INTERCOOLER of Ferrari Ferrari Portofino USA

View All

Ferrari Portofino USA - INTERCOOLER

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	340704	RH INTERCOOLER	Enquire	To Order
	340705	LH INTERCOOLER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	340923	RH INTAKE DUCT CONNECTOR	Enquire	To Order
	340924	LH INTAKE DUCT CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	974284	TURBO INLET DUCT HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	900284	SCREW COLLAR	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	257273	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	327860	COMPL. RH ANCILLARIES PIPE	Enquire	To Order
	342016	COMPL. LH ANCILLARIES PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	285553	VIBRATION DAMPER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14040614	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	308759	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	785338	RH COMPRESSOR FLANGED INTAKE PIPE	Enquire	To Order
	785339	LH COMPRESSOR FLANGED INTAKE PIPE,	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	330933	COMPRESSOR INTAKE GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	813619	RH COMPRESSOR FLANGED OUTLET PIPE	Enquire	To Order
	813620	LH COMPRESSOR FLANGED OUTLET PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	308862	COMPRESSOR OUTLET GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	332707	INTERCOOLER INLET HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	339351	RH PIPE FROM ENGINE TO INTERCOOLER	Enquire	To Order
	339352	LH PIPE FROM ENGINE TO INTERCOOLER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	813624	HOSE CONNECTION FROM TURBO TO INTERCOOLER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	297483	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	780895	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	290938	INTERCOOLER FASTENER RUBBER BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66121400	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	338492	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	782582	BUSH - INTERCOOLER SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	327937	RH INTERCOOLER OUTLET HOSE	Enquire	To Order
	327938	LH INTERCOOLER OUTLET HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	786970	INTERMEDIATE PIPE BETWEEN INTERCOOLER AND THROTTLE BODY HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	272880	PRESSURE AND TEMPERATURE SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	311609	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	328619	THROTTLE BODY CONNECTOR HOSE UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	908630	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	747660	PIPE FROM INTAKE TO RH VENTURI	Enquire	To Order
	747661	PIPE FROM INTAKE TO LH VENTURI	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	330230	PIPE FROM ENGINE TO RH VENTURI	Enquire	To Order
	330231	PIPE FROM ENGINE TO LH VENTURI	Enquire	To Order
	813216	PIPE FROM ENGINE TO LH VENTURI	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	332708	COMPL. RH THROTTLE BODY COLLAR HOSE UNION	Enquire	To Order
	332709	COMPL. LH THROTTLE BODY COLLAR HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	113113	WASHER	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	340704	RH INTERCOOLER	340704 RH INTERCOOLER	-	1	Enquire
0001	340705	LH INTERCOOLER	340705 LH INTERCOOLER	-	1	Enquire
0002	340923	RH INTAKE DUCT CONNECTOR	340923 RH INTAKE DUCT CONNECTOR	-	1	Enquire
