Name: Oil System - Radiator
Rating: 4.0 (1 reviews)

Oil System - Radiator of Lamborghini Lamborghini Gallardo (2003-2005)

View All

Lamborghini Gallardo (2003-2005) - Oil System - Radiator

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	7L115655	LH PIPE	$31.79	To Order

Photo	Part No	Description	Price (each)	Stock
	N10233401	CLAMP 16.2 X 7 X 0.60	$3.05	To Order

Photo	Part No	Description	Price (each)	Stock
	7L115311C	PLUG	$568.56	To Order

Photo	Part No	Description	Price (each)	Stock
	7L115664C	PIPE	$186.83	To Order

Photo	Part No	Description	Price (each)	Stock
	N90107203	CLAMP 12 X 8.0 X 0.5	$3.77	To Order

Photo	Part No	Description	Price (each)	Stock
	357711798	RUBBER SEAL	$3.51	To Order

Photo	Part No	Description	Price (each)	Stock
	N10005104	SCREW M8X35	$1.43	To Order

Photo	Part No	Description	Price (each)	Stock
	7L115373B	OIL TANK	$4,274.20	To Order

Photo	Part No	Description	Price (each)	Stock
	400115341B	HEAT SHIELD	$137.77	To Order

Photo	Part No	Description	Price (each)	Stock
	N10156305	SCREW M6X12	$1.19	To Order

Photo	Part No	Description	Price (each)	Stock
	7L115333B	RUBBER BUFFER	$11.56	To Order

Photo	Part No	Description	Price (each)	Stock
	N138486	WASHER A16X22	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N160282	OIL DRAINAGE M16X1,5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7L919501A	Water Temperature Sensor	$359.56	To Order

Photo	Part No	Description	Price (each)	Stock
	7L115659G	OIL SUCTION ROSE	$1,040.31	To Order

Photo	Part No	Description	Price (each)	Stock
	7L115689B	PIPE	$725.81	To Order

Photo	Part No	Description	Price (each)	Stock
	N91107101	WASHER	$4.90	To Order

Photo	Part No	Description	Price (each)	Stock
	7L115688B	OILPIPE	$880.39	To Order

Photo	Part No	Description	Price (each)	Stock
	400117335	COOLER EXIT CONE	$1,284.97	To Order

Photo	Part No	Description	Price (each)	Stock
	418864929	PROTECTION	$461.04	To Order

Photo	Part No	Description	Price (each)	Stock
	400117097A	BRACKET	$497.32	To Order

Photo	Part No	Description	Price (each)	Stock
	400317025	LH CONVEYOR	$670.19	To Order

Photo	Part No	Description	Price (each)	Stock
	7L117015B	OIL COOLER	$1,427.33	To Order

Photo	Part No	Description	Price (each)	Stock
	7L133741	SUPPORT	$14.80	To Order

Photo	Part No	Description	Price (each)	Stock
	7L115255	FLANGE	$67.08	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT000759	STUD BOLT (M6X14)	$5.32	To Order

Photo	Part No	Description	Price (each)	Stock
	N10129201	O-RING	$5.14	To Order

Photo	Part No	Description	Price (each)	Stock
	1J0711795	SPACER	$3.77	To Order

Photo	Part No	Description	Price (each)	Stock
	400422095	FAIRLEAD	$48.72	To Order

Photo	Part No	Description	Price (each)	Stock
	7L115333	RUBBER BUFFER	$23.07	To Order

Photo	Part No	Description	Price (each)	Stock
	N90937701	CABLE TIES	$1.55	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
01	400117098A	BRACKET	400117098A BRACKET	$122.05	1
02	N902322	SCREW	N902322 SCREW	-	1	Enquire
03	N90847903	Screw M6X15	N90847903 Screw M6X15	$1.16	4
04	7L117413C	HOSE	7L117413C HOSE	$987.91	1
05	7L115687C	HOSE	7L115687C HOSE	$1,227.16	1
06	N10451405	OVAL HEXAGON SOCKET HEAD BOLT	N10451405 OVAL HEXAGON SOCKET HEAD BOLT	$1.43 MSRP: ~~7.22~~ (80.2% off)	4
07	N90265703	NUT M6X7.6	N90265703 NUT M6X7.6	$9.27	2
08	400115339A	HEAT SHIELD	400115339A HEAT SHIELD	$263.44	1
09	400115707	CONNECTOR	400115707 CONNECTOR	$34.14	1
10	7L115655	LH PIPE	7L115655 LH PIPE	$31.79	1
11	N10233401	CLAMP 16.2 X 7 X 0.60	N10233401 CLAMP 16.2 X 7 X 0.60	$3.05	2
13	7L115311C	PLUG	7L115311C PLUG	$568.56	1
14	7L115664C	PIPE	7L115664C PIPE	$186.83	2
16	N90107203	CLAMP 12 X 8.0 X 0.5	N90107203 CLAMP 12 X 8.0 X 0.5	$3.77	2
17	357711798	RUBBER SEAL	357711798 RUBBER SEAL	$3.51	2
18	N10005104	SCREW M8X35	N10005104 SCREW M8X35	$1.43	2
19	7L115373B	OIL TANK	7L115373B OIL TANK	$4,274.20	1
20	400115341B	HEAT SHIELD	400115341B HEAT SHIELD	$137.77	1
21	N10156305	SCREW M6X12	N10156305 SCREW M6X12	$1.19	6
22	7L115333B	RUBBER BUFFER	7L115333B RUBBER BUFFER	$11.56	1
23	N138486	WASHER A16X22	N138486 WASHER A16X22	-	1	Enquire
24	N160282	OIL DRAINAGE M16X1,5	N160282 OIL DRAINAGE M16X1,5	-	1	Enquire
25	7L919501A	Water Temperature Sensor	7L919501A Water Temperature Sensor	$359.56	1
26	7L115659G	OIL SUCTION ROSE	7L115659G OIL SUCTION ROSE	$1,040.31	1
27	7L115689B	PIPE	7L115689B PIPE	$725.81	1
28	N91107101	WASHER	N91107101 WASHER	$4.90	1
29	7L115688B	OILPIPE	7L115688B OILPIPE	$880.39	1
30	400117335	COOLER EXIT CONE	400117335 COOLER EXIT CONE	$1,284.97	1
31	418864929	PROTECTION	418864929 PROTECTION	$461.04	1
32	400117097A	BRACKET	400117097A BRACKET	$497.32	1
33	400317025	LH CONVEYOR	400317025 LH CONVEYOR	$670.19	1
34	7L117015B	OIL COOLER	7L117015B OIL COOLER	$1,427.33	1
35	7L133741	SUPPORT	7L133741 SUPPORT	$14.80	1
36	7L115255	FLANGE	7L115255 FLANGE	$67.08	1
37	WHT000759	STUD BOLT (M6X14)	WHT000759 STUD BOLT (M6X14)	$5.32	2
38	N10129201	O-RING	N10129201 O-RING	$5.14	1
39	1J0711795	SPACER	1J0711795 SPACER	$3.77	2
40	400422095	FAIRLEAD	400422095 FAIRLEAD	$48.72	1
41	7L115333	RUBBER BUFFER	7L115333 RUBBER BUFFER	$23.07	1
42	N90937701	CABLE TIES	N90937701 CABLE TIES	$1.55 MSRP: ~~2.00~~ (22.5% off)	1
