Anti-Theft System

Ferrari 296 GTB Europe RH

Find Your Part

Ferrari 296 GTB Europe RH - ANTI-THEFT SYSTEM

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
336779 COMPL. ANTI-THEFT SYSTEM SIREN Enquire To Order
Photo Part No Description Price (each) Stock
333337 GSM MICROPHONE Enquire To Order
333337 GSM MICROPHONE Enquire To Order
333337 GSM MICROPHONE Enquire To Order
Photo Part No Description Price (each) Stock
895549 KEY SCREWDRIVER-RING KIT Enquire To Order
Photo Part No Description Price (each) Stock
332825 GLONASS SPEAKER Enquire To Order
332825 GLONASS SPEAKER Enquire To Order
Photo Part No Description Price (each) Stock
965601 SPEAKER COVER Enquire To Order
965601 SPEAKER COVER Enquire To Order
818342 SPEAKER COVER Enquire To Order
Photo Part No Description Price (each) Stock
818431 GLONASS ECU Enquire To Order
956025 E-CALL TCU Enquire To Order
824396 TCU ECALL / SVR Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
741711 ERA GLONASS ECU BRACKET Enquire To Order
741711 ERA GLONASS ECU BRACKET Enquire To Order
741711 ERA GLONASS ECU BRACKET Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
85833700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
824398 RF ANTENNA Enquire To Order
Photo Part No Description Price (each) Stock
336506 GLONASS GPS ANTENNA Enquire To Order
336506 GLONASS GPS ANTENNA Enquire To Order
336506 GLONASS GPS ANTENNA Enquire To Order
Photo Part No Description Price (each) Stock
336507 GLONASS GSM ANTENNA Enquire To Order
336507 GLONASS GSM ANTENNA Enquire To Order
336507 GLONASS GSM ANTENNA Enquire To Order
Photo Part No Description Price (each) Stock
925991 PASSIVE START ANTENNA Enquire To Order
935814 PASSIVE START ANTENNA Enquire To Order
Photo Part No Description Price (each) Stock
839378 PASSIVE START ECU Enquire To Order
940501 PASSIVE START ECU Enquire To Order
Photo Part No Description Price (each) Stock
16285227 SCREW M5 X 20 Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire To Order
Photo Part No Description Price (each) Stock
775528 PASSIVE ENTRY RF ANTENNA CABLE Enquire To Order
775528 PASSIVE ENTRY RF ANTENNA CABLE Enquire To Order
912307 RF ANTENNA CABLE Enquire To Order
Photo Part No Description Price (each) Stock
829636 COMPL. E-CALL CONTROL Enquire To Order
829636 COMPL. E-CALL CONTROL Enquire To Order
829636 COMPL. E-CALL CONTROL Enquire To Order
Photo Part No Description Price (each) Stock
85833700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
293416 ANTI-LIFT SENSOR Enquire To Order
Photo Part No Description Price (each) Stock
88831000 GRUB SCREW Enquire To Order
Photo Part No Description Price (each) Stock
902033 SPACER Enquire To Order
Photo Part No Description Price (each) Stock
310778 PASSIVE START ANTENNA Enquire To Order
Photo Part No Description Price (each) Stock
85833700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
953697 WRENCH Enquire To Order
953698 WRENCH Enquire To Order
953699 WRENCH Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
865296 KEY FOB Enquire To Order
865295 KEY FOB Enquire To Order
923359 KEY FOB Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
865301 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
916407 LUGGAGE COMPARTMENT TUB SPLITTER Enquire To Order
916407 LUGGAGE COMPARTMENT TUB SPLITTER Enquire To Order
916407 LUGGAGE COMPARTMENT TUB SPLITTER Enquire To Order
Photo Part No Description Price (each) Stock
766328 WRENCH BIT Enquire To Order
Photo Part No Description Price (each) Stock
6326163 SECRET CARD LABEL FOR KEYS Enquire To Order
Photo Part No Description Price (each) Stock
772851 KEY AND BLOCK KIT Enquire To Order
Photo Part No Description Price (each) Stock
824397 DRIVER CARD Enquire To Order
Photo Part No Description Price (each) Stock
766286 KEY AND BLOCK KIT Enquire To Order
Photo Part No Description Price (each) Stock
85833700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
907909 NPE-SPLITTER CABLE Enquire To Order
907909 NPE-SPLITTER CABLE Enquire To Order
907909 NPE-SPLITTER CABLE Enquire To Order
Photo Part No Description Price (each) Stock
865300 KEY RING Enquire To Order
Photo Part No Description Price (each) Stock
925517 SCREWDRIVER ADAPTER Enquire To Order
View All
ANTI-THEFT SYSTEM of Ferrari Ferrari 296 GTB Europe RH Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 336779
