Antenna amplifier of Rolls Royce Rolls Royce Phantom Extended Wheelbase

View All

Rolls Royce Phantom Extended Wheelbase - Antenna amplifier

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	65200304184	Amplifier, rear window antenna	Enquire	To Order
	65200304186	Amplifier, rear window antenna	Enquire	To Order
	65200413982	Amplifier, rear window antenna	Enquire	To Order

...and 4 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	65200140687	Instrument carrier	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7147153450	Self-locking hex nut	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65250140147	Trap circuit	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7146961863	Screw, self tapping	Enquire	To Order
	7149158177	Screw, self tapping	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61120301756	LEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61120301754	Earth cable	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65209166896	TV amplifier	Enquire	To Order
	65256990093	TV amplifier	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65250398096	Antenna bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7146961863	Screw, self tapping	Enquire	To Order
	7149158177	Screw, self tapping	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	65200304184	Amplifier, rear window antenna	65200304184 Amplifier, rear window antenna 315MHZ	-	-	Enquire
1	65200304186	Amplifier, rear window antenna	65200304186 Amplifier, rear window antenna 868MHZ	-	-	Enquire
1	65200413982	Amplifier, rear window antenna	65200413982 Amplifier, rear window antenna 315MHZ	-	-	Enquire
1	65200432277	Amplifier, rear window antenna	65200432277 Amplifier, rear window antenna 868MHZ	-	-	Enquire
1	65200432278	Amplifier, rear window antenna	65200432278 Amplifier, rear window antenna 315MHZ	-	-	Enquire
1	65200432279	Amplifier, rear window antenna	65200432279 Amplifier, rear window antenna 315MHZ	-	-	Enquire
1	65250309273	Amplifier, rear window antenna	65250309273 Amplifier, rear window antenna 315MHZ	-	-	Enquire
2	65200140687	Instrument carrier	65200140687 Instrument carrier	-	-	Enquire
3	7147153450	Self-locking hex nut	7147153450 Self-locking hex nut M6	-	-	Enquire
4	65250140147	Trap circuit	65250140147 Trap circuit	-	-	Enquire
5	7146961863	Screw, self tapping	7146961863 Screw, self tapping ISA M5X12	-	-	Enquire
5	7149158177	Screw, self tapping	7149158177 Screw, self tapping ISA M5X12	-	-	Enquire
6	61120301756	LEAD	61120301756 LEAD	-	-	Enquire
7	61120301754	Earth cable	61120301754 Earth cable 4MMÐ†	-	-	Enquire
8	65209166896	TV amplifier	65209166896 TV amplifier	-	-	Enquire
8	65256990093	TV amplifier	65256990093 TV amplifier	-	-	Enquire
9	65250398096	Antenna bracket	65250398096 Antenna bracket	-	-	Enquire
10	7146961863	Screw, self tapping	7146961863 Screw, self tapping ISA M5X12	-	-	Enquire
10	7149158177	Screw, self tapping	7149158177 Screw, self tapping ISA M5X12	-	-	Enquire
