Name: DASHBOARD - DUCTS -APPLICABLE FOR RHD-
Rating: 4.7 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	838354	COMPL. DRIVER SIDE RH VENTILATION DUCT	$186.33	To Order

Photo	Part No	Description	Price (each)	Stock
	838370	COMPL. DIFFUSER SURROUND	$200.67	To Order

Photo	Part No	Description	Price (each)	Stock
	852357	COMPL. RH DEMISTER DUCT	$54.46	To Order

Photo	Part No	Description	Price (each)	Stock
	852360	COMPL. LH DEMISTER DUCT	$54.46	To Order

Photo	Part No	Description	Price (each)	Stock
	838376	DRIVER SIDE FOOTWELL DUCT	$60.18	To Order

Photo	Part No	Description	Price (each)	Stock
	892675	COMPL. PASSENGER SIDE LOWER FOOTWELL AIR DUCT	$67.36	To Order

Photo	Part No	Description	Price (each)	Stock
	838358	COMPL. RH PASSENGER SIDE VENTILATION DUCT	$114.66	To Order

Photo	Part No	Description	Price (each)	Stock
	838373	COMPL. LH PASSENGER SIDE VENTILATION DUCT	$172.00	To Order

Photo	Part No	Description	Price (each)	Stock
	805508	CENTRE HVAC/VENTILATION CONNECTOR	$9.45	To Order

Photo	Part No	Description	Price (each)	Stock
	805509	HVAC CONNECTOR GASKET	$10.45	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
0001	838354	COMPL. DRIVER SIDE RH VENTILATION DUCT	838354 COMPL. DRIVER SIDE RH VENTILATION DUCT	$186.33	1
0002	838370	COMPL. DIFFUSER SURROUND	838370 COMPL. DIFFUSER SURROUND	$200.67	1
0003	852357	COMPL. RH DEMISTER DUCT	852357 COMPL. RH DEMISTER DUCT	$54.46	1
0004	852360	COMPL. LH DEMISTER DUCT	852360 COMPL. LH DEMISTER DUCT	$54.46	1
0005	838376	DRIVER SIDE FOOTWELL DUCT	838376 DRIVER SIDE FOOTWELL DUCT	$60.18	1
0006	892675	COMPL. PASSENGER SIDE LOWER FOOTWELL AIR DUCT	892675 COMPL. PASSENGER SIDE LOWER FOOTWELL AIR DUCT	$67.36	1
0007	838358	COMPL. RH PASSENGER SIDE VENTILATION DUCT	838358 COMPL. RH PASSENGER SIDE VENTILATION DUCT	$114.66	1
0008	838373	COMPL. LH PASSENGER SIDE VENTILATION DUCT	838373 COMPL. LH PASSENGER SIDE VENTILATION DUCT	$172.00	1
0009	805508	CENTRE HVAC/VENTILATION CONNECTOR	805508 CENTRE HVAC/VENTILATION CONNECTOR	$9.45	1
0010	805509	HVAC CONNECTOR GASKET	805509 HVAC CONNECTOR GASKET	$10.45	1
