Ferrari 296 GTS USA - OTHER ELECTRICAL CONTROLS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	981516	COMPL. POWER WINDOW BUTTON BEZEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14418074	SCREW	Enquire	To Order
	14418074	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12639901	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	163675	INERTIA SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	764154	UPPER BLANKING CAP ON RH DOOR GRAB HANDLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	764140	UPPER BLANKING CAP ON LH DOOR GRAB HANDLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14418074	SCREW	Enquire	To Order
	14418074	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14418074	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	905814	LUGGAGE COMPARTMENT LID AND FUEL FILLER FLAP RELEASE BUTTONS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	319574	MEMORY BUTTONS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	188266	GLOVE COMPARTMENT LIGHT BUTTON	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	286443	AIR VENT CONTROL	Enquire	To Order
	82893600	AIR VENT CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	286444	AIR VENT CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	934275	INSTRUMENT FUNCTION CONTROL	Enquire	To Order
	965154	INSTRUMENT FUNCTION CONTROL	Enquire	To Order
	965154	INSTRUMENT FUNCTION CONTROL	Enquire	To Order

...and 21 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	769368	AC CONTROL PANEL	Enquire	To Order
	769355	AC CONTROL PANEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14418924	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	899480	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	319555	EPB SWITCH WITH AUTOPARK DISABLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	88822200	SCREW TORX HEAD M4 X 10MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	193862	STEERING COLUMN ADJUSTMENT CONTROL	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	981516	COMPL. POWER WINDOW BUTTON BEZEL	981516 COMPL. POWER WINDOW BUTTON BEZEL	-	1	Enquire
0002	85833700	SCREW	85833700 SCREW M5 X 10	-	10	Enquire
0003	14418074	SCREW	14418074 SCREW M3 X 8	-	2	Enquire
0003	14418074	SCREW	14418074 SCREW M3 X 8	-	2	Enquire
0004	12639901	WASHER	12639901 WASHER	-	6	Enquire
0005	163675	INERTIA SWITCH	163675 INERTIA SWITCH	-	1	Enquire
0006	764154	UPPER BLANKING CAP ON RH DOOR GRAB HANDLE	764154 UPPER BLANKING CAP ON RH DOOR GRAB HANDLE	-	1	Enquire
0007	764140	UPPER BLANKING CAP ON LH DOOR GRAB HANDLE	764140 UPPER BLANKING CAP ON LH DOOR GRAB HANDLE	-	1	Enquire
0008	14418074	SCREW	14418074 SCREW M3 X 10	-	1	Enquire
0008	14418074	SCREW	14418074 SCREW M3 X 8	-	8	Enquire
0009	14418074	SCREW	14418074 SCREW M3 X 8	-	2	Enquire
0010	905814	LUGGAGE COMPARTMENT LID AND FUEL FILLER FLAP RELEASE BUTTONS	905814 LUGGAGE COMPARTMENT LID AND FUEL FILLER FLAP RELEASE BUTTONS	-	1	Enquire
0011	319574	MEMORY BUTTONS	319574 MEMORY BUTTONS Applicable for full electric seats or full electric seats with ventilation	-	1	Enquire
0012	188266	GLOVE COMPARTMENT LIGHT BUTTON	188266 GLOVE COMPARTMENT LIGHT BUTTON	-	1	Enquire
0013	286443	AIR VENT CONTROL	286443 AIR VENT CONTROL	-	2	Enquire
0013	82893600	AIR VENT CONTROL	82893600 AIR VENT CONTROL	-	2	Enquire
0014	286444	AIR VENT CONTROL	286444 AIR VENT CONTROL	-	2	Enquire
0015	934275	INSTRUMENT FUNCTION CONTROL	934275 INSTRUMENT FUNCTION CONTROL Base	-	1	Enquire
0015	965154	INSTRUMENT FUNCTION CONTROL	965154 INSTRUMENT FUNCTION CONTROL Version with rear parking camera or surround view	-	1	Enquire
0015	965154	INSTRUMENT FUNCTION CONTROL	965154 INSTRUMENT FUNCTION CONTROL	-	1	Enquire
