Chassis - Complete Front Structure And Panels

Ferrari 430 Scuderia Spider 16M

Find Your Part

Ferrari 430 Scuderia Spider 16M - CHASSIS - COMPLETE FRONT STRUCTURE AND PANELS

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
65393611 Complete Front Cross Member Enquire To Order
Photo Part No Description Price (each) Stock
68037611 COMPLETE FRONT SUBSTRUCTURE Enquire To Order
69113511 COMPLETE FRONT SUBSTRUCTURE Enquire To Order
Photo Part No Description Price (each) Stock
65393800 R.H. PLATE FOR FRONT HOOD BONNET HINGE Enquire To Order
Photo Part No Description Price (each) Stock
65393900 L.H. PLATE FOR FRONT HOOD BONNET HINGE Enquire To Order
Photo Part No Description Price (each) Stock
985202382 FRONT FIREWALL Enquire To Order
212400 FRONT SHIELD -Valid for GD- Enquire To Order
Photo Part No Description Price (each) Stock
67962711 LUGGAGE COMPARTMENT UPPER REAR WALL Enquire To Order
Photo Part No Description Price (each) Stock
80305811 RH FRONT LATERAL TRELLIS Enquire To Order
Photo Part No Description Price (each) Stock
80305911 LH FRONT LATERAL TRELLIS Enquire To Order
Photo Part No Description Price (each) Stock
67656611 COMPLETE LUGGAGE COMPARTMENT BACK PANEL Enquire To Order
Photo Part No Description Price (each) Stock
14642891 POP RIVET Enquire To Order
Photo Part No Description Price (each) Stock
65133800 RIVET Enquire To Order
Photo Part No Description Price (each) Stock
15180411 Hexagonal Blind Rivet Enquire To Order
248150 ESAGONAL RIVET M8 Enquire To Order
248146 HEXAGONAL RIVET Enquire To Order
...and 2 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
65151200 Rivet Enquire To Order
Photo Part No Description Price (each) Stock
60853400 RIVET Enquire To Order
166101 Knurled Rivet Enquire To Order
65135000 Knurled Rivet Enquire To Order
...and 2 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
65065400 HEXAGONAL HEAD STUD BOLT Enquire To Order
Photo Part No Description Price (each) Stock
13836771 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
80307311 LH. PLATE MOBILE PIPE Enquire To Order
80307211 RH. PLATE MOBILE PIPE Enquire To Order
Photo Part No Description Price (each) Stock
66219811 Luggage Compartment Upper Substructure Shield Enquire To Order
Photo Part No Description Price (each) Stock
67963111 RH FENDER SUPPORT WALL Enquire To Order
Photo Part No Description Price (each) Stock
68031911 LH FENDER SUPPORT WALL Enquire To Order
Photo Part No Description Price (each) Stock
68037611 COMPLETE FRONT SUBSTRUCTURE Enquire To Order
Photo Part No Description Price (each) Stock
65317411 RH BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
65317511 LH BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
70000950 REPAIR INSERTS KIT Enquire To Order
Photo Part No Description Price (each) Stock
65709811 RH HINGE FIXED FASTENING BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
65709911 LH FIXED HINGE FIXED FASTENER BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
69665511 COMPLETE WINDSCREEN UPPER CROSS MEMBER Enquire To Order
Photo Part No Description Price (each) Stock
65548800 PLATE Enquire To Order
Photo Part No Description Price (each) Stock
65897200 NUT Enquire To Order
View All
CHASSIS - COMPLETE FRONT STRUCTURE AND PANELS of Ferrari Ferrari 430 Scuderia Spider 16M Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 65393611
Complete Front Cross Member 		- 1 Enquire
2 68037611
COMPLETE FRONT SUBSTRUCTURE
Not for USA, CDN 		- 1 Enquire
2 69113511
COMPLETE FRONT SUBSTRUCTURE
Applicable for USA, CDN 		- 1 Enquire
3 65393800
R.H. PLATE FOR FRONT HOOD BONNET HINGE 		- 1 Enquire
4 65393900
L.H. PLATE FOR FRONT HOOD BONNET HINGE 		- 1 Enquire
5 985202382
FRONT FIREWALL
Not for GD 		- 1 Enquire
5 212400
FRONT SHIELD -Valid for GD-
Applicable for GD 		- 1 Enquire
6 67962711
LUGGAGE COMPARTMENT UPPER REAR WALL 		- 1 Enquire
7 80305811
RH FRONT LATERAL TRELLIS 		- 1 Enquire
8 80305911
LH FRONT LATERAL TRELLIS 		- 1 Enquire
9 67656611
COMPLETE LUGGAGE COMPARTMENT BACK PANEL 		- 1 Enquire
10 14642891
POP RIVET
L. 14 mm 		- - Enquire
11 65133800
RIVET
L. 6.4 mm 		- - Enquire
12 15180411
Hexagonal Blind Rivet 		- - Enquire
12 248150
ESAGONAL RIVET M8
M8 		- - Enquire
12 248146
HEXAGONAL RIVET
M6 		- - Enquire
12 15624311
HEXAGONAL RIVET
M5 		- - Enquire
12 15624211
Hexagonal Rivet
M4 		- - Enquire
13 65151200
Rivet
M6 		- - Enquire
14 60853400
RIVET 		- - Enquire
14 166101
Knurled Rivet
M4 		- - Enquire
14 65135000
Knurled Rivet
M8 		- - Enquire
14 65930400
Knurled Rivet
M6 		- - Enquire
14 65319800
Nut Knurled Rivet
M5 		- - Enquire
15 65065400
HEXAGONAL HEAD STUD BOLT
M6 		- - Enquire
16 13836771
SCREW 		- - Enquire
17 80307311
LH. PLATE MOBILE PIPE 		- 1 Enquire
17 80307211
RH. PLATE MOBILE PIPE 		- 1 Enquire
18 66219811
Luggage Compartment Upper Substructure Shield 		- 1 Enquire
19 67963111
RH FENDER SUPPORT WALL 		- 1 Enquire
20 68031911
LH FENDER SUPPORT WALL 		- 1 Enquire
21 68037611
COMPLETE FRONT SUBSTRUCTURE
No longer supplied 		- 1 Enquire
22 65317411
RH BRACKET 		- 1 Enquire
23 65317511
LH BRACKET 		- 1 Enquire
24 70000950
REPAIR INSERTS KIT 		- 1 Enquire
26 65709811
RH HINGE FIXED FASTENING BRACKET 		- 1 Enquire
27 65709911
LH FIXED HINGE FIXED FASTENER BRACKET 		- 1 Enquire
28 69665511
COMPLETE WINDSCREEN UPPER CROSS MEMBER
Applicable for Spider 16M 		- 1 Enquire
29 65548800
PLATE 		- 2 Enquire
30 65897200
NUT 		- 4 Enquire
