ALTERNATOR - STARTING MOTOR - AIR CONDITIONING COMPRESSOR of Ferrari Ferrari 550 Maranello (2011-2012)

View All

Ferrari 550 Maranello (2011-2012) - ALTERNATOR - STARTING MOTOR - AIR CONDITIONING COMPRESSOR

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	11500124	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13540824	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13540824	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10441290	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12639724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	153390	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164397	STARTER MOTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16044921	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84653800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11193874	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	176333	STARTER MOTOR SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13577724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	124683	PROTECTIVE CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147985	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638524	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	204539	AC SYSTEM COMPRESSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	170595	MOUNTING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14307834	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11190574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10569474	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11343821	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	169774	CABLE FROM ALTERNATOR TO BATTERY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	176334	COMPRESSOR SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13577724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81591700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	165490	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101632	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14307934	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	201444	Belt For Alternator And Compressor	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11190574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	156858	Alternator 140 Amp	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164534	ALTERNATOR SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	137920	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	123172	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11190574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	128944	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16102314	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601374	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154803	PROTECTIVE CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148020	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13507401	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164533	BELT TENSIONER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14307834	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11190574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148629	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102742	Nyloc Nut M10 x 1.25 x 10mm	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	128944	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	125668	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14496524	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148632	BELT TIGHTENING PULLEY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	123350	BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11060076	Seeger Ring	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148020	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101016	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14307834	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164538	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11190574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	145476	L.H. BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	172537	Belt Tightening Pulley	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	102695	WASHER	102695 WASHER Valid from car No. 58891	-	1	Enquire
-	133216	NUT	133216 NUT Valid from car No. 58891	-	1	Enquire
-	175035	ALTERNATOR MOUNT	175035 ALTERNATOR MOUNT Valid from car No. 58891	-	1	Enquire
-	201444	Belt For Alternator And Compressor	201444 Belt For Alternator And Compressor COMPRESSOR / Valid from engine Nr. 51923	-	1	Enquire
-	179273	CABLES FOR MOTOR DEVICES CONNECTION	179273 CABLES FOR MOTOR DEVICES CONNECTION MOTOR DEVICES / Valid for GD / Valid from car Ass. Nr. 32105	-	1	Enquire
