FRONT BUMPER of Ferrari Ferrari 458 Spider

View All

Ferrari 458 Spider - FRONT BUMPER

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	83327310	COMPL. FRONT BUMPER	Enquire	To Order
	83104610	COMPL. FRONT BUMPER	Enquire	To Order
	83327210	COMPL. FRONT BUMPER	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	13046214	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81761910	FRONT RH SPOILER	Enquire	To Order
	83262500	FRONT RH SPOILER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81762010	FRONT LH SPOILER	Enquire	To Order
	83262800	FRONT LH SPOILER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82131810	TOW HOOK COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81761100	RH AIR INTAKE GRILLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81761200	LH AIR INTAKE GRILLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81368400	RH BRAKE AIR INTAKE GRILLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81368500	LH Brake Air Intake Grille	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82955600	BADGE MOUNTING	Enquire	To Order
	86056700	BADGE MOUNTING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13275424	Screw	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82288600	INNER SENSOR HOUSING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82288700	OUTER SENSOR HOUSING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	83435300	FRONT LICENSE PLATE MOUNTING	Enquire	To Order
	85096200	FRONT LICENSE PLATE MOUNT	Enquire	To Order
	83435900	FRONT LICENSE PLATE MOUNTING	Enquire	To Order

...and 4 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	14115480	BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15688075	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	239082	Parking Sensor	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	82118300	SCREW -No longer supplied- -Replaced by 11625714-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	105864	SPACER WASHER D.6.5-24X1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	83054700	Front Bumper Impact Absorber	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	770452	SILICONE RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16405002	Clip for Tow Hook Hole Cover	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	83327310	COMPL. FRONT BUMPER	83327310 COMPL. FRONT BUMPER Parking sensors; Does not contain sensors; Applicable for USA, CDN	-	1	Enquire
1	83104610	COMPL. FRONT BUMPER	83104610 COMPL. FRONT BUMPER Not for USA, CDN	-	1	Enquire
1	83327210	COMPL. FRONT BUMPER	83327210 COMPL. FRONT BUMPER Applicable for USA, CDN	-	1	Enquire
1	83104710	COMPL. FRONT BUMPER	83104710 COMPL. FRONT BUMPER Parking sensors; Does not contain sensors; Not for USA, CDN	-	1	Enquire
2	13046214	NUT	13046214 NUT	-	6	Enquire
3	81761910	FRONT RH SPOILER	81761910 FRONT RH SPOILER	-	1	Enquire
3	83262500	FRONT RH SPOILER	83262500 FRONT RH SPOILER Carbon	-	1	Enquire
4	81762010	FRONT LH SPOILER	81762010 FRONT LH SPOILER	-	1	Enquire
4	83262800	FRONT LH SPOILER	83262800 FRONT LH SPOILER Carbon	-	1	Enquire
5	82131810	TOW HOOK COVER	82131810 TOW HOOK COVER Order clip 16405002 ref. 23 separately	-	1	Enquire
6	81761100	RH AIR INTAKE GRILLE	81761100 RH AIR INTAKE GRILLE	-	1	Enquire
7	81761200	LH AIR INTAKE GRILLE	81761200 LH AIR INTAKE GRILLE	-	1	Enquire
8	81368400	RH BRAKE AIR INTAKE GRILLE	81368400 RH BRAKE AIR INTAKE GRILLE	-	1	Enquire
9	81368500	LH Brake Air Intake Grille	81368500 LH Brake Air Intake Grille	-	1	Enquire
10	82955600	BADGE MOUNTING	82955600 BADGE MOUNTING	-	1	Enquire
10	86056700	BADGE MOUNTING	86056700 BADGE MOUNTING No longer supplied	-	1	Enquire
11	13275424	Screw	13275424 Screw	-	1	Enquire
12	82288600	INNER SENSOR HOUSING	82288600 INNER SENSOR HOUSING Parking sensors	-	2	Enquire
13	82288700	OUTER SENSOR HOUSING	82288700 OUTER SENSOR HOUSING Parking sensors	-	2	Enquire
14	83435300	FRONT LICENSE PLATE MOUNTING	83435300 FRONT LICENSE PLATE MOUNTING Applicable for J	-	1	Enquire
14	85096200	FRONT LICENSE PLATE MOUNT	85096200 FRONT LICENSE PLATE MOUNT Applicable for GOLFO	-	1	Enquire
14	83435900	FRONT LICENSE PLATE MOUNTING	83435900 FRONT LICENSE PLATE MOUNTING Not for Taiwan; Not for AUS, CINA, USA, CDN, GOLFO, J	-	1	Enquire
14	83435100	FRONT LICENSE PLATE MOUNTING	83435100 FRONT LICENSE PLATE MOUNTING Applicable for AUS	-	1	Enquire
14	83434700	FRONT LICENSE PLATE MOUNTING	83434700 FRONT LICENSE PLATE MOUNTING Applicable for Taiwan; Applicable for USA, CDN	-	1	Enquire
14	83436000	FRONT LICENSE PLATE MOUNTING	83436000 FRONT LICENSE PLATE MOUNTING Applicable for Germany	-	1	Enquire
14	83435500	FRONT LICENSE PLATE MOUNTING	83435500 FRONT LICENSE PLATE MOUNTING Applicable for CINA	-	1	Enquire
15	14115480	BLOCK	14115480 BLOCK	-	4	Enquire
16	15688075	SCREW	15688075 SCREW	-	2	Enquire
17	239082	Parking Sensor	239082 Parking Sensor Parking sensors	-	4	Enquire
18	82118300	SCREW -No longer supplied- -Replaced by 11625714-	82118300 SCREW -No longer supplied- -Replaced by 11625714-	-	6	Enquire
19	105864	SPACER WASHER D.6.5-24X1.5	105864 SPACER WASHER D.6.5-24X1.5	-	6	Enquire
20	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	6	Enquire
21	83054700	Front Bumper Impact Absorber	83054700 Front Bumper Impact Absorber Applicable for USA, CDN	-	1	Enquire
22	770452	SILICONE RING	770452 SILICONE RING Parking sensors	-	4	Enquire
23	16405002	Clip for Tow Hook Hole Cover	16405002 Clip for Tow Hook Hole Cover	-	1	Enquire
24	12643724	WASHER	12643724 WASHER	-	2	Enquire
