Trim Frame Rear Part

Lamborghini Aventador LP780 Ultimae

Illustration Number: 701.03.00

Find Your Part

Lamborghini Aventador LP780 Ultimae - TRIM FRAME REAR PART (701.03.00)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
470813031F FRAME $28,319.79 To Order
Photo Part No Description Price (each) Stock
470813249B CROSS MEMBER $346.79 To Order
Photo Part No Description Price (each) Stock
470814519D CROSS MEMBER $344.08 IN STOCK
Photo Part No Description Price (each) Stock
470814587C CROSS MEMBER $7,967.44 To Order
475814587 CROSS MEMBER $2,755.38 To Order
Photo Part No Description Price (each) Stock
470814657B ARM $58.46 To Order
470814658B ARM $58.46 To Order
Photo Part No Description Price (each) Stock
470814185E ARM Enquire To Order
470814186E ARM Enquire To Order
Photo Part No Description Price (each) Stock
N0195306 BOLT, HEX. HD. WITH SHOULDER, SELF-LOCKING $3.05 IN STOCK
Photo Part No Description Price (each) Stock
N10406504 OVAL HEXAGON SOCKET HEAD BOLT $1.74 IN STOCK
Photo Part No Description Price (each) Stock
N90900401 HEX SOCKET OVAL HEAD COLLARED $1.25 IN STOCK
Photo Part No Description Price (each) Stock
WHT001237 HEX SOCKET HEAD COLLARED BOLT $1.43 IN STOCK
Photo Part No Description Price (each) Stock
N90798805 HEXAGON COLLAR NUT $2.08 IN STOCK
Photo Part No Description Price (each) Stock
N90863802 HEXAGON HEAD BOLT (COMBI) $1.47 IN STOCK
Photo Part No Description Price (each) Stock
470813465B SIDE REINFORCEMENT $56.25 To Order
Photo Part No Description Price (each) Stock
470813466B SIDE REINFORCEMENT $56.25 To Order
Photo Part No Description Price (each) Stock
N10761201 TOOTHED LOCK WASHER $6.20 To Order
Photo Part No Description Price (each) Stock
WHT001942 WASHER $3.30 IN STOCK
Photo Part No Description Price (each) Stock
N90848003 HEX COLLARED BOLT $4.64 To Order
Photo Part No Description Price (each) Stock
N0116945 WASHER $0.82 IN STOCK
Photo Part No Description Price (each) Stock
N91000203 OVAL HEXAGON SOCKET HEAD BOLT $11.56 IN STOCK
View All
TRIM FRAME REAR PART of Lamborghini Lamborghini Aventador LP780 Ultimae Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 470813031F
FRAME
CONTACT YOUR AREA MANAGER-REAR 		$28,319.79 1
2 470813249B
CROSS MEMBER
CONTACT YOUR AREA MANAGER-REAR 		$346.79 2
3 470814519D
CROSS MEMBER
REAR
IN STOCK 		$344.08 1
4 470814587C
CROSS MEMBER
CARBON- CONTACT YOUR AREA MANAGER - PARTICULAR DIMENSION-REAR 		$7,967.44 1
4 475814587
CROSS MEMBER
REAR 		$2,755.38 1
5 470814657B
ARM
LEFT REAR 		$58.46 1
5 470814658B
ARM
RIGHT REAR 		$58.46 1
8 470814185E
ARM
LEFT REAR 		- 1 Enquire
8 470814186E
ARM
LEFT REAR 		- 1 Enquire
9 N0195306
BOLT, HEX. HD. WITH SHOULDER, SELF-LOCKING
M8X25
IN STOCK 		$3.05 (57.3% off) 14
10 N10406504
OVAL HEXAGON SOCKET HEAD BOLT
M6X12
IN STOCK 		$1.74 (75.8% off) 4
11 N90900401
HEX SOCKET OVAL HEAD COLLARED
M6X20
IN STOCK 		$1.25 2
12 WHT001237
HEX SOCKET HEAD COLLARED BOLT
M8X40
IN STOCK 		$1.43 (80% off) 4
13 N90798805
HEXAGON COLLAR NUT
M8
IN STOCK 		$2.08 (71.5% off) 2
14 N90863802
HEXAGON HEAD BOLT (COMBI)
WITH THE READLOCK-M8X25
IN STOCK 		$1.47 (79.6% off) 6
15 470813465B
SIDE REINFORCEMENT
LEFT REAR 		$56.25 1
16 470813466B
SIDE REINFORCEMENT
RIGHT REAR 		$56.25 1
17 N10761201
TOOTHED LOCK WASHER
14X24X30 		$6.20 2
19 WHT001942
WASHER
IN STOCK 		$3.30 2
20 N90848003
HEX COLLARED BOLT
M8X18 		$4.64 2
21 N0116945
WASHER
7X22
IN STOCK 		$0.82 4
22 N91000203
OVAL HEXAGON SOCKET HEAD BOLT
M8X25-H
IN STOCK 		$11.56 4
