Electrical System 3 of Lamborghini Lamborghini Huracan LP580 Coupe

View All

Lamborghini Huracan LP580 Coupe - Electrical System 3

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
000	4T0951195	HOSE REINFORCEMENT	4T0951195 HOSE REINFORCEMENT	-	1	Enquire
001	4T8998786	WIRE SET	4T8998786 WIRE SET	-	1	Enquire
002	4T0971095F	WIRING SET FOR FRONT BUMPER (PARKING SENSORS)	4T0971095F WIRING SET FOR FRONT BUMPER (PARKING SENSORS)	-	1	Enquire
002	4T0971095G	WIRING SET FOR FRONT BUMPER (HOMELINK )	4T0971095G WIRING SET FOR FRONT BUMPER (HOMELINK )	-	1	Enquire
002	4T0971095H	WIRING SET FOR FRONT BUMPER (HOMELINK / PARKING SENSORS)	4T0971095H WIRING SET FOR FRONT BUMPER (HOMELINK / PARKING SENSORS)	-	1	Enquire
003	4T0971085	WIRING SET FOR REAR BUMPER (PLATE LIGHTS)	4T0971085 WIRING SET FOR REAR BUMPER (PLATE LIGHTS)	-	1	Enquire
003	4T0971085A	WIRING SET FOR REAR BUMPER (PLATE LIGHTS / PARKING SENSORS)	4T0971085A WIRING SET FOR REAR BUMPER (PLATE LIGHTS / PARKING SENSORS)	-	1	Enquire
003	4T0971085D	WIRING SET FOR REAR BUMPER (PLATE LIGHTS /REAR VIEW CAMERA / PARKING SENSORS)	4T0971085D WIRING SET FOR REAR BUMPER (PLATE LIGHTS /REAR VIEW CAMERA / PARKING SENSORS)	-	1	Enquire
004	N90937701	CABLE TIES	N90937701 CABLE TIES	-	1	Enquire
005	4S0971341J	CABLE GUIDE	4S0971341J CABLE GUIDE	-	1	Enquire
006	8J0959841	FOAM FILLER PIECE	8J0959841 FOAM FILLER PIECE	-	1	Enquire
007	7L971627AD	WIRING HARNESS FOR - INJECTORS - BANK 1 (BANK 1-5) (DIRECT)	7L971627AD WIRING HARNESS FOR - INJECTORS - BANK 1 (BANK 1-5) (DIRECT)	-	1	Enquire
008	7L971627AC	WIRING HARNESS FOR - INJECTORS - BANK 2 (BANK 6-10) (DIRECT)	7L971627AC WIRING HARNESS FOR - INJECTORS - BANK 2 (BANK 6-10) (DIRECT)	-	1	Enquire
009	7L971627AE	WIRING HARNESS FOR INJECTORS	7L971627AE WIRING HARNESS FOR INJECTORS	-	1	Enquire
010	7L971627AF	WIRING HARNESS FOR INJECTORS	7L971627AF WIRING HARNESS FOR INJECTORS	-	1	Enquire
011	420971503A	BRACKET FOR CONNECTOR HOUSING	420971503A BRACKET FOR CONNECTOR HOUSING	-	2	Enquire
011	420971503B	BRACKET FOR CONNECTOR HOUSING	420971503B BRACKET FOR CONNECTOR HOUSING	-	2	Enquire
012	N10196103	OVAL SOCKET HEAD BOLT WITH HEX DRIVE	N10196103 OVAL SOCKET HEAD BOLT WITH HEX DRIVE	-	4	Enquire
013	N90925202	HEXAGON SOCKET HEAD COLLARED BOLT, THREAD FORMING	N90925202 HEXAGON SOCKET HEAD COLLARED BOLT, THREAD FORMING	-	4	Enquire
014	7L971845AR	BRACKET FOR CONNECTOR HOUSING	7L971845AR BRACKET FOR CONNECTOR HOUSING	-	2	Enquire
014	7L971845AQ	BRACKET FOR CONNECTOR HOUSING	7L971845AQ BRACKET FOR CONNECTOR HOUSING	-	2	Enquire
