Rear seat frame of Bentley Bentley New Flying Spur (2020-2024)

View All

Bentley New Flying Spur (2020-2024) - Rear seat frame (885005)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4N0885511B	backrest frame	Enquire
	4N0885512B	backrest frame	Enquire

Photo	Part No	Description	Price (each)	Stock
	4N0885111	Rear seat frame	Enquire
	4N0885112	Rear seat frame	Enquire

Photo	Part No	Description	Price (each)	Stock
	WHT004970	Clamping bolt	Enquire

Photo	Part No	Description	Price (each)	Stock
	3Y5885547	clamping ring D >> - 05.09.2023	Enquire
	3Y5885547A	clamping ring	Enquire

Photo	Part No	Description	Price (each)	Stock
	N98923402	Hexagon collar nut	Enquire

Photo	Part No	Description	Price (each)	Stock
	N91134301	Int. serration flange screw	$2.21	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0937545G	Clutch carrier	Enquire	IN STOCK
	4N0937546G	Clutch carrier	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0886879A	Module support with air cushions for low. back support	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N90737803	Hexagon socket flat head bolt	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4H0941117	Securing element	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0963575A	ventliation motor D - 01.04.2019>>	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0886920B	guide for head restraint, adjustable	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	3SE886203A	Supporting bracket D >> - 04.07.2023	Enquire	IN STOCK
	3SE886203B	Supporting bracket	Enquire	IN STOCK
	3SE886204A	Supporting bracket D >> - 04.07.2023	Enquire	IN STOCK

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	N90698606	Hexagon socket head panel bolt	$0.92	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	3SE886223B	Gap cover	Enquire	IN STOCK
	3SE886224B	Gap cover	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N90825801	Pop rivet	$0.35	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	3SE886209B	Tension wire D >> - 18.10.2023	Enquire	IN STOCK
	3SE886209C	Tension wire	Enquire	IN STOCK
	3SE886210B	Tension wire D >> - 18.10.2023	Enquire	IN STOCK

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	3SE853779A	Seat back trim	Enquire	IN STOCK
	3SE853780A	Seat back trim	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0885153A	Retainer for rest	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10340103	Hexagon collar nut	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0882829	Damper for pneumatic pump	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0882829A	Damper for pneumatic pump	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0886073	Air pump	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4H0885665	guide sleeve	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4H0941117	Securing element	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0885321A	seat well	Enquire	IN STOCK
	4N0885322A	seat well	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	4N0963575A	ventliation motor D - 01.04.2019>>	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	3SE885909	Support element	Enquire	IN STOCK
	3SE885910	Support element	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	3SE885146	Support element	Enquire	IN STOCK
	3SE885151	Support element	Enquire	IN STOCK

