FRONT SUSPENSION - WISHBONES

Find Your Part

Ferrari F50 - FRONT SUSPENSION - WISHBONES

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
150932 SHOCK ABSORBER CONTROL ROCKER ARM $1,283.66 To Order
Photo Part No Description Price (each) Stock
13539124 STUD $5.06 To Order
Photo Part No Description Price (each) Stock
150153 SEAL RING $41.14 To Order
Photo Part No Description Price (each) Stock
150152 ROLLER BEARING $182.13 To Order
Photo Part No Description Price (each) Stock
152022 SPACER $26.26 To Order
Photo Part No Description Price (each) Stock
151983 FULCRUM PIN $369.04 To Order
Photo Part No Description Price (each) Stock
153322 PIN $93.05 To Order
Photo Part No Description Price (each) Stock
10732531 WASHER $0.52 To Order
Photo Part No Description Price (each) Stock
132876 NUT -As an alternative- $34.56 To Order
Photo Part No Description Price (each) Stock
150082 BUSHING $498.25 To Order
Photo Part No Description Price (each) Stock
156260 Washer thickness mm. 0,2 $1.43 To Order
Photo Part No Description Price (each) Stock
149125 BALL JOINT $593.69 To Order
Photo Part No Description Price (each) Stock
10717477 NUT $9.51 To Order
Photo Part No Description Price (each) Stock
165656 SHOCK ABSORBER CONTROL ROD $465.32 To Order
Photo Part No Description Price (each) Stock
149124 L.H. THREADED NUT $4.52 To Order
Photo Part No Description Price (each) Stock
149126 BALL JOINT $593.69 To Order
Photo Part No Description Price (each) Stock
146999 BALL JOINT FOR LOWER LEVER $364.03 To Order
Photo Part No Description Price (each) Stock
155002 Washer $15.66 To Order
Photo Part No Description Price (each) Stock
149807 NUT $1.18 To Order
Photo Part No Description Price (each) Stock
152678 LOWER LEVER $4,492.86 To Order
Photo Part No Description Price (each) Stock
152819 SCREW $28.59 To Order
Photo Part No Description Price (each) Stock
166448 WASHER $11.70 To Order
Photo Part No Description Price (each) Stock
133216 NUT $9.30 To Order
Photo Part No Description Price (each) Stock
152817 SCREW WITH ECCENTRIC $34.56 To Order
Photo Part No Description Price (each) Stock
152818 ECCENTRIC WASHER $57.75 To Order
Photo Part No Description Price (each) Stock
132876 NUT -As an alternative- $34.56 To Order
Photo Part No Description Price (each) Stock
152623 LOWER LEVER TIE ROD $545.55 To Order
Photo Part No Description Price (each) Stock
152693 PIN $25.66 To Order
Photo Part No Description Price (each) Stock
132876 NUT -As an alternative- $34.56 To Order
Photo Part No Description Price (each) Stock
129221 WASHER $4.39 To Order
Photo Part No Description Price (each) Stock
10717477 NUT $9.51 To Order
Photo Part No Description Price (each) Stock
152660 BRACKET FOR LOWER LEVER FIXING $593.69 To Order
Photo Part No Description Price (each) Stock
12601474 WASHER $0.03 To Order
Photo Part No Description Price (each) Stock
133216 NUT $9.30 To Order
Photo Part No Description Price (each) Stock
14040711 NUT $0.41 To Order
Photo Part No Description Price (each) Stock
12429324 STUD $15.66 To Order
