REAR SUSPENSION - CALLIPERS AND DISCS of Ferrari Ferrari Portofino Europe

View All

Ferrari Portofino Europe - REAR SUSPENSION - CALLIPERS AND DISCS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	335650	RH REAR CALIPER WITH PADS	Enquire	To Order
	829930	RH REAR CALIPER WITH PADS	Enquire	To Order
	342739	RH REAR CALIPER WITH PADS	Enquire	To Order

...and 33 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	338392	RH REAR DISC SHIELD	Enquire	To Order
	338391	LH REAR DISC SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	977797	HOSE	Enquire	To Order
	977797	HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	338393	BRAKE DISC	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228132	SPRING WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	195167	SCREW M12 X 1.5 X 95	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228131	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104370	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	338397	COMPL. BRAKE PIPE FROM CALLIPER TO RH HOSE	Enquire	To Order
	338396	COMPL. BRAKE PIPE FROM CALLIPER TO LH HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	116374	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	339252	COMPL. RH PARKING BRAKE CALLIPER	Enquire	To Order
	339251	COMPL. LH PARKING BRAKE CALLIPER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	338792	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004286	REAR PAD SET WITH SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	303385	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	310942	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004343	SET OF EPB PADS	Enquire	To Order
	70006840	SET OF EPB PADS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004365	LH EPB CALLIPER BODY	Enquire	To Order
	70004366	RH EPB CALLIPER BODY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004367	EPB GUIDE SPARE PARTS KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004368	GEAR MOTOR SPARE PARTS KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004369	RUBBER SPARE PARTS KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004370	O-RING AND SCREW KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	70004901	REAR DUST GAITER KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	215665	BLEED SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	215666	PROTECTIVE CAP	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	335650	RH REAR CALIPER WITH PADS	335650 RH REAR CALIPER WITH PADS No longer supplied - Replaced by 829930; Anodised black	-	1	Enquire
0001	829930	RH REAR CALIPER WITH PADS	829930 RH REAR CALIPER WITH PADS Anodised black	-	1	Enquire
0001	342739	RH REAR CALIPER WITH PADS	342739 RH REAR CALIPER WITH PADS No longer supplied - Replaced by 829931; Black	-	1	Enquire
0001	829931	RH REAR CALIPER WITH PADS	829931 RH REAR CALIPER WITH PADS Black	-	1	Enquire
0001	342741	RH REAR CALIPER WITH PADS	342741 RH REAR CALIPER WITH PADS No longer supplied - Replaced by 829922; Red	-	1	Enquire
0001	829922	RH REAR CALIPER WITH PADS	829922 RH REAR CALIPER WITH PADS Red	-	1	Enquire
0001	342743	RH REAR CALIPER WITH PADS	342743 RH REAR CALIPER WITH PADS No longer supplied - Replaced by 829923; Silver	-	1	Enquire
0001	829923	RH REAR CALIPER WITH PADS	829923 RH REAR CALIPER WITH PADS Silver	-	1	Enquire
0001	342745	RH REAR CALIPER WITH PADS	342745 RH REAR CALIPER WITH PADS No longer supplied - Replaced by 829924; Yellow	-	1	Enquire
0001	829924	RH REAR CALIPER WITH PADS	829924 RH REAR CALIPER WITH PADS Yellow	-	1	Enquire
0001	342747	RH REAR CALIPER WITH PADS	342747 RH REAR CALIPER WITH PADS No longer supplied - Replaced by 829925; Scuderia red	-	1	Enquire
0001	829925	RH REAR CALIPER WITH PADS	829925 RH REAR CALIPER WITH PADS Scuderia red	-	1	Enquire
0001	342749	RH REAR CALIPER WITH PADS	342749 RH REAR CALIPER WITH PADS No longer supplied - Replaced by 829926; Dark grey	-	1	Enquire
0001	829926	RH REAR CALIPER WITH PADS	829926 RH REAR CALIPER WITH PADS Dark grey	-	1	Enquire
0001	342751	RH REAR CALIPER WITH PADS	342751 RH REAR CALIPER WITH PADS No longer supplied - Replaced by 829927; Gold	-	1	Enquire
0001	829927	RH REAR CALIPER WITH PADS	829927 RH REAR CALIPER WITH PADS Gold	-	1	Enquire
0001	342753	RH REAR CALIPER WITH PADS	342753 RH REAR CALIPER WITH PADS No longer supplied - Replaced by 829928; Blue	-	1	Enquire
0001	829928	RH REAR CALIPER WITH PADS	829928 RH REAR CALIPER WITH PADS Blue	-	1	Enquire
0001	335649	LH REAR CALIPER WITH PADS	335649 LH REAR CALIPER WITH PADS No longer supplied - Replaced by 829677; Anodised black	-	1	Enquire
