Lift-Up-And-Slide-Back Sunroof

Rolls Royce Phantom

Find Your Part

Rolls Royce Phantom - Lift-up-and-slide-back sunroof

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
54107198065 Sliding roof frame assembly Enquire To Order
Photo Part No Description Price (each) Stock
7147131047 Hex Bolt Enquire To Order
Photo Part No Description Price (each) Stock
7147131048 Screw Enquire To Order
Photo Part No Description Price (each) Stock
7147132785 Spacer Enquire To Order
Photo Part No Description Price (each) Stock
54107159253 Sunroof glass Enquire To Order
Photo Part No Description Price (each) Stock
7140397550 Fillister head screw Enquire To Order
Photo Part No Description Price (each) Stock
54137151994 Trim, frame Enquire To Order
Photo Part No Description Price (each) Stock
54107160458 Seal, panorama sunroof Enquire To Order
Photo Part No Description Price (each) Stock
67616949628 Drive unit, sunroof Enquire To Order
67619137056 Drive unit, sunroof Enquire To Order
Photo Part No Description Price (each) Stock
7147132782 Fillister head screw Enquire To Order
Photo Part No Description Price (each) Stock
54137000497 EMERGENCY TOOL ELECTR.SLIDING ROOF Enquire To Order
Photo Part No Description Price (each) Stock
51738197504 WATER OUTLET HOSE Enquire To Order
Photo Part No Description Price (each) Stock
54137155389 Drain pipe Enquire To Order
Photo Part No Description Price (each) Stock
54137060976 WATER OUTLET VALVE Enquire To Order
Photo Part No Description Price (each) Stock
51488371597 SOUND ABSORBER Enquire To Order
Photo Part No Description Price (each) Stock
54137028563 SLIPSTREAM DEFLECTOR Enquire To Order
Photo Part No Description Price (each) Stock
54107198136 Mechanism, sliding roof Enquire To Order
Photo Part No Description Price (each) Stock
54137198001 Supended headliner Enquire To Order
Photo Part No Description Price (each) Stock
54107198066 SPACER HOLDER Enquire To Order
Photo Part No Description Price (each) Stock
54107198067 Pivot lever, wind deflector Enquire To Order
View All
Lift-up-and-slide-back sunroof of Rolls Royce Rolls Royce Phantom Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 54107198065
Sliding roof frame assembly 		- - Enquire
2 7147131047
Hex Bolt
M6X10,5 		- - Enquire
3 7147131048
Screw
M6X25,5 		- - Enquire
4 7147132785
Spacer
D=2MM 		- - Enquire
5 54107159253
Sunroof glass 		- - Enquire
6 7140397550
Fillister head screw
M5X16 		- - Enquire
7 54137151994
Trim, frame 		- - Enquire
8 54107160458
Seal, panorama sunroof 		- - Enquire
9 67616949628
Drive unit, sunroof 		- - Enquire
9 67619137056
Drive unit, sunroof 		- - Enquire
10 7147132782
Fillister head screw
M5X28 		- - Enquire
11 54137000497
EMERGENCY TOOL ELECTR.SLIDING ROOF 		- - Enquire
12 51738197504
WATER OUTLET HOSE 		- - Enquire
13 54137155389
Drain pipe 		- - Enquire
14 54137060976
WATER OUTLET VALVE 		- - Enquire
15 51488371597
SOUND ABSORBER
100X70X3 		- - Enquire
16 54137028563
SLIPSTREAM DEFLECTOR 		- - Enquire
17 54107198136
Mechanism, sliding roof 		- - Enquire
18 54137198001
Supended headliner
BLACK