Find Your Part

CLUTCH HOUSING of Ferrari Ferrari Portofino M USA

View All

Ferrari Portofino M USA - CLUTCH HOUSING

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	866551	COMPL. TRANSMISSION HOUSING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	338192	CLUTCH HOUSING SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	318975	SNAP RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	252524	COMPL. BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	253627	RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11062474	SNAP RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	342924	TRANSMISSION HOUSING FLANGE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14306624	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12602479	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059421	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102704	ALIGNMENT DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13543124	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14306731	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14499421	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	341028	BUSH TRAVEL LIMITER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	18754324	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	269664	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	786862	TRANSMISSION HOUSING BUSHING SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	747853	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638124	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059114	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	329287	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	255271	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	854453	BUSHING TRAVEL STOP BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13028734	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	866551	COMPL. TRANSMISSION HOUSING	866551 COMPL. TRANSMISSION HOUSING	-	1	Enquire
0002	338192	CLUTCH HOUSING SHAFT	338192 CLUTCH HOUSING SHAFT	-	1	Enquire
0003	318975	SNAP RING	318975 SNAP RING	-	2	Enquire
0004	252524	COMPL. BEARING	252524 COMPL. BEARING	-	2	Enquire
0005	253627	RING	253627 RING	-	2	Enquire
0006	11062474	SNAP RING	11062474 SNAP RING	-	2	Enquire
0007	342924	TRANSMISSION HOUSING FLANGE	342924 TRANSMISSION HOUSING FLANGE	-	1	Enquire
0008	14306624	SCREW	14306624 SCREW M8 X 35	-	4	Enquire
0009	12602479	WASHER	12602479 WASHER	-	4	Enquire
0010	14059421	NUT	14059421 NUT	-	10	Enquire
0011	102704	ALIGNMENT DOWEL	102704 ALIGNMENT DOWEL	-	2	Enquire
0012	13543124	STUD BOLT	13543124 STUD BOLT M8 X 16	-	2	Enquire
0013	14306731	SCREW	14306731 SCREW M8 X 1.25 X 40	-	1	Enquire
0014	14499421	WASHER	14499421 WASHER	-	3	Enquire
0015	341028	BUSH TRAVEL LIMITER BRACKET	341028 BUSH TRAVEL LIMITER BRACKET	-	1	Enquire
0016	18754324	SCREW	18754324 SCREW M10 X 1.25 X 32	-	3	Enquire
0017	269664	WASHER	269664 WASHER	-	3	Enquire
0018	786862	TRANSMISSION HOUSING BUSHING SHIELD	786862 TRANSMISSION HOUSING BUSHING SHIELD	-	1	Enquire
0019	747853	SCREW	747853 SCREW M5 X 25	-	1	Enquire
0020	12638124	WASHER	12638124 WASHER	-	4	Enquire
0021	14059114	NUT	14059114 NUT	-	3	Enquire
0022	329287	BUSH	329287 BUSH	-	1	Enquire
0023	255271	NUT	255271 NUT	-	1	Enquire
0024	854453	BUSHING TRAVEL STOP BRACKET	854453 BUSHING TRAVEL STOP BRACKET	-	1	Enquire
0025	13028734	SCREW	13028734 SCREW M8 X 25	-	2	Enquire