0001	829677	LH REAR CALIPER WITH PADS	829677 LH REAR CALIPER WITH PADS Anodised black	-	1	Enquire
0001	342738	LH REAR CALIPER WITH PADS	342738 LH REAR CALIPER WITH PADS No longer supplied - Replaced by 829878; Black	-	1	Enquire
0001	829878	LH REAR CALIPER WITH PADS	829878 LH REAR CALIPER WITH PADS Black	-	1	Enquire
0001	342740	LH REAR CALIPER WITH PADS	342740 LH REAR CALIPER WITH PADS No longer supplied - Replaced by 829882; Red	-	1	Enquire
0001	829882	LH REAR CALIPER WITH PADS	829882 LH REAR CALIPER WITH PADS Red	-	1	Enquire
0001	342742	LH REAR CALIPER WITH PADS	342742 LH REAR CALIPER WITH PADS No longer supplied - Replaced by 829885; Silver	-	1	Enquire
0001	829885	LH REAR CALIPER WITH PADS	829885 LH REAR CALIPER WITH PADS Silver	-	1	Enquire
0001	342744	LH REAR CALIPER WITH PADS	342744 LH REAR CALIPER WITH PADS No longer supplied - Replaced by 829886; Yellow	-	1	Enquire
0001	829886	LH REAR CALIPER WITH PADS	829886 LH REAR CALIPER WITH PADS Yellow	-	1	Enquire
0001	342746	LH REAR CALIPER WITH PADS	342746 LH REAR CALIPER WITH PADS No longer supplied - Replaced by 829888; Scuderia red	-	1	Enquire
0001	829888	LH REAR CALIPER WITH PADS	829888 LH REAR CALIPER WITH PADS Scuderia red	-	1	Enquire
0001	342748	LH REAR CALIPER WITH PADS	342748 LH REAR CALIPER WITH PADS No longer supplied - Replaced by 829889; Dark grey	-	1	Enquire
0001	829889	LH REAR CALIPER WITH PADS	829889 LH REAR CALIPER WITH PADS Dark grey	-	1	Enquire
0001	342750	LH REAR CALIPER WITH PADS	342750 LH REAR CALIPER WITH PADS No longer supplied - Replaced by 829891; Gold	-	1	Enquire
0001	829891	LH REAR CALIPER WITH PADS	829891 LH REAR CALIPER WITH PADS Gold	-	1	Enquire
0001	342752	LH REAR CALIPER WITH PADS	342752 LH REAR CALIPER WITH PADS No longer supplied - Replaced by 829893; Blue	-	1	Enquire
0001	829893	LH REAR CALIPER WITH PADS	829893 LH REAR CALIPER WITH PADS Blue	-	1	Enquire
0002	338392	RH REAR DISC SHIELD	338392 RH REAR DISC SHIELD	-	1	Enquire
0002	338391	LH REAR DISC SHIELD	338391 LH REAR DISC SHIELD	-	1	Enquire
0003	977797	HOSE	977797 HOSE Replace as a pair	-	2	Enquire
0003	977797	HOSE	977797 HOSE	-	2	Enquire
0004	338393	BRAKE DISC	338393 BRAKE DISC	-	2	Enquire
0005	228132	SPRING WASHER	228132 SPRING WASHER	-	4	Enquire
0006	195167	SCREW M12 X 1.5 X 95	195167 SCREW M12 X 1.5 X 95 M12 X 1.5 X 105	-	4	Enquire
0007	228131	SCREW	228131 SCREW M8 X 20	-	2	Enquire
0008	104370	SCREW	104370 SCREW	-	2	Enquire
0009	338397	COMPL. BRAKE PIPE FROM CALLIPER TO RH HOSE	338397 COMPL. BRAKE PIPE FROM CALLIPER TO RH HOSE	-	1	Enquire
0009	338396	COMPL. BRAKE PIPE FROM CALLIPER TO LH HOSE	338396 COMPL. BRAKE PIPE FROM CALLIPER TO LH HOSE	-	1	Enquire
0010	116374	CLIP	116374 CLIP	-	4	Enquire
0011	339252	COMPL. RH PARKING BRAKE CALLIPER	339252 COMPL. RH PARKING BRAKE CALLIPER	-	1	Enquire
0011	339251	COMPL. LH PARKING BRAKE CALLIPER	339251 COMPL. LH PARKING BRAKE CALLIPER	-	1	Enquire
0012	338792	SCREW	338792 SCREW M10 X 1.5 X 90	-	4	Enquire
0013	70004286	REAR PAD SET WITH SPRING	70004286 REAR PAD SET WITH SPRING	-	1	Enquire
0014	303385	CLIP	303385 CLIP	-	2	Enquire
0015	310942	CLIP	310942 CLIP 3 compartments	-	4	Enquire
0016	70004343	SET OF EPB PADS	70004343 SET OF EPB PADS For 2 callipers - Contains pads, spring, pins and split pins; Applies until depletion	-	1	Enquire
0016	70006840	SET OF EPB PADS	70006840 SET OF EPB PADS Applicable after depletion of 70004343; For 2 callipers- -Includes pads, springs, pins and split pins	-	1	Enquire
0017	70004365	LH EPB CALLIPER BODY	70004365 LH EPB CALLIPER BODY Also contains fastener hardware for gear motor, O-rings and grease	-	1	Enquire
0017	70004366	RH EPB CALLIPER BODY	70004366 RH EPB CALLIPER BODY Also contains fastener hardware for gear motor, O-rings and grease	-	1	Enquire
0018	70004367	EPB GUIDE SPARE PARTS KIT	70004367 EPB GUIDE SPARE PARTS KIT For 1 calliper- -Includes guides and gaiters	-	2	Enquire
0019	70004368	GEAR MOTOR SPARE PARTS KIT	70004368 GEAR MOTOR SPARE PARTS KIT For 1 calliper- -Includes gear motor complete with respective fastener hardware, O-rings and grease	-	2	Enquire
0020	70004369	RUBBER SPARE PARTS KIT	70004369 RUBBER SPARE PARTS KIT For 1 calliper- -Includes gaiters and piston cap, does not include piston gasket and gear motor O-rings	-	2	Enquire
0021	70004370	O-RING AND SCREW KIT	70004370 O-RING AND SCREW KIT Contains O-rings, screws and grease only	-	1	Enquire
0022	70004901	REAR DUST GAITER KIT	70004901 REAR DUST GAITER KIT	-	1	Enquire
0023	215665	BLEED SCREW	215665 BLEED SCREW	-	4	Enquire
0024	215666	PROTECTIVE CAP	215666 PROTECTIVE CAP	-	4	Enquire
