Exhaust System 2 of Lamborghini Lamborghini Diablo SV (1995-1997)

View All

Lamborghini Diablo SV (1995-1997) - Exhaust System 2

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	R1470005	THERMOCOUPLE KIT	R1470005 THERMOCOUPLE KIT (x2 heat probs & x1 ECU)	-	1	Enquire
002	N02214621	HEXAGON NUT M8 SELF-LOCKING	N02214621 HEXAGON NUT M8 SELF-LOCKING DADO	-	6	Enquire
003	8440806	WASHER	8440806 WASHER use : WHT001185	-	6	Enquire
004	4431146	RIGHT CATALYTIC CON.	4431146 RIGHT CATALYTIC CON. CONVERTITORE CATALITICO DX	-	1	Enquire
005	4432145	GASKET	4432145 GASKET GUARNIZIONE	-	2	Enquire
006	4425084	HALF RING	4425084 HALF RING SEMIANELLO FILETTATO	-	2	Enquire
007	4424070	BI-CONE RING	4424070 BI-CONE RING ANELLO DOPPIO CONO	-	2	Enquire
008	N0444416	STUD BOLT	N0444416 STUD BOLT PRIGIONIERO	-	4	Enquire
009	4425084	HALF RING	4425084 HALF RING SEMIANELLO	-	2	Enquire
010	8440806	WASHER	8440806 WASHER use : WHT001185	-	4	Enquire
011	N02214621	HEXAGON NUT M8 SELF-LOCKING	N02214621 HEXAGON NUT M8 SELF-LOCKING DADO	-	4	Enquire
012	4431147	PLUG	4431147 PLUG TAPPO	-	2	Enquire
013	N91122801	WASHER 18,5X24X1,5	N91122801 WASHER 18,5X24X1,5 RONDELLA	-	2	Enquire
014	4431148	PLUG	4431148 PLUG TAPPO	-	2	Enquire
015	WHT001191	WASHER	WHT001191 WASHER RONDELLA	-	2	Enquire
016	WHT002959	CLAMPING NUT	WHT002959 CLAMPING NUT DADO	-	2	Enquire
017	6033680	ELECTR. CONT. UNIT	6033680 ELECTR. CONT. UNIT CENTRALINA ELETTRONICA	-	1	Enquire
018	4431143	LEFT CATALYTIC CON.	4431143 LEFT CATALYTIC CON. CONVERTITORE CATALITICO SX	-	1	Enquire
019	6033687	THERMOCOUPLE	6033687 THERMOCOUPLE TERMOCOPPIA (L=500 MM)	-	1	Enquire
020	5934453	SHIELD	5934453 SHIELD PROTEZIONE	-	1	Enquire