0002	340924	LH INTAKE DUCT CONNECTOR	340924 LH INTAKE DUCT CONNECTOR	-	1	Enquire
0003	974284	TURBO INLET DUCT HOSE	974284 TURBO INLET DUCT HOSE	-	2	Enquire
0004	900284	SCREW COLLAR ARRIVING SOON	900284 SCREW COLLAR ARRIVING SOON	-	4	Enquire
0005	257273	CLIP	257273 CLIP	-	2	Enquire
0006	327860	COMPL. RH ANCILLARIES PIPE	327860 COMPL. RH ANCILLARIES PIPE	-	1	Enquire
0006	342016	COMPL. LH ANCILLARIES PIPE	342016 COMPL. LH ANCILLARIES PIPE	-	1	Enquire
0007	285553	VIBRATION DAMPER	285553 VIBRATION DAMPER	-	6	Enquire
0008	14040614	NUT	14040614 NUT	-	6	Enquire
0009	308759	COLLAR	308759 COLLAR	-	2	Enquire
0010	785338	RH COMPRESSOR FLANGED INTAKE PIPE	785338 RH COMPRESSOR FLANGED INTAKE PIPE	-	1	Enquire
0010	785339	LH COMPRESSOR FLANGED INTAKE PIPE,	785339 LH COMPRESSOR FLANGED INTAKE PIPE,	-	1	Enquire
0011	330933	COMPRESSOR INTAKE GASKET	330933 COMPRESSOR INTAKE GASKET	-	2	Enquire
0012	813619	RH COMPRESSOR FLANGED OUTLET PIPE	813619 RH COMPRESSOR FLANGED OUTLET PIPE	-	1	Enquire
0012	813620	LH COMPRESSOR FLANGED OUTLET PIPE	813620 LH COMPRESSOR FLANGED OUTLET PIPE	-	1	Enquire
0013	308862	COMPRESSOR OUTLET GASKET	308862 COMPRESSOR OUTLET GASKET	-	2	Enquire
0014	231620	SCREW	231620 SCREW M6 X 25	-	8	Enquire
0015	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM M6 X 14	-	2	Enquire
0016	332707	INTERCOOLER INLET HOSE	332707 INTERCOOLER INLET HOSE	-	1	Enquire
0017	339351	RH PIPE FROM ENGINE TO INTERCOOLER	339351 RH PIPE FROM ENGINE TO INTERCOOLER	-	1	Enquire
0017	339352	LH PIPE FROM ENGINE TO INTERCOOLER	339352 LH PIPE FROM ENGINE TO INTERCOOLER	-	1	Enquire
0018	813624	HOSE CONNECTION FROM TURBO TO INTERCOOLER	813624 HOSE CONNECTION FROM TURBO TO INTERCOOLER	-	1	Enquire
0019	297483	COLLAR	297483 COLLAR	-	6	Enquire
0020	780895	COLLAR	780895 COLLAR	-	6	Enquire
0021	290938	INTERCOOLER FASTENER RUBBER BUSH	290938 INTERCOOLER FASTENER RUBBER BUSH	-	2	Enquire
0022	66121400	WASHER	66121400 WASHER	-	2	Enquire
0023	338492	SPACER	338492 SPACER	-	2	Enquire
0024	782582	BUSH - INTERCOOLER SUPPORT	782582 BUSH - INTERCOOLER SUPPORT	-	4	Enquire
0025	327937	RH INTERCOOLER OUTLET HOSE	327937 RH INTERCOOLER OUTLET HOSE	-	1	Enquire
0025	327938	LH INTERCOOLER OUTLET HOSE	327938 LH INTERCOOLER OUTLET HOSE	-	1	Enquire
0026	786970	INTERMEDIATE PIPE BETWEEN INTERCOOLER AND THROTTLE BODY HOSE	786970 INTERMEDIATE PIPE BETWEEN INTERCOOLER AND THROTTLE BODY HOSE	-	2	Enquire
0027	272880	PRESSURE AND TEMPERATURE SENSOR	272880 PRESSURE AND TEMPERATURE SENSOR	-	2	Enquire
0028	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 18	-	4	Enquire
0029	311609	COLLAR	311609 COLLAR	-	2	Enquire
0030	328619	THROTTLE BODY CONNECTOR HOSE UNION	328619 THROTTLE BODY CONNECTOR HOSE UNION No longer supplied	-	2	Enquire
0031	908630	COLLAR	908630 COLLAR	-	2	Enquire
0032	747660	PIPE FROM INTAKE TO RH VENTURI	747660 PIPE FROM INTAKE TO RH VENTURI	-	1	Enquire
0032	747661	PIPE FROM INTAKE TO LH VENTURI	747661 PIPE FROM INTAKE TO LH VENTURI	-	1	Enquire
0033	330230	PIPE FROM ENGINE TO RH VENTURI	330230 PIPE FROM ENGINE TO RH VENTURI	-	1	Enquire
0033	330231	PIPE FROM ENGINE TO LH VENTURI	330231 PIPE FROM ENGINE TO LH VENTURI	-	1	Enquire
0033	813216	PIPE FROM ENGINE TO LH VENTURI	813216 PIPE FROM ENGINE TO LH VENTURI	-	1	Enquire
0034	332708	COMPL. RH THROTTLE BODY COLLAR HOSE UNION	332708 COMPL. RH THROTTLE BODY COLLAR HOSE UNION	-	1	Enquire
0034	332709	COMPL. LH THROTTLE BODY COLLAR HOSE	332709 COMPL. LH THROTTLE BODY COLLAR HOSE	-	1	Enquire
0035	113113	WASHER	113113 WASHER D. 6.45-16 X 2	-	2	Enquire
