DRIVING SHAFT - CONNECTING RODS ANO PISTONS of Ferrari Ferrari 355 (2.7 Motronic)

View All

Ferrari 355 (2.7 Motronic) - DRIVING SHAFT - CONNECTING RODS ANO PISTONS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	155119	CRANKSHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	163528	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164098	FRONT AND REAR UPPER HALF	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	COMPLETESETONLY	LOWER SHIM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164101	UPPER INTERMEDIATE HALF BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164099	INTERMEDIATE LOWER HALF BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	146111	UPPER SHIM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164108	LOWER SHIM RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	151289	KEY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	146911	OIL PUMP CONTROL GEAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	160807	COMPLETE TOOTHED WHEEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10841010	DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148671	SEAL RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	183581	Rear Crankshaft Oil Seal	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155562	COMPLETE CONNECTING ROD AND CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159141	PISTON WITH RINGS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	160813	AC SEAL RING (1st groove)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164026	PISTONS RINGS SET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	132773	ROF OIL SCRAPING RING (3rd groove)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154717	GUDGEON PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	166901	STOP RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	202389	CONNECTING ROD HALF BEARING	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	166564	1st undersize 0.254 mm on Ø	166564 1st undersize 0.254 mm on Ø BEARING / 1st UNDERSIZE mm. 0,254	-	16	Enquire
-	166565	2nd undersize 0.508 mm on Ø	166565 2nd undersize 0.508 mm on Ø BEARING / 2nd UNDERSIZE mm. 0,508	-	16	Enquire
-	166901	STOP RING	166901 STOP RING Replaces 152993	-	16	Enquire
-	164026	PISTONS RINGS SET	164026 PISTONS RINGS SET	-	8	Enquire
-	158186	CONNECTING ROD TIGHTENING SCREW	158186 CONNECTING ROD TIGHTENING SCREW TIGHTENING SCREW	-	16	Enquire
-	155097	BUSHING	155097 BUSHING	-	8	Enquire
-	160807	COMPLETE TOOTHED WHEEL	160807 COMPLETE TOOTHED WHEEL Valid after stock exhaustion of 160827	-	1	Enquire
-	164109	LOWER SHIM RING	164109 LOWER SHIM RING 1st OVERSIZE mm. 0,127 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164110	LOWER SHIM RING	164110 LOWER SHIM RING 2nd OVERSIZE mm. 0,254 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164112	UPPER SHIM RING	164112 UPPER SHIM RING 1st OVERSIZE mm. 0,127 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164113	UPPER SHIM RING	164113 UPPER SHIM RING 2nd OVERSIZE mm. 0,254 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164950	INTERMEDIATE LOWER HALF BEARING	164950 INTERMEDIATE LOWER HALF BEARING BEARING / 1st UNDERSIZE mm. 0,254 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164951	INTERMEDIATE LOWER HALF BEARING	164951 INTERMEDIATE LOWER HALF BEARING BEARING / 2nd UNDERSIZE mm. 0,508 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164957	UPPER INTEMEDIATE HALF BEARING	164957 UPPER INTEMEDIATE HALF BEARING BEARING / 2nd UNDERSIZE mm. 0,508 