Photo Part No Description Price (each) Stock
152626 BALL JOINT $588.16 To Order
Photo Part No Description Price (each) Stock
10730321 WASHER $0.57 To Order
Photo Part No Description Price (each) Stock
14040711 NUT $0.41 To Order
Photo Part No Description Price (each) Stock
153746 BALL JOINT $465.66 To Order
Photo Part No Description Price (each) Stock
102901 SPACER WASHER $0.39 To Order
Photo Part No Description Price (each) Stock
133216 NUT $9.30 To Order
Photo Part No Description Price (each) Stock
150786 SPACER $97.86 To Order
Photo Part No Description Price (each) Stock
151229 BRACKET FOR LOWER LEVER $94.66 To Order
Photo Part No Description Price (each) Stock
151290 R.H. UPPER LEVER $3,313.48 To Order
Photo Part No Description Price (each) Stock
248334 SCREW $0.68 To Order
Photo Part No Description Price (each) Stock
238108 WASHER $0.47 To Order
Photo Part No Description Price (each) Stock
130202 BALL JOINT FOR UPPER LEVER $915.61 To Order
Photo Part No Description Price (each) Stock
150143 WASHER $21.44 To Order
Photo Part No Description Price (each) Stock
169193 NUT $1.49 To Order
Photo Part No Description Price (each) Stock
151812 R.H. LEVER SUPPORT SUPPORT $1,412.03 To Order
Photo Part No Description Price (each) Stock
102742 Nyloc Nut M10 x 1.25 x 10mm $0.45 To Order
Photo Part No Description Price (each) Stock
152021 WASHER $11.18 To Order
Photo Part No Description Price (each) Stock
151982 BUSHING $142.74 To Order
Photo Part No Description Price (each) Stock
150961 CENTERING DOWEL $43.31 To Order
Photo Part No Description Price (each) Stock
12638524 WASHER $0.06 To Order
Photo Part No Description Price (each) Stock
14040711 NUT $0.41 To Order
Photo Part No Description Price (each) Stock
152020 BUSHING $364.88 To Order
Photo Part No Description Price (each) Stock
163918 BALL JOINT FOR CONTROL ARM $139.58 To Order
Photo Part No Description Price (each) Stock
152032 WASHER Th. mm. 0,2 $6.90 To Order
Photo Part No Description Price (each) Stock
132876 NUT -As an alternative- $34.56 To Order
Photo Part No Description Price (each) Stock
152031 WASHER $293.93 To Order
Photo Part No Description Price (each) Stock
152023 UPPER LEVER PIN $224.63 To Order
Photo Part No Description Price (each) Stock
152615 END OF STROKE PAD $14.91 To Order
View All
FRONT SUSPENSION - WISHBONES of Ferrari Ferrari F50 Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 152037
WASHER Th. mm. 0,8
As an alternative 		$6.68 4
- 152038
WASHER Th. mm. 1,0
As an alternative 		$6.68 4
- 152035
WASHER Th. mm. 0,6
As an alternative 		$6.68 4
- 152036
WASHER Th. mm. 0,7
As an alternative 		$6.68 4
- 152033
WASHER Th. mm. 0,3
As an alternative 		$6.90 4
- 152034
WASHER
As an alternative 		$6.90 (18.8% off) 4
- 133216
NUT 		$9.30 (10.7% off) 2
- 151811
L.H. LEVER SUPPORT SUPPORT 		$3,407.18 1
- 171114
L.H. UPPER LEVER 		$3,313.48 1
- 102742
Nyloc Nut M10 x 1.25 x 10mm 		$0.45 (86.2% off) 4
- 147985
NUT 		$0.16 (68% off) 4
- 102742
Nyloc Nut M10 x 1.25 x 10mm 		$0.45 (86.2% off) 2
- 12601474
