Name: ENGINE COVERS
Rating: 5.0 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	920136	TIMING COVER COMPLETE WITH PREASSEMBLED PUMP	$3,061.85	To Order
	990072	TIMING COVER COMPLETE WITH PREASSEMBLED PUMP	$3,036.05	To Order

Photo	Part No	Description	Price (each)	Stock
	255494	SCREW	$9.60	To Order

Photo	Part No	Description	Price (each)	Stock
	262913	THERMOSTAT/PRESSURE SWITCH	$272.77	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SCREW	$0.31	To Order

Photo	Part No	Description	Price (each)	Stock
	806488	GASKET	$78.61	To Order

Photo	Part No	Description	Price (each)	Stock
	810696	HOSE	$71.66	To Order

Photo	Part No	Description	Price (each)	Stock
	14300524	SCREW	$1.77	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WASHER	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	180137	TEMPERATURE SENSOR	$30.23	To Order

Photo	Part No	Description	Price (each)	Stock
	825475	WATER DELIVERY PIPE	$31.52	To Order

Photo	Part No	Description	Price (each)	Stock
	287632	O-RING	$3.23	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	$0.32	To Order

Photo	Part No	Description	Price (each)	Stock
	14459581	O-RING	$2.43	To Order

Photo	Part No	Description	Price (each)	Stock
	14459081	GASKET	$2.43	To Order

Photo	Part No	Description	Price (each)	Stock
	14458381	O-RING	$1.36	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SCREW	$0.31	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
0001	920136	TIMING COVER COMPLETE WITH PREASSEMBLED PUMP	920136 TIMING COVER COMPLETE WITH PREASSEMBLED PUMP Applies until depletion	$3,061.85	1
0001	990072	TIMING COVER COMPLETE WITH PREASSEMBLED PUMP	990072 TIMING COVER COMPLETE WITH PREASSEMBLED PUMP Applicable after depletion of 920136	$3,036.05	1
0002	255494	SCREW	255494 SCREW M6 X 55	$9.60	7
0003	262913	THERMOSTAT/PRESSURE SWITCH	262913 THERMOSTAT/PRESSURE SWITCH	$272.77 MSRP: ~~360.40~~ (24.3% off)	1
0004	231619	SCREW	231619 SCREW M6 X 22	$0.31	9
0005	806488	GASKET	806488 GASKET Also included in engine gasket set	$78.61	1
0006	810696	HOSE	810696 HOSE	$71.66	1
0007	14300524	SCREW	14300524 SCREW M6 X 75	$1.77	2
0008	11197774	WASHER	11197774 WASHER	$0.06 MSRP: ~~0.30~~ (80% off)	2
0009	180137	TEMPERATURE SENSOR	180137 TEMPERATURE SENSOR	$30.23 MSRP: ~~32.99~~ (8.4% off)	1
0010	825475	WATER DELIVERY PIPE	825475 WATER DELIVERY PIPE	$31.52	1
0011	287632	O-RING	287632 O-RING	$3.23	2
0012	231620	SCREW	231620 SCREW M6 X 30	$0.32 MSRP: ~~0.35~~ (8.6% off)	36
0013	14459581	O-RING	14459581 O-RING Also included in engine gasket set	$2.43	2
0014	14459081	GASKET	14459081 GASKET Also included in engine gasket set	$2.43	2
0015	14458381	O-RING	14458381 O-RING Also included in engine gasket set	$1.36	2
0016	231619	SCREW	231619 SCREW M6 X 18	$0.31	1