-	176334	COMPRESSOR SHIELD	176334 COMPRESSOR SHIELD PROTECTION / Valid after stock exhaustion of 165491	-	1	Enquire
-	179241	CABLES FOR MOTOR DEVICES CONNECTION	179241 CABLES FOR MOTOR DEVICES CONNECTION MOTOR DEVICES / Not for GD / Valid from car Ass. Nr. 32102 GS / and from car Ass. Nr. 32057 M.Y. 99	-	1	Enquire
-	171391	CABLE FROM ALTERNATOR TO BATTERY	171391 CABLE FROM ALTERNATOR TO BATTERY BATTERY / Valid for GD / Vale fino alla vett. Ass. Nr. 32104	-	1	Enquire
-	176333	STARTER MOTOR SHIELD	176333 STARTER MOTOR SHIELD PROTECTION / Valid after stock exhaustion of 165895	-	1	Enquire
-	16044821	SCREW	16044821 SCREW L. 80	-	1	Enquire
-	175033	PIN	175033 PIN Valid from car No. 58891	-	1	Enquire
1	11500124	STUD BOLT	11500124 STUD BOLT	-	2	Enquire
2	13540824	STUD BOLT	13540824 STUD BOLT	-	1	Enquire
3	13540824	STUD BOLT	13540824 STUD BOLT	-	2	Enquire
4	10441290	BRACKET WITH SHEATH	10441290 BRACKET WITH SHEATH	-	2	Enquire
5	12639724	WASHER	12639724 WASHER	-	2	Enquire
6	127494	WASHER	127494 WASHER	-	2	Enquire
7	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	2	Enquire
8	153390	PIN	153390 PIN Valid till car No. 58890	-	1	Enquire
9	164397	STARTER MOTOR	164397 STARTER MOTOR	-	1	Enquire
10	16044921	SCREW	16044921 SCREW L. 85	-	2	Enquire
11	84653800	WASHER	84653800 WASHER	-	3	Enquire
12	11193874	WASHER	11193874 WASHER	-	3	Enquire
13	176333	STARTER MOTOR SHIELD	176333 STARTER MOTOR SHIELD PROTECTION / Valid till stock exhaustion	-	1	Enquire
14	13577724	WASHER	13577724 WASHER	-	3	Enquire
15	127494	WASHER	127494 WASHER	-	3	Enquire
16	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	3	Enquire
17	124683	PROTECTIVE CAP	124683 PROTECTIVE CAP	-	1	Enquire
18	147985	NUT	147985 NUT	-	1	Enquire
19	12638524	WASHER	12638524 WASHER	-	1	Enquire
20	204539	AC SYSTEM COMPRESSOR	204539 AC SYSTEM COMPRESSOR COMPRESSOR	-	1	Enquire
21	170595	MOUNTING	170595 MOUNTING	-	1	Enquire
22	14307834	SCREW	14307834 SCREW	-	4	Enquire
23	11190574	WASHER	11190574 WASHER	-	6	Enquire
24	10569474	WASHER	10569474 WASHER	-	1	Enquire
25	11343821	SCREW	11343821 SCREW	-	1	Enquire
26	169774	CABLE FROM ALTERNATOR TO BATTERY	169774 CABLE FROM ALTERNATOR TO BATTERY BATTERY -Not for GD / Valid till car Ass. Nr. 32101 GS and / till car Ass. Nr. 32056 M.Y. 99	-	1	Enquire
27	176334	COMPRESSOR SHIELD	176334 COMPRESSOR SHIELD PROTECTION / Valid till stock exhaustion	-	1	Enquire
28	13577724	WASHER	13577724 WASHER	-	2	Enquire
29	81591700	SCREW	81591700 SCREW	-	2	Enquire
30	127494	WASHER	127494 WASHER	-	2	Enquire
31	165490	BRACKET	165490 BRACKET	-	1	Enquire
32	101632	SCREW	101632 SCREW	-	1	Enquire
33	14307934	SCREW	14307934 SCREW	-	1	Enquire
34	201444	Belt For Alternator And Compressor	201444 Belt For Alternator And Compressor COMPRESSOR / Valid till engine Nr. 51922	-	1	Enquire
35	11190574	WASHER	11190574 WASHER	-	3	Enquire
36	156858	Alternator 140 Amp	156858 Alternator 140 Amp	-	1	Enquire
37	164534	ALTERNATOR SUPPORT	164534 ALTERNATOR SUPPORT Valid till car No. 58890	-	1	Enquire
38	137920	SCREW	137920 SCREW	-	1	Enquire
39	123172	BUSHING	123172 BUSHING	-	1	Enquire
40	11190574	WASHER	11190574 WASHER	-	1	Enquire
41	128944	WASHER	128944 WASHER	-	2	Enquire
42	16102314	NUT	16102314 NUT	-	1	Enquire
43	12601374	WASHER	12601374 WASHER	-	1	Enquire
44	154803	PROTECTIVE CAP	154803 PROTECTIVE CAP	-	1	Enquire
45	148020	NUT	148020 NUT	-	1	Enquire
46	13507401	WASHER	13507401 WASHER	-	2	Enquire
47	164533	BELT TENSIONER BRACKET	164533 BELT TENSIONER BRACKET	-	1	Enquire
48	14307834	SCREW	14307834 SCREW	-	1	Enquire
49	11190574	WASHER	11190574 WASHER	-	1	Enquire
50	148629	PIN	148629 PIN	-	1	Enquire
51	102742	Nyloc Nut M10 x 1.25 x 10mm ARRIVING SOON	102742 Nyloc Nut M10 x 1.25 x 10mm ARRIVING SOON	-	1	Enquire
52	128944	WASHER	128944 WASHER	-	1	Enquire
53	125668	SCREW	125668 SCREW	-	1	Enquire
54	14496524	WASHER	14496524 WASHER	-	1	Enquire
55	148632	BELT TIGHTENING PULLEY	148632 BELT TIGHTENING PULLEY Valid till car No. 58890	-	1	Enquire
56	123350	BEARING	123350 BEARING Valid till car No. 58890	-	1	Enquire
57	11060076	Seeger Ring	11060076 Seeger Ring Valid till car No. 58890	-	1	Enquire
58	148020	NUT	148020 NUT Valid till car No. 58890	-	1	Enquire
59	101016	WASHER	101016 WASHER Valid till car No. 58890	-	1	Enquire
60	14307834	SCREW	14307834 SCREW	-	1	Enquire
61	164538	BUSHING	164538 BUSHING	-	2	Enquire
62	11190574	WASHER	11190574 WASHER	-	1	Enquire
63	145476	L.H. BRACKET	145476 L.H. BRACKET Valid from car Ass. Nr. 32102 GS, / from car Ass. Nr. 32105 GD and / from car Ass. Nr. 32057 M.Y. 99	-	1	Enquire
64	172537	Belt Tightening Pulley	172537 Belt Tightening Pulley PULLEY / Valid from car No. 58891	-	1	Enquire
