Ferrari LaFerrari - GEARBOX OIL COOLING SYSTEM

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
298095 GEARBOX OIL RADIATOR Enquire To Order
Photo Part No Description Price (each) Stock
294318 CLUTCH OIL RADIATOR Enquire To Order
Photo Part No Description Price (each) Stock
305209 GL OIL DELIVERY PIPE Enquire To Order
Photo Part No Description Price (each) Stock
305208 GL OIL RETURN PIPE Enquire To Order
Photo Part No Description Price (each) Stock
305206 ATF FLUID RETURN PIPE Enquire To Order
Photo Part No Description Price (each) Stock
305207 ATF FLUID DELIVERY PIPE Enquire To Order
Photo Part No Description Price (each) Stock
303322 ADHESIVE FOAM Enquire To Order
Photo Part No Description Price (each) Stock
299800 BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
287095 FORK Enquire To Order
Photo Part No Description Price (each) Stock
14306424 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
14499421 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
254644 O-RING Enquire To Order
Photo Part No Description Price (each) Stock
243396 RETAINER BLOCK Enquire To Order
Photo Part No Description Price (each) Stock
243399 BUSH Enquire To Order
Photo Part No Description Price (each) Stock
243398 PLATE Enquire To Order
Photo Part No Description Price (each) Stock
13027824 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
13550224 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
231624 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER Enquire To Order
Photo Part No Description Price (each) Stock
812273 CABLE GROMMET Enquire To Order
Photo Part No Description Price (each) Stock
149707 SPACER Enquire To Order
Photo Part No Description Price (each) Stock
12643724 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
287096 FORK Enquire To Order
Photo Part No Description Price (each) Stock
248334 SCREW M6 X 14MM Enquire To Order
Photo Part No Description Price (each) Stock
292132 SPACER Enquire To Order
Photo Part No Description Price (each) Stock
231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER Enquire To Order
Photo Part No Description Price (each) Stock
231625 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
12646624 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
248334 SCREW M6 X 14MM Enquire To Order
Photo Part No Description Price (each) Stock
85744500 GASKET Enquire To Order
Photo Part No Description Price (each) Stock
86065100 GASKET Enquire To Order
Photo Part No Description Price (each) Stock
85933600 GASKET Enquire To Order
View All
GEARBOX OIL COOLING SYSTEM of Ferrari Ferrari LaFerrari Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 298095
GEARBOX OIL RADIATOR 		- 1 Enquire
2 294318
CLUTCH OIL RADIATOR 		- 1 Enquire
3 305209
GL OIL DELIVERY PIPE 		- 1 Enquire
4 305208
GL OIL RETURN PIPE 		- 1 Enquire
5 305206
ATF FLUID RETURN PIPE 		- 1 Enquire
6 305207
ATF FLUID DELIVERY PIPE 		- 1 Enquire
7 303322
ADHESIVE FOAM 		- 1 Enquire
8 299800
BRACKET 		- 1 Enquire
9 287095
FORK 		- 1 Enquire
10 14306424
SCREW
M8 X 20 		- 2 Enquire
11 14499421
WASHER 		- 2 Enquire
12 254644
O-RING 		- 4 Enquire
13 243396
RETAINER BLOCK 		- 6 Enquire
14 243399
BUSH 		- 12 Enquire
15 243398
PLATE 		- 6 Enquire
16 13027824
SCREW 		- 2 Enquire
17 13550224
WASHER 		- 2 Enquire
18 231624
SCREW
M6 X 45 		- 3 Enquire
19 231619
SOCKET HEAD SCREW M6 X 22 WITH WASHER
M6 X 22 		- 4 Enquire
20 812273
CABLE GROMMET 		- 4 Enquire
21 149707
SPACER 		- 4 Enquire
22 12643724
WASHER 		- 4 Enquire
23 287096
FORK 		- 1 Enquire
24 248334
SCREW M6 X 14MM 		- 1 Enquire
25 292132
SPACER 		- 1 Enquire
26 231619
SOCKET HEAD SCREW M6 X 22 WITH WASHER
M6 X 22 		- 1 Enquire
27 231625
SCREW
M6 X 40 		- 1 Enquire
28 12646624
WASHER 		- 1 Enquire
29 248334
SCREW M6 X 14MM
M6 X 14 		- 4 Enquire
30 85744500
GASKET 		- 1 Enquire
31 86065100
GASKET 		- 1 Enquire
32 85933600
GASKET 		- 1 Enquire
