BATTERIES

Find Your Part

Ferrari 296 GTB USA - BATTERIES

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
766996 HVB BATTERY $20,398.87 To Order
Photo Part No Description Price (each) Stock
962530 SCREW $3.32 To Order
Photo Part No Description Price (each) Stock
962531 SCREW $3.13 To Order
Photo Part No Description Price (each) Stock
966818 LITHIUM BATTERY $3,094.65 To Order
949042 BATTERY $757.71 To Order
966818 LITHIUM BATTERY $3,094.65 To Order
Photo Part No Description Price (each) Stock
840964 VENTING PIPE $121.82 To Order
884483 VENTING PIPE $154.03 To Order
950103 BATTERY VENT $30.08 To Order
...and 3 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
935783 VENTING BLOCK $73.08 To Order
950118 BATTERY VENT BLOCK $81.69 To Order
935783 VENTING BLOCK $73.08 To Order
Photo Part No Description Price (each) Stock
817742 VENTING PIPE FLANGE GASKET $45.01 To Order
817742 VENTING PIPE FLANGE GASKET $45.01 To Order
Photo Part No Description Price (each) Stock
62797600 Allen Bolt Countersunk M6 x 20 $1.10 To Order
Photo Part No Description Price (each) Stock
322605 SPACER $2.25 To Order
Photo Part No Description Price (each) Stock
310112 CLIP $0.65 To Order
Photo Part No Description Price (each) Stock
199631 CONNECTOR $0.42 To Order
Photo Part No Description Price (each) Stock
779107 LEAD ACID BATTERY INSTALLATION KIT $78.82 To Order
Photo Part No Description Price (each) Stock
834740 BATTERY BREATHER CAP $1.10 To Order
Photo Part No Description Price (each) Stock
859545 TEMPERATURE SENSOR $87.51 To Order
View All
BATTERIES of Ferrari Ferrari 296 GTB USA Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 766996
HVB BATTERY
See TI 2932 		$20,398.87 1
0002 962530
SCREW
M10 X 1.25 X 40 		$3.32 4
0003 962531
SCREW
M10 X 1.25 X 30 		$3.13 2
0004 966818
LITHIUM BATTERY
40 Ah - With 30% charge - Version for lithium battery - After depletion of stock, order lead acid battery 949042, see TI 2950 for installation; Applies until depletion 		$3,094.65 1
0004 949042
BATTERY
50 Ah - Version for lead battery - See TI 2950 for installation procedure for lead acid battery; Applicable after depletion of 966818 		$757.71 1
0004 966818
LITHIUM BATTERY 		$3,094.65 1
0005 840964
VENTING PIPE
Version for lithium battery 		$121.82 1
0005 884483
VENTING PIPE
Version for lithium battery 		$154.03 1
0005 950103
BATTERY VENT
Version for lead battery 		$30.08 1
0005 950678
BATTERY VENT
Version for lead battery 		$30.08 1
0005 840964
VENTING PIPE 		$121.82 1
0005 884483
VENTING PIPE 		$154.03 1
0006 935783
VENTING BLOCK
Version for lithium battery 		$73.08 1
0006 950118
BATTERY VENT BLOCK
Version for lead battery - Also included with lead acid battery installation kit 		$81.69 1
0006 935783
VENTING BLOCK 		$73.08 1
0007 817742
VENTING PIPE FLANGE GASKET
Version for lithium battery 		$45.01 1
0007 817742
VENTING PIPE FLANGE GASKET 		$45.01 1
0008 62797600
Allen Bolt Countersunk M6 x 20
M5 X 10 		$1.10 (24.1% off) 2
0009 322605
SPACER
Version for lead battery - Also included with lead acid battery installation kit 		$2.25 1
0010 310112
CLIP
Version for lead battery - Also included with lead acid battery installation kit; 1 compartment- 		$0.65 1
0011 199631
CONNECTOR
Version for lead battery - Also included with lead acid battery installation kit 		$0.42 1
0012 779107
LEAD ACID BATTERY INSTALLATION KIT 		$78.82 1
0013 834740
BATTERY BREATHER CAP
Version for lead battery - Also included with lead acid battery installation kit 		$1.10 1
0014 859545
TEMPERATURE SENSOR 		$87.51 2