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4N0885511B	backrest frame	4N0885511B backrest frame left ,PR:1TA	-	1	Enquire
1	4N0885512B	backrest frame	4N0885512B backrest frame right ,PR:1TA	-	1	Enquire
2	4N0885111	Rear seat frame	4N0885111 Rear seat frame left ,PR:1TA	-	1	Enquire
2	4N0885112	Rear seat frame	4N0885112 Rear seat frame right ,PR:1TA	-	1	Enquire
3	WHT004970	Clamping bolt	WHT004970 Clamping bolt	-	2	Enquire
4	3Y5885547	clamping ring D >> - 05.09.2023	3Y5885547 clamping ring D >> - 05.09.2023	-	2	Enquire
4	3Y5885547A	clamping ring	3Y5885547A clamping ring	-	2	Enquire
5	N98923402	Hexagon collar nut	N98923402 Hexagon collar nut	-	1	Enquire
6	N91134301	Int. serration flange screw IN STOCK	N91134301 Int. serration flange screw M10X20 IN STOCK	$2.21	3
7	4N0937545G	Clutch carrier	4N0937545G Clutch carrier left	-	1	Enquire
7	4N0937546G	Clutch carrier	4N0937546G Clutch carrier right	-	1	Enquire
8	4N0886879A	Module support with air cushions for low. back support	4N0886879A Module support with air cushions for low. back support left a. right	-	1	Enquire
9	N90737803	Hexagon socket flat head bolt	N90737803 Hexagon socket flat head bolt	-	1	Enquire
10	4H0941117	Securing element	4H0941117 Securing element PR:4D2	-	4	Enquire
11	4N0963575A	ventliation motor D - 01.04.2019>>	4N0963575A ventliation motor D - 01.04.2019>> left a. right	-	1	Enquire
12	4N0886920B	guide for head restraint, adjustable	4N0886920B guide for head restraint, adjustable	-	2	Enquire
13	3SE886203A	Supporting bracket D >> - 04.07.2023	3SE886203A Supporting bracket D >> - 04.07.2023 left	-	1	Enquire
13	3SE886203B	Supporting bracket	3SE886203B Supporting bracket left	-	1	Enquire
13	3SE886204A	Supporting bracket D >> - 04.07.2023	3SE886204A Supporting bracket D >> - 04.07.2023 right	-	1	Enquire
13	3SE886204B	Supporting bracket	3SE886204B Supporting bracket right	-	1	Enquire
14	N90698606	Hexagon socket head panel bolt IN STOCK	N90698606 Hexagon socket head panel bolt IN STOCK	$0.92	2
15	3SE886223B	Gap cover	3SE886223B Gap cover left	-	1	Enquire
15	3SE886224B	Gap cover	3SE886224B Gap cover right	-	1	Enquire
16	N90825801	Pop rivet IN STOCK	N90825801 Pop rivet IN STOCK	$0.35	1
17	3SE886209B	Tension wire D >> - 18.10.2023	3SE886209B Tension wire D >> - 18.10.2023 left	-	1	Enquire
17	3SE886209C	Tension wire	3SE886209C Tension wire left	-	1	Enquire
17	3SE886210B	Tension wire D >> - 18.10.2023	3SE886210B Tension wire D >> - 18.10.2023 right	-	1	Enquire
17	3SE886210C	Tension wire	3SE886210C Tension wire right	-	1	Enquire
18	3SE853779A	Seat back trim	3SE853779A Seat back trim left	-	1	Enquire
18	3SE853780A	Seat back trim	3SE853780A Seat back trim right	-	1	Enquire
19	4N0885153A	Retainer for rest	4N0885153A Retainer for rest left a. right ,PR:1TA	-	1	Enquire
20	N10340103	Hexagon collar nut	N10340103 Hexagon collar nut	-	4	Enquire
21	4N0882829	Damper for pneumatic pump	4N0882829 Damper for pneumatic pump upper ,PR:4D2	-	1	Enquire
22	4N0882829A	Damper for pneumatic pump	4N0882829A Damper for pneumatic pump lower ,PR:4D2	-	1	Enquire
23	4N0886073	Air pump	4N0886073 Air pump left a. right	-	1	Enquire
24	4H0885665	guide sleeve	4H0885665 guide sleeve left a. right	-	2	Enquire
25	4H0941117	Securing element	4H0941117 Securing element PR:4D2	-	4	Enquire
26	4N0885321A	seat well	4N0885321A seat well left ,PR:1TA	-	1	Enquire
26	4N0885322A	seat well	4N0885322A seat well right ,PR:1TA	-	1	Enquire
27	4N0963575A	ventliation motor D - 01.04.2019>>	4N0963575A ventliation motor D - 01.04.2019>>	-	1	Enquire
28	3SE885909	Support element	3SE885909 Support element plastic left inner ,PR:3NL	-	1	Enquire
28	3SE885910	Support element	3SE885910 Support element plastic right inner ,PR:3NL	-	1	Enquire
29	3SE885146	Support element	3SE885146 Support element plastic left outer ,PR:3NL	-	1	Enquire
29	3SE885151	Support element	3SE885151 Support element plastic right outer ,PR:3NL	-	1	Enquire
