)	-	1	Enquire
014	4T0919609A	OPERATING UNIT FOR MULTIMEDIA SYSTEM -MMI- WITH JOYSTICK (OPT - HIGH GLOSS BLACK)	4T0919609A OPERATING UNIT FOR MULTIMEDIA SYSTEM -MMI- WITH JOYSTICK (OPT - HIGH GLOSS BLACK)	-	1	Enquire
014	4T0919609D	OPERATING DEVICE MMI SWITCH	4T0919609D OPERATING DEVICE MMI SWITCH	-	1	Enquire
015	N10625802	HEXAGON SOCKET FLAT HEAD BOLT	N10625802 HEXAGON SOCKET FLAT HEAD BOLT	-	4	Enquire
016	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD	N10569501 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD	-	4	Enquire
