Door - Power Window

Ferrari 512 TR

Find Your Part

Ferrari 512 TR - Door - Power window

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
63096200 L.H. window regulator Enquire To Order
Photo Part No Description Price (each) Stock
61533600 L.H. glass Enquire To Order
Photo Part No Description Price (each) Stock
63057200 L.H. frame work complete Enquire To Order
Photo Part No Description Price (each) Stock
61548600 Gasket for L.H. door Enquire To Order
Photo Part No Description Price (each) Stock
61574000 Support for LH external rear view mirror Enquire To Order
Photo Part No Description Price (each) Stock
147985 NUT Enquire To Order
Photo Part No Description Price (each) Stock
61568600 BUTTON Enquire To Order
Photo Part No Description Price (each) Stock
62771300 Column Enquire To Order
Photo Part No Description Price (each) Stock
61509800 Run channel Enquire To Order
Photo Part No Description Price (each) Stock
61509900 Rear run channel Enquire To Order
Photo Part No Description Price (each) Stock
62106600 OUTER BUSHING Enquire To Order
Photo Part No Description Price (each) Stock
62106700 INNER BUSHING Enquire To Order
Photo Part No Description Price (each) Stock
63108500 L.H. glass base Enquire To Order
Photo Part No Description Price (each) Stock
63111300 Cover to fix LH mirror Enquire To Order
Photo Part No Description Price (each) Stock
10902424 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire To Order
Photo Part No Description Price (each) Stock
12643724 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
62766200 Bushing Enquire To Order
Photo Part No Description Price (each) Stock
10902221 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
14084411 Nut Enquire To Order
Photo Part No Description Price (each) Stock
127494 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
62766300 CLIP Enquire To Order
Photo Part No Description Price (each) Stock
84653800 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
812273 CABLE GROMMET Enquire To Order
Photo Part No Description Price (each) Stock
12648925 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire To Order
Photo Part No Description Price (each) Stock
10902221 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
127494 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
12648925 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
81591700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
127494 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
12648925 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
63951200 Bracket Enquire To Order
Photo Part No Description Price (each) Stock
13836371 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
10977521 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
12638124 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
319201 FUEL FILLER PIPE ASSEMBLY Enquire To Order
Photo Part No Description Price (each) Stock
64536300 Spacer Enquire To Order
Photo Part No Description Price (each) Stock
64536200 Spacer Enquire To Order
View All
Door - Power window of Ferrari Ferrari 512 TR Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 63108400
R.H. glass base 		- 1 Enquire
- 63111200
Cover to fix RH mirror
R.H. mirror 		- 1 Enquire
- 61573900
Support for RH external rear view mirror
view mirror 		- 1 Enquire
- 63057100
R.H. frame work complete 		- 1 Enquire
- 61548500
Gasket for R.H. door 		- 1 Enquire
- 63096100
R.H. window regulator 		- 1 Enquire
- 61533700
R.H. glass 		- 1 Enquire
1 63096200
L.H. window regulator 		- 1 Enquire
2 61533600
L.H. glass 		- 1 Enquire
3 63057200
L.H. frame work complete 		- 1 Enquire
4 61548600
Gasket for L.H. door 		- 1 Enquire
5 61574000
Support for LH external rear view mirror
view mirror 		- 1 Enquire
6 147985
NUT 		- 2 Enquire
7 61568600
BUTTON 		- 6 Enquire
8 62771300
Column 		- 4 Enquire
9 61509800
Run channel 		- 2 Enquire
10 61509900
Rear run channel 		- 2 Enquire
11 62106600
OUTER BUSHING 		- 4 Enquire
12 62106700
INNER BUSHING 		- 4 Enquire
13 63108500
L.H. glass base 		- 1 Enquire
14 63111300
Cover to fix LH mirror
L.H. mirror 		- 1 Enquire
15 10902424
SCREW 		- 4 Enquire
16 14059290
FLANGED NUT M6 		- 4 Enquire
17 12643724
WASHER 		- 14 Enquire
18 62766200
Bushing 		- 4 Enquire
19 10902221
SCREW 		- 6 Enquire
20 14084411
Nut 		- 2 Enquire
21 127494
WASHER 		- 2 Enquire
22 62766300
CLIP 		- 4 Enquire
23 84653800
WASHER 		- 2 Enquire
24 812273
CABLE GROMMET 		- 2 Enquire
25 12648925
WASHER 		- 4 Enquire
26 14059290
FLANGED NUT M6 		- 4 Enquire
27 10902221
SCREW 		- 6 Enquire
28 127494
WASHER 		- 6 Enquire
29 12648925
WASHER 		- 6 Enquire
30 81591700
SCREW 		- 2 Enquire
31 127494
WASHER 		- 2 Enquire
32 12648925
WASHER 		- 2 Enquire
33 63951200
Bracket 		- 2 Enquire
34 13836371
SCREW 		- 2 Enquire
35 10977521
SCREW 		- 2 Enquire
36 12638124
WASHER 		- 4 Enquire
37 319201
FUEL FILLER PIPE ASSEMBLY 		- 2 Enquire
38 64536300
Spacer 		- 2 Enquire
39 64536200
Spacer 		- 2 Enquire