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164956	UPPER INTERMEDIATE HALF BEARING	164956 UPPER INTERMEDIATE HALF BEARING BEARING / 1st UNDERSIZE mm. 0,254 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164954	FRONT AND REAR LOWER HALF	164954 FRONT AND REAR LOWER HALF 2nd UNDERSIZE mm. 0,508 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164947	FRONT AND REAR UPPER HALF	164947 FRONT AND REAR UPPER HALF 2nd UNDERSIZE mm. 0,508 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164953	FRONT AND REAR LOWER HALF	164953 FRONT AND REAR LOWER HALF 1st UNDERSIZE mm. 0,254 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	164946	FRONT AND REAR UPPER HALF	164946 FRONT AND REAR UPPER HALF 1st UNDERSIZE mm. 0,254 / Not as spare part / With the half-bearings complete series	-	-	Enquire
-	170930	HALF-BEARINGS COMPLETE SERIES	170930 HALF-BEARINGS COMPLETE SERIES 2nd UNDERSIZE mm. 0,508 / See tecnical information / ofS.A.T. N.717	-	1	Enquire
-	163528	THREADED PLUG	163528 THREADED PLUG Replaces 10268450	-	1	Enquire
-	204886	HALF-BEARINGS COMPLETE SERIES - STANDARD SIZE	204886 HALF-BEARINGS COMPLETE SERIES - STANDARD SIZE STANDARD SIZE / See tecnical information / of S.A.T. N.717	-	1	Enquire
-	170929	HALF-BEARINGS COMPLETE SERIES	170929 HALF-BEARINGS COMPLETE SERIES 1st UNDERSIZE mm. 0,254 / See tecnical information / ofS.A.T. N.717	-	1	Enquire
1	155119	CRANKSHAFT	155119 CRANKSHAFT See tecnical information / of SAT. N.717	-	1	Enquire
2	163528	THREADED PLUG	163528 THREADED PLUG Replaced by 163528	-	1	Enquire
3	164098	FRONT AND REAR UPPER HALF	164098 FRONT AND REAR UPPER HALF Not as spare part / With the half-bearings complete series	-	2	Enquire
4	COMPLETESETONLY	LOWER SHIM	COMPLETESETONLY LOWER SHIM Not as spare part / With the half-bearings complete series	-	2	Enquire
5	164101	UPPER INTERMEDIATE HALF BEARING	164101 UPPER INTERMEDIATE HALF BEARING BEARING / Not as spare part / With the half-bearings complete series	-	3	Enquire
6	164099	INTERMEDIATE LOWER HALF BEARING	164099 INTERMEDIATE LOWER HALF BEARING BEARING / Not as spare part / With the half-bearings complete series	-	3	Enquire
7	146111	UPPER SHIM	146111 UPPER SHIM Not as spare part / With the half-bearings complete series	-	2	Enquire
8	164108	LOWER SHIM RING	164108 LOWER SHIM RING Not as spare part / With the half-bearings complete series	-	2	Enquire
9	151289	KEY	151289 KEY	-	1	Enquire
10	146911	OIL PUMP CONTROL GEAR	146911 OIL PUMP CONTROL GEAR GEAR	-	1	Enquire
11	160807	COMPLETE TOOTHED WHEEL	160807 COMPLETE TOOTHED WHEEL	-	1	Enquire
12	10841010	DOWEL	10841010 DOWEL	-	1	Enquire
13	148671	SEAL RING	148671 SEAL RING	-	1	Enquire
14	183581	Rear Crankshaft Oil Seal	183581 Rear Crankshaft Oil Seal	-	1	Enquire
15	155562	COMPLETE CONNECTING ROD AND CAP	155562 COMPLETE CONNECTING ROD AND CAP AND CAP	-	8	Enquire
16	159141	PISTON WITH RINGS	159141 PISTON WITH RINGS	-	8	Enquire
17	160813	AC SEAL RING (1st groove)	160813 AC SEAL RING (1st groove) Not as spare part / With the pistons rings set	-	8	Enquire
18	164026	PISTONS RINGS SET	164026 PISTONS RINGS SET Not as spare part / With the pistons rings set	-	8	Enquire
19	132773	ROF OIL SCRAPING RING (3rd groove)	132773 ROF OIL SCRAPING RING (3rd groove) (3rd groove) / Not as spare part / With the pistons rings set	-	8	Enquire
20	154717	GUDGEON PIN	154717 GUDGEON PIN	-	8	Enquire
21	166901	STOP RING	166901 STOP RING Not spare part now replaced by / 166901	-	16	Enquire
25	202389	CONNECTING ROD HALF BEARING	202389 CONNECTING ROD HALF BEARING BEARING	-	16	Enquire
