DASHBOARD - SUBSTRUCTURE -NOT FOR RHD- of Ferrari Ferrari SF90 Spider Europe

View All

Ferrari SF90 Spider Europe - DASHBOARD - SUBSTRUCTURE -NOT FOR RHD-

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	939583	DASHBOARD CROSS MEMBER	$3,688.27	To Order
	911905	DASHBOARD CROSS MEMBER	$3,890.39	To Order

Photo	Part No	Description	Price (each)	Stock
	827521	RH RELAY MOUNTING BRACKET	$22.92	To Order

Photo	Part No	Description	Price (each)	Stock
	852358	RH DEMISTER DUCT BRACKET	$42.98	To Order

Photo	Part No	Description	Price (each)	Stock
	852361	LH DEMISTER DUCT BRACKET	$42.98	To Order

Photo	Part No	Description	Price (each)	Stock
	808174	NIT FASTENER BRACKET	$64.49	To Order
	911518	NIT FASTENER BRACKET	$229.33	To Order

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	971988	CENTRE MOUNTING BRACKET	$186.33	To Order

Photo	Part No	Description	Price (each)	Stock
	791384	BRACKET FASTENING EXTRUSION TO TUNNEL	$103.20	To Order
	791385	BRACKET FASTENING EXTRUSION TO TUNNEL	$98.89	To Order

Photo	Part No	Description	Price (each)	Stock
	805424	BODY COMPUTER BRACKET	$114.66	To Order
	946429	BODY COMPUTER BRACKET	$120.39	To Order
	911514	BODY COMPUTER BRACKET	$140.46	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	806632	DRIVER SIDE UNDERDASHBOARD TRIM BRACKET	$88.85	To Order
	946445	DRIVER SIDE UNDERDASHBOARD TRIM BRACKET	$96.02	To Order
	911511	DRIVER SIDE UNDERDASHBOARD TRIM BRACKET	$229.33	To Order

Photo	Part No	Description	Price (each)	Stock
	837920	LOWER BRACKET FOR STEERING COLUMN TRIM	$98.89	To Order
	837920	LOWER BRACKET FOR STEERING COLUMN TRIM	$98.89	To Order
	86592000	LOWER BRACKET FOR LOWER STEERING COLUMN TRIM	$54.46	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	86431600	UPPER BRACKET FOR LOWER STEERING COLUMN TRIM	$15.07	To Order
	830574	UPPER BRACKET FOR LOWER STEERING COLUMN TRIM	$22.92	To Order

Photo	Part No	Description	Price (each)	Stock
	837930	UPPER STEERING COLUMN TRIM BRACKET	$14.31	To Order
	837930	UPPER STEERING COLUMN TRIM BRACKET	$14.31	To Order

Photo	Part No	Description	Price (each)	Stock
	805519	BRACKET	$133.17	To Order

Photo	Part No	Description	Price (each)	Stock
	852386	LH MOUNT BRACKET	$100.33	To Order
	911512	LH MOUNT BRACKET	$94.59	To Order

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	827518	RH DASHBOARD MOUNTING BRACKET	$21.48	To Order

Photo	Part No	Description	Price (each)	Stock
	913351	LH DASHBOARD MOUNTING BRACKET	$25.79	To Order

Photo	Part No	Description	Price (each)	Stock
	821382	BRACKET	$57.33	To Order

Photo	Part No	Description	Price (each)	Stock
	82118300	SCREW -No longer supplied- -Replaced by 11625714-	$0.57	To Order

Photo	Part No	Description	Price (each)	Stock
	805434	COMPL. DASHBOARD SUBSTRUCTURE	$1,553.85	To Order

Photo	Part No	Description	Price (each)	Stock
	835864	HAPTIC CONTROL MOUNTING BRACKET	$34.38	To Order

Photo	Part No	Description	Price (each)	Stock
	819965	BRACKET FASTENING RH SATELLITE TO CHASSIS	$11.59	To Order

Photo	Part No	Description	Price (each)	Stock
	819964	BRACKET FASTENING LH SATELLITE TO CHASSIS	$8.17	To Order

Photo	Part No	Description	Price (each)	Stock
	862953	RH LATERAL TRIM FASTENER BRACKET	$11.59	To Order

Photo	Part No	Description	Price (each)	Stock
	862952	LH LATERAL TRIM FASTENER BRACKET	$11.59	To Order

Photo	Part No	Description	Price (each)	Stock
	795930	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	919017	DRIVER SIDE CASTING FASTENER BRACKET	$14.31	To Order

Photo	Part No	Description	Price (each)	Stock
	88822200	SCREW	$0.70	To Order

Photo	Part No	Description	Price (each)	Stock
	67681200	GASKET	$4.10	To Order

Photo	Part No	Description	Price (each)	Stock
	904454	GLOVE COMPARTMENT REINFORCEMENT BRACKET	$172.00	To Order

Photo	Part No	Description	Price (each)	Stock
	938125	REINFORCEMENT	$186.33	To Order