0015	965154	INSTRUMENT FUNCTION CONTROL	965154 INSTRUMENT FUNCTION CONTROL	-	1	Enquire
0015	965155	INSTRUMENT FUNCTION CONTROL	965155 INSTRUMENT FUNCTION CONTROL Applicable for front parking sensors	-	1	Enquire
0015	965157	INSTRUMENT FUNCTION CONTROL	965157 INSTRUMENT FUNCTION CONTROL Version with lift system - Not for Assetto Fiorano FIO2	-	1	Enquire
0015	965156	INSTRUMENT FUNCTION CONTROL	965156 INSTRUMENT FUNCTION CONTROL Applicable for front parking sensors and lift system - Not for Assetto Fiorano FIO2	-	1	Enquire
0015	965158	INSTRUMENT FUNCTION CONTROL	965158 INSTRUMENT FUNCTION CONTROL Version with rear parking camera and lift system or surround view and lift system - Not for Assetto Fiorano FIO2	-	1	Enquire
0015	965158	INSTRUMENT FUNCTION CONTROL	965158 INSTRUMENT FUNCTION CONTROL	-	1	Enquire
0015	965158	INSTRUMENT FUNCTION CONTROL	965158 INSTRUMENT FUNCTION CONTROL	-	1	Enquire
0015	965159	INSTRUMENT FUNCTION CONTROL	965159 INSTRUMENT FUNCTION CONTROL Version with front parking sensors and surround view or with rear parking camera and front parking sensors	-	1	Enquire
0015	965159	INSTRUMENT FUNCTION CONTROL	965159 INSTRUMENT FUNCTION CONTROL	-	1	Enquire
0015	965159	INSTRUMENT FUNCTION CONTROL	965159 INSTRUMENT FUNCTION CONTROL	-	1	Enquire
0015	965160	INSTRUMENT FUNCTION CONTROL	965160 INSTRUMENT FUNCTION CONTROL Version with front parking sensors, surround view and lift system or with rear parking camera and front parking sensors and lift system - Not for Assetto Fiorano FIO2	-	1	Enquire
0015	965160	INSTRUMENT FUNCTION CONTROL	965160 INSTRUMENT FUNCTION CONTROL	-	1	Enquire
0015	965160	INSTRUMENT FUNCTION CONTROL	965160 INSTRUMENT FUNCTION CONTROL	-	1	Enquire
0015	926151	INSTRUMENT FUNCTION CONTROL	926151 INSTRUMENT FUNCTION CONTROL	-	1	Enquire
0015	965150	INSTRUMENT FUNCTION CONTROL	965150 INSTRUMENT FUNCTION CONTROL Version with lift system - Not for Assetto Fiorano FIO2	-	1	Enquire
0015	965147	INSTRUMENT FUNCTION CONTROL	965147 INSTRUMENT FUNCTION CONTROL Version with rear parking camera or surround view	-	1	Enquire
0015	965151	INSTRUMENT FUNCTION CONTROL	965151 INSTRUMENT FUNCTION CONTROL Version with rear parking camera and lift system or surround view and lift system - Not for Assetto Fiorano FIO2	-	1	Enquire
0015	965148	INSTRUMENT FUNCTION CONTROL	965148 INSTRUMENT FUNCTION CONTROL Applicable for front parking sensors	-	1	Enquire
0015	965149	INSTRUMENT FUNCTION CONTROL	965149 INSTRUMENT FUNCTION CONTROL Applicable for front parking sensors and lift system - Not for Assetto Fiorano FIO2	-	1	Enquire
0015	965152	INSTRUMENT FUNCTION CONTROL	965152 INSTRUMENT FUNCTION CONTROL Version with front parking sensors and surround view or with rear parking camera and front parking sensors	-	1	Enquire
0015	965153	INSTRUMENT FUNCTION CONTROL	965153 INSTRUMENT FUNCTION CONTROL Version with front parking sensors, surround view and lift system or with rear parking camera and front parking sensors and lift system - Not for Assetto Fiorano FIO2	-	1	Enquire
0016	769368	AC CONTROL PANEL	769368 AC CONTROL PANEL	-	1	Enquire
0016	769355	AC CONTROL PANEL	769355 AC CONTROL PANEL	-	1	Enquire
0017	14418924	SCREW	14418924 SCREW M4 X 8	-	4	Enquire
0018	899480	NUT	899480 NUT M4 X 3,2	-	6	Enquire
0019	319555	EPB SWITCH WITH AUTOPARK DISABLE	319555 EPB SWITCH WITH AUTOPARK DISABLE	-	1	Enquire
0020	88822200	SCREW TORX HEAD M4 X 10MM	88822200 SCREW TORX HEAD M4 X 10MM M4 X 10	-	3	Enquire
0021	193862	STEERING COLUMN ADJUSTMENT CONTROL	193862 STEERING COLUMN ADJUSTMENT CONTROL Applicable for full electric seats	-	1	Enquire