COMPL. ANTI-THEFT SYSTEM SIREN 		- 1 Enquire
0002 333337
GSM MICROPHONE
Applicable for E-CALL system - Version with SVR satellite alarm system with or without card 		- 1 Enquire
0002 333337
GSM MICROPHONE 		- 1 Enquire
0002 333337
GSM MICROPHONE 		- 1 Enquire
0003 895549
KEY SCREWDRIVER-RING KIT 		- 1 Enquire
0004 332825
GLONASS SPEAKER
Applicable for E-CALL system 		- 1 Enquire
0004 332825
GLONASS SPEAKER 		- 1 Enquire
0005 965601
SPEAKER COVER
Applicable for E-CALL system 		- 1 Enquire
0005 965601
SPEAKER COVER 		- 1 Enquire
0005 818342
SPEAKER COVER
Applicable for E-CALL system 		- 1 Enquire
0006 818431
GLONASS ECU
No longer supplied - Replaced by -; Unprogrammed 		- 1 Enquire
0006 956025
E-CALL TCU
Applicable for E-CALL system - Applicable for UAE only 		- 1 Enquire
0006 824396
TCU ECALL / SVR
Applicable for E-CALL system - Version with SVR satellite alarm system with or without card - Not for Turkey 		- 1 Enquire
0006 956023
E-CALL TCU
Specific for Turkey - Applicable for E-CALL system 		- 1 Enquire
0007 741711
ERA GLONASS ECU BRACKET
Applicable for E-CALL system - Version with SVR satellite alarm system with or without card 		- 1 Enquire
0007 741711
ERA GLONASS ECU BRACKET 		- 1 Enquire
0007 741711
ERA GLONASS ECU BRACKET 		- 1 Enquire
0007 791164
COMPL. ANTI-THEFT SYSTEM ECU BRACKET
Applicable for E-CALL system - Version with SVR satellite alarm system with or without card 		- 1 Enquire
0008 85833700
SCREW
M5 X 14 		- 4 Enquire
0009 824398
RF ANTENNA
Version with satellite alarm system with card 		- 1 Enquire
0010 336506
GLONASS GPS ANTENNA
Applicable for E-CALL system - Version with SVR satellite alarm system with or without card 		- 1 Enquire
0010 336506
GLONASS GPS ANTENNA 		- 1 Enquire
0010 336506
GLONASS GPS ANTENNA 		- 1 Enquire
0011 336507
GLONASS GSM ANTENNA
Applicable for E-CALL system - Version with SVR satellite alarm system with or without card 		- 1 Enquire
0011 336507
GLONASS GSM ANTENNA 		- 1 Enquire
0011 336507
GLONASS GSM ANTENNA 		- 1 Enquire
0012 925991
PASSIVE START ANTENNA 		- 1 Enquire
0012 935814
PASSIVE START ANTENNA 		- 1 Enquire
0013 839378
PASSIVE START ECU 		- 1 Enquire
0013 940501
PASSIVE START ECU 		- 1 Enquire
0014 16285227
SCREW M5 X 20
M5 X 20 		- 1 Enquire
0015 14059290
FLANGED NUT M6 		- 1 Enquire
0016 775528
PASSIVE ENTRY RF ANTENNA CABLE 		- 1 Enquire
0016 775528
PASSIVE ENTRY RF ANTENNA CABLE 		- 1 Enquire
0016 912307
RF ANTENNA CABLE 		- 1 Enquire
0017 829636
COMPL. E-CALL CONTROL
Applicable for E-CALL system - Version with SVR satellite alarm system with or without card 		- 1 Enquire
0017 829636
COMPL. E-CALL CONTROL 		- 1 Enquire
0017 829636
COMPL. E-CALL CONTROL 		- 1 Enquire
0018 85833700
SCREW
M5 X 10 		- 6 Enquire
0019 293416
ANTI-LIFT SENSOR 		- 1 Enquire
0020 88831000
GRUB SCREW
M5 X 30 		- 2 Enquire
0021 902033
SPACER 		- 2 Enquire
0022 310778
PASSIVE START ANTENNA 		- 4 Enquire
0023 85833700
SCREW
M5 X 12 		- 2 Enquire
0024 953697
WRENCH
Leather 		- 1 Enquire
0024 953698
WRENCH
Leather 		- 1 Enquire
0024 953699
WRENCH
Carbon version; Leather 		- 1 Enquire
0024 953700
WRENCH
Carbon version; Leather 		- 1 Enquire
0025 865296
KEY FOB
Plastic 		- 1 Enquire
0025 865295
KEY FOB
Yellow 		- 1 Enquire
0025 923359
KEY FOB
Grey 		- 1 Enquire
0025 865703
KEY FOB
Carbon version 		- 1 Enquire
0026 865301
SCREW 		- 4 Enquire
0027 916407
LUGGAGE COMPARTMENT TUB SPLITTER
Applicable for version in carbon fibre 		- 1 Enquire
0027 916407
LUGGAGE COMPARTMENT TUB SPLITTER 		- 1 Enquire
0027 916407
LUGGAGE COMPARTMENT TUB SPLITTER 		- 1 Enquire
0028 766328
WRENCH BIT 		- 1 Enquire
0029 6326163
SECRET CARD LABEL FOR KEYS 		- 1 Enquire
0030 772851
KEY AND BLOCK KIT
Manage the loose components; No longer supplied; Contains: 1 key, 2 ignition switch blocks and 1 CODE CARD 		- 1 Enquire
0031 824397
DRIVER CARD
Version with satellite alarm system with card - Request ASM authorisation 		- 1 Enquire
0032 766286
KEY AND BLOCK KIT
Contains: 1 wrench and 2 blocks 		- 1 Enquire
0033 85833700
SCREW
M5 X 16 		- 2 Enquire
0034 907909
NPE-SPLITTER CABLE
Applicable for version in carbon fibre 		- 1 Enquire
0034 907909
NPE-SPLITTER CABLE 		- 1 Enquire
0034 907909
NPE-SPLITTER CABLE 		- 1 Enquire
0035 865300
KEY RING 		- 2 Enquire
0036 925517
SCREWDRIVER ADAPTER 		- 1 Enquire