Photo	Part No	Description	Price (each)	Stock
	904457	PASSENGER SIDE BRACKET	$401.34	To Order

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	911517	DOOR BACKING BRACKET	$77.39	To Order

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	88831000	GRUB SCREW M5 X 40	$0.57	To Order

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	88822200	SCREW	$0.70	To Order

Photo	Part No	Description	Price (each)	Stock
	946096	MYFERRARI CONNECT ECU BRACKET	$37.25	To Order
	902624	MYFERRARI CONNECT ECU BRACKET	Enquire	To Order
	946096	MYFERRARI CONNECT ECU BRACKET	$37.25	To Order

...and 3 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	85833900	SCREW	$0.36	ARRIVING SOON
	85833900	SCREW	$0.36	ARRIVING SOON
	85833900	SCREW	$0.36	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	88822200	SCREW	$0.70	To Order
	88822200	SCREW	$0.70	To Order
	88822200	SCREW	$0.70	To Order

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	939583	DASHBOARD CROSS MEMBER	939583 DASHBOARD CROSS MEMBER	$3,688.27	1
0001	911905	DASHBOARD CROSS MEMBER	911905 DASHBOARD CROSS MEMBER	$3,890.39	1
0002	827521	RH RELAY MOUNTING BRACKET	827521 RH RELAY MOUNTING BRACKET	$22.92	1
0003	852358	RH DEMISTER DUCT BRACKET	852358 RH DEMISTER DUCT BRACKET	$42.98	1
0004	852361	LH DEMISTER DUCT BRACKET	852361 LH DEMISTER DUCT BRACKET	$42.98	1
0005	808174	NIT FASTENER BRACKET	808174 NIT FASTENER BRACKET	$64.49	1
0005	911518	NIT FASTENER BRACKET	911518 NIT FASTENER BRACKET	$229.33	1
0006	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 16 ARRIVING SOON	$0.36	8
0007	971988	CENTRE MOUNTING BRACKET	971988 CENTRE MOUNTING BRACKET	$186.33	1
0008	791384	BRACKET FASTENING EXTRUSION TO TUNNEL	791384 BRACKET FASTENING EXTRUSION TO TUNNEL	$103.20	1
0008	791385	BRACKET FASTENING EXTRUSION TO TUNNEL	791385 BRACKET FASTENING EXTRUSION TO TUNNEL	$98.89	1
0009	805424	BODY COMPUTER BRACKET	805424 BODY COMPUTER BRACKET	$114.66	1
0009	946429	BODY COMPUTER BRACKET	946429 BODY COMPUTER BRACKET Version with MyFerrari Connect Hardware Readiness	$120.39	1
0009	911514	BODY COMPUTER BRACKET	911514 BODY COMPUTER BRACKET	$140.46	1
0009	946429	BODY COMPUTER BRACKET	946429 BODY COMPUTER BRACKET	$120.39	1
0010	806632	DRIVER SIDE UNDERDASHBOARD TRIM BRACKET	806632 DRIVER SIDE UNDERDASHBOARD TRIM BRACKET	$88.85	1
0010	946445	DRIVER SIDE UNDERDASHBOARD TRIM BRACKET	946445 DRIVER SIDE UNDERDASHBOARD TRIM BRACKET	$96.02	1
0010	911511	DRIVER SIDE UNDERDASHBOARD TRIM BRACKET	911511 DRIVER SIDE UNDERDASHBOARD TRIM BRACKET	$229.33	1
0011	837920	LOWER BRACKET FOR STEERING COLUMN TRIM	837920 LOWER BRACKET FOR STEERING COLUMN TRIM	$98.89	1
0011	837920	LOWER BRACKET FOR STEERING COLUMN TRIM	837920 LOWER BRACKET FOR STEERING COLUMN TRIM	$98.89	1
0011	86592000	LOWER BRACKET FOR LOWER STEERING COLUMN TRIM	86592000 LOWER BRACKET FOR LOWER STEERING COLUMN TRIM Applicable for full electric seats	$54.46	1
0011	86592000	LOWER BRACKET FOR LOWER STEERING COLUMN TRIM	86592000 LOWER BRACKET FOR LOWER STEERING COLUMN TRIM	$54.46	1
0012	86431600	UPPER BRACKET FOR LOWER STEERING COLUMN TRIM	86431600 UPPER BRACKET FOR LOWER STEERING COLUMN TRIM	$15.07	1
0012	830574	UPPER BRACKET FOR LOWER STEERING COLUMN TRIM	830574 UPPER BRACKET FOR LOWER STEERING COLUMN TRIM	$22.92	1
0013	837930	UPPER STEERING COLUMN TRIM BRACKET	837930 UPPER STEERING COLUMN TRIM BRACKET Applicable for full electric seats	$14.31	1
0013	837930	UPPER STEERING COLUMN TRIM BRACKET	837930 UPPER STEERING COLUMN TRIM BRACKET	$14.31	1
0014	805519	BRACKET	805519 BRACKET	$133.17	1
