REAR BUMPER AND MOVABLE SPOILER -Valid for 456 GTA- of Ferrari Ferrari 456 GT/GTA

View All

Ferrari 456 GT/GTA - REAR BUMPER AND MOVABLE SPOILER -Valid for 456 GTA-

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	64089110	COMPLETE REAR BUMPER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64723500	RH BRACKET FOR BUMPER FIXING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64723600	LH BRACKET FOR BUMPER FIXING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63214100	ABSORPTION PAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	174159	COMPLETE LH LIGHT LIFTING MOTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63737200	MOBILE STABILIZER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63739200	SPACER FOR WICK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64723700	TRASMISSION PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63739600	R.H. BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63739300	SPACER FOR BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62794500	THREADED PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	186180	REAR LICENSE PLATE LIGHT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64890800	CENTRAL SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63857700	SEMI-BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63857500	BRACKET FOR SHAFT FIXING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63738000	SUPPORT WHIT FLANGE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16135724	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16102314	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84653800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84653800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64059900	R.H. SUPPORT BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65469000	SUPPORT COMPLETE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63870600	R.H. BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63737800	PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63741000	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63186100	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12608574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12647021	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14040711	NUT M8 FLANGED	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64831100	HEAT SHIELDS SERIES	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81591700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14084111	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14202782	BLOCK -Valid for SA-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	319201	FUEL FILLER PIPE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638124	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62794800	RUBBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140594	REAR SIDE-MARKER LIGHT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12648925	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64231400	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11087776	SNAP RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	319201	FUEL FILLER PIPE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638124	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	133988	HEX NUT M10 X 1.25 X 8	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127497	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12626224	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16043021	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14040711	NUT M8 FLANGED	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12642777	WASHER -Valid for GTS-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10902224	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	133988	HEX NUT M10 X 1.25 X 8	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12648504	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64064700	PROTECTION BOOT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64086400	AIR INTAKE GRILLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64086600	PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62790300	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62948400	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	64498600	LH REAR WHEELHOUSE PROTECTION	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	64498700	RH REAR WHEELHOUSE PROTECTION	64498700 RH REAR WHEELHOUSE PROTECTION	-	1	Enquire