WASHER 		$0.03 4
- 10717477
NUT 		$9.51 2
- 156266
WASHER Th. mm. 1,0 -As an alternative-
As an alternative 		$1.43 (57.7% off) 2
- 156262
WASHER Th. mm. 0,5 -As an alternative-
As an alternative 		$1.43 (57.7% off) 2
- 156263
WASHER Th. mm. 0,6 -As an alternative-
As an alternative 		$1.43 (57.7% off) 2
- 156264
WASHER Th. mm. 0,7 -As an alternative-
As an alternative 		$1.17 (65.4% off) 2
- 156265
WASHER Th. mm. 0,8 -As an alternative-
As an alternative 		$1.17 (60.3% off) 2
- 132876
NUT -As an alternative- 		$34.56 2
- 156261
WASHER Th. mm. 0,3 -As an alternative-
As an alternative 		$1.17 (60.3% off) 2
1 150932
SHOCK ABSORBER CONTROL ROCKER ARM
ROCKER ARM 		$1,283.66 2
2 13539124
STUD 		$5.06 4
3 150153
SEAL RING 		$41.14 4
4 150152
ROLLER BEARING 		$182.13 4
5 152022
SPACER 		$26.26 2
6 151983
FULCRUM PIN 		$369.04 2
7 153322
PIN 		$93.05 2
8 10732531
WASHER 		$0.52 4
9 132876
NUT -As an alternative- 		$34.56 2
10 150082
BUSHING 		$498.25 4
11 156260
Washer thickness mm. 0,2 		$1.43 (57.7% off) 2
12 149125
BALL JOINT 		$593.69 2
13 10717477
NUT
Not as spare part now / Replaced by 10717477 		$9.51 2
14 165656
SHOCK ABSORBER CONTROL ROD 		$465.32 2
15 149124
L.H. THREADED NUT 		$4.52 2
16 149126
BALL JOINT 		$593.69 2
17 146999
BALL JOINT FOR LOWER LEVER 		$364.03 2
18 155002
Washer 		$15.66 2
19 149807
NUT 		$1.18 (41% off) 2
20 152678
LOWER LEVER 		$4,492.86 2
21 152819
SCREW 		$28.59 2
22 166448
WASHER 		$11.70 4
23 133216
NUT 		$9.30 (10.7% off) 2
24 152817
SCREW WITH ECCENTRIC 		$34.56 2
25 152818
ECCENTRIC WASHER 		$57.75 2
26 132876
NUT -As an alternative- 		$34.56 2
27 152623
LOWER LEVER TIE ROD 		$545.55 2
28 152693
PIN 		$25.66 2
29 132876
NUT -As an alternative- 		$34.56 2
30 129221
WASHER 		$4.39 2
31 10717477
NUT
Not as spare part now / Replaced by 10717477 		$9.51 2
32 152660
BRACKET FOR LOWER LEVER FIXING
FIXING 		$593.69 2
33 12601474
WASHER 		$0.03 4
34 133216
NUT 		$9.30 (10.7% off) 4
35 14040711
NUT 		$0.41 2
36 12429324
STUD 		$15.66 4
37 152626
BALL JOINT 		$588.16 2
38 10730321
WASHER 		$0.57 (43% off) 4
39 14040711
NUT 		$0.41 4
40 153746
BALL JOINT 		$465.66 2
41 102901
SPACER WASHER 		$0.39 4
42 133216
NUT 		$9.30 (10.7% off) 4
43 150786
SPACER 		$97.86 4
44 151229
BRACKET FOR LOWER LEVER 		$94.66 2
45 151290
R.H. UPPER LEVER 		$3,313.48 1
46 248334
SCREW 		$0.68 8
47 238108
WASHER 		$0.47 (27.7% off) 8
48 130202
BALL JOINT FOR UPPER LEVER 		$915.61 2
49 150143
WASHER 		$21.44 2
50 169193
NUT 		$1.49 2
51 151812
R.H. LEVER SUPPORT SUPPORT 		$1,412.03 1
52 102742
Nyloc Nut M10 x 1.25 x 10mm 		$0.45 (86.2% off) 2
53 152021
WASHER 		$11.18 2
54 151982
BUSHING 		$142.74 2
55 150961
CENTERING DOWEL 		$43.31 4
56 12638524
WASHER 		$0.06 (76% off) 10
57 14040711
NUT 		$0.41 10
58 152020
BUSHING 		$364.88 4
59 163918
BALL JOINT FOR CONTROL ARM 		$139.58 (22.5% off) 4
60 152032
WASHER Th. mm. 0,2 		$6.90 4
61 132876
NUT -As an alternative- 		$34.56 4
62 152031
WASHER 		$293.93 4
63 152023
UPPER LEVER PIN 		$224.63 4
64 152615
END OF STROKE PAD 		$14.91 2