0015	852386	LH MOUNT BRACKET	852386 LH MOUNT BRACKET	$100.33	1
0015	911512	LH MOUNT BRACKET	911512 LH MOUNT BRACKET	$94.59	1
0016	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 12 ARRIVING SOON	$0.36	3
0017	827518	RH DASHBOARD MOUNTING BRACKET	827518 RH DASHBOARD MOUNTING BRACKET	$21.48	1
0018	913351	LH DASHBOARD MOUNTING BRACKET	913351 LH DASHBOARD MOUNTING BRACKET	$25.79	1
0019	821382	BRACKET	821382 BRACKET	$57.33	1
0020	82118300	SCREW -No longer supplied- -Replaced by 11625714-	82118300 SCREW -No longer supplied- -Replaced by 11625714- M6 X 16	$0.57	1
0021	805434	COMPL. DASHBOARD SUBSTRUCTURE	805434 COMPL. DASHBOARD SUBSTRUCTURE	$1,553.85	1
0022	835864	HAPTIC CONTROL MOUNTING BRACKET	835864 HAPTIC CONTROL MOUNTING BRACKET	$34.38	2
0023	819965	BRACKET FASTENING RH SATELLITE TO CHASSIS	819965 BRACKET FASTENING RH SATELLITE TO CHASSIS	$11.59	1
0024	819964	BRACKET FASTENING LH SATELLITE TO CHASSIS	819964 BRACKET FASTENING LH SATELLITE TO CHASSIS	$8.17	1
0025	862953	RH LATERAL TRIM FASTENER BRACKET	862953 RH LATERAL TRIM FASTENER BRACKET Not for version in carbon fibre	$11.59	1
0026	862952	LH LATERAL TRIM FASTENER BRACKET	862952 LH LATERAL TRIM FASTENER BRACKET Not for version in carbon fibre	$11.59	1
0027	795930	SCREW	795930 SCREW M4 X 8	-	4	Enquire
0028	919017	DRIVER SIDE CASTING FASTENER BRACKET	919017 DRIVER SIDE CASTING FASTENER BRACKET Not for version in carbon fibre	$14.31	1
0029	88822200	SCREW	88822200 SCREW Version with MyFerrari Connect Hardware Readiness; M4 X 10	$0.70	2
0030	67681200	GASKET	67681200 GASKET	$4.10	1
0031	904454	GLOVE COMPARTMENT REINFORCEMENT BRACKET	904454 GLOVE COMPARTMENT REINFORCEMENT BRACKET Applicable for Assetto Fiorano FIO1/FIO2	$172.00	1
0032	938125	REINFORCEMENT	938125 REINFORCEMENT Applicable for Assetto Fiorano FIO1/FIO2	$186.33	1
0033	904457	PASSENGER SIDE BRACKET	904457 PASSENGER SIDE BRACKET	$401.34	1
0034	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 16 ARRIVING SOON	$0.36	6
0035	911517	DOOR BACKING BRACKET	911517 DOOR BACKING BRACKET	$77.39	1
0036	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 16 ARRIVING SOON	$0.36	1
0037	88831000	GRUB SCREW M5 X 40	88831000 GRUB SCREW M5 X 40 M5 X 25	$0.57	1
0038	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 16 ARRIVING SOON	$0.36	4
0039	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 16 ARRIVING SOON	$0.36	2
0040	88822200	SCREW	88822200 SCREW 3.5 X 13	$0.70	2
0041	946096	MYFERRARI CONNECT ECU BRACKET	946096 MYFERRARI CONNECT ECU BRACKET Version with MyFerrari Connect Hardware Readiness; Applies until depletion	$37.25	1
0041	902624	MYFERRARI CONNECT ECU BRACKET	902624 MYFERRARI CONNECT ECU BRACKET Version with MyFerrari Connect Hardware Readiness; Applicable after depletion of 946096	-	1	Enquire
0041	946096	MYFERRARI CONNECT ECU BRACKET	946096 MYFERRARI CONNECT ECU BRACKET	$37.25	1
0041	902624	MYFERRARI CONNECT ECU BRACKET	902624 MYFERRARI CONNECT ECU BRACKET	-	1	Enquire
0041	946096	MYFERRARI CONNECT ECU BRACKET	946096 MYFERRARI CONNECT ECU BRACKET	$37.25	1
0041	902624	MYFERRARI CONNECT ECU BRACKET	902624 MYFERRARI CONNECT ECU BRACKET	-	1	Enquire
0042	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 12 ARRIVING SOON	$0.36	2
0042	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 12 ARRIVING SOON	$0.36	2
0042	85833900	SCREW ARRIVING SOON	85833900 SCREW M5 X 12 ARRIVING SOON	$0.36	2
0043	88822200	SCREW	88822200 SCREW M4 X 10	$0.70	2
0043	88822200	SCREW	88822200 SCREW M4 X 10	$0.70	2
0043	88822200	SCREW	88822200 SCREW M4 X 10	$0.70	2