-	63870700	L.H. BRACKET	63870700 L.H. BRACKET	-	1	Enquire
-	64060000	L.H. SUPPORT BRACKET	64060000 L.H. SUPPORT BRACKET	-	1	Enquire
-	63739700	L.H. BRACKET	63739700 L.H. BRACKET	-	1	Enquire
-	64699210	COMPLETE REAR BUMPER	64699210 COMPLETE REAR BUMPER Valid for USA	-	1	Enquire
-	64638210	REAR BUMPER -Without stabilizer	64638210 REAR BUMPER -Without stabilizer Valid for USA	-	1	Enquire
-	65055610	COMPLETE REAR BUMPER	65055610 COMPLETE REAR BUMPER Valid for CDN	-	1	Enquire
-	65293710	REAR BUMPER -Without stabilizer	65293710 REAR BUMPER -Without stabilizer Valid for CDN	-	1	Enquire
-	64638110	REAR BUMPER -Without stabilizer-	64638110 REAR BUMPER -Without stabilizer- Not for USA and CDN	-	1	Enquire
1	64089110	COMPLETE REAR BUMPER	64089110 COMPLETE REAR BUMPER Not for USA and CDN	-	1	Enquire
2	64723500	RH BRACKET FOR BUMPER FIXING	64723500 RH BRACKET FOR BUMPER FIXING FIXING	-	1	Enquire
3	64723600	LH BRACKET FOR BUMPER FIXING	64723600 LH BRACKET FOR BUMPER FIXING FIXING	-	1	Enquire
4	63214100	ABSORPTION PAD	63214100 ABSORPTION PAD	-	2	Enquire
5	174159	COMPLETE LH LIGHT LIFTING MOTOR	174159 COMPLETE LH LIGHT LIFTING MOTOR	-	1	Enquire
6	63737200	MOBILE STABILIZER	63737200 MOBILE STABILIZER	-	1	Enquire
7	63739200	SPACER FOR WICK	63739200 SPACER FOR WICK	-	8	Enquire
8	64723700	TRASMISSION PIPE	64723700 TRASMISSION PIPE	-	1	Enquire
9	63739600	R.H. BRACKET	63739600 R.H. BRACKET	-	1	Enquire
10	63739300	SPACER FOR BRACKET	63739300 SPACER FOR BRACKET	-	2	Enquire
11	62794500	THREADED PIN	62794500 THREADED PIN	-	2	Enquire
12	186180	REAR LICENSE PLATE LIGHT	186180 REAR LICENSE PLATE LIGHT	-	2	Enquire
13	64890800	CENTRAL SHIELD	64890800 CENTRAL SHIELD	-	1	Enquire
14	63857700	SEMI-BUSHING	63857700 SEMI-BUSHING	-	4	Enquire
15	63857500	BRACKET FOR SHAFT FIXING	63857500 BRACKET FOR SHAFT FIXING	-	2	Enquire
16	63738000	SUPPORT WHIT FLANGE	63738000 SUPPORT WHIT FLANGE	-	2	Enquire
17	16135724	SCREW	16135724 SCREW	-	4	Enquire
18	16102314	NUT	16102314 NUT	-	4	Enquire
19	84653800	WASHER	84653800 WASHER	-	4	Enquire
20	84653800	WASHER	84653800 WASHER	-	4	Enquire
21	64059900	R.H. SUPPORT BRACKET	64059900 R.H. SUPPORT BRACKET	-	1	Enquire
22	65469000	SUPPORT COMPLETE	65469000 SUPPORT COMPLETE GASKET	-	1	Enquire
23	63870600	R.H. BRACKET	63870600 R.H. BRACKET	-	1	Enquire
24	63737800	PLATE	63737800 PLATE	-	2	Enquire
25	63741000	BUSHING	63741000 BUSHING	-	4	Enquire
26	63186100	SPACER	63186100 SPACER	-	1	Enquire
27	12608574	WASHER	12608574 WASHER	-	1	Enquire
28	12647021	WASHER	12647021 WASHER	-	1	Enquire
29	14040711	NUT M8 FLANGED	14040711 NUT M8 FLANGED	-	1	Enquire
30	64831100	HEAT SHIELDS SERIES	64831100 HEAT SHIELDS SERIES	-	1	Enquire
31	81591700	SCREW	81591700 SCREW	-	2	Enquire
32	10519424	WASHER	10519424 WASHER	-	2	Enquire
33	14084111	NUT	14084111 NUT	-	4	Enquire
34	12643724	WASHER	12643724 WASHER	-	10	Enquire
35	14202782	BLOCK -Valid for SA-	14202782 BLOCK -Valid for SA-	-	2	Enquire
36	319201	FUEL FILLER PIPE ASSEMBLY	319201 FUEL FILLER PIPE ASSEMBLY	-	4	Enquire
37	12638124	WASHER	12638124 WASHER	-	4	Enquire
38	62794800	RUBBER	62794800 RUBBER	-	2	Enquire
39	140594	REAR SIDE-MARKER LIGHT	140594 REAR SIDE-MARKER LIGHT Valid for USA and CDN	-	2	Enquire
40	127494	WASHER	127494 WASHER	-	4	Enquire
41	12648925	WASHER	12648925 WASHER	-	4	Enquire
42	64231400	SCREW	64231400 SCREW	-	2	Enquire
43	11087776	SNAP RING	11087776 SNAP RING	-	4	Enquire
44	319201	FUEL FILLER PIPE ASSEMBLY	319201 FUEL FILLER PIPE ASSEMBLY	-	4	Enquire
45	12638124	WASHER	12638124 WASHER	-	4	Enquire
46	133988	HEX NUT M10 X 1.25 X 8	133988 HEX NUT M10 X 1.25 X 8	-	8	Enquire
47	127497	WASHER	127497 WASHER	-	8	Enquire
48	12626224	WASHER	12626224 WASHER	-	8	Enquire
49	16043021	SCREW	16043021 SCREW	-	4	Enquire
50	14040711	NUT M8 FLANGED	14040711 NUT M8 FLANGED	-	4	Enquire
51	12642777	WASHER -Valid for GTS-	12642777 WASHER -Valid for GTS-	-	4	Enquire
52	10902224	SCREW	10902224 SCREW	-	4	Enquire
53	133988	HEX NUT M10 X 1.25 X 8	133988 HEX NUT M10 X 1.25 X 8	-	2	Enquire
54	12648504	WASHER	12648504 WASHER	-	2	Enquire
55	64064700	PROTECTION BOOT	64064700 PROTECTION BOOT	-	1	Enquire
56	64086400	AIR INTAKE GRILLE	64086400 AIR INTAKE GRILLE	-	1	Enquire
57	64086600	PLATE	64086600 PLATE	-	14	Enquire
58	62790300	NUT	62790300 NUT	-	14	Enquire
59	62948400	WASHER	62948400 WASHER	-	14	Enquire
60	64498600	LH REAR WHEELHOUSE PROTECTION	64498600 LH REAR WHEELHOUSE PROTECTION	-	1	Enquire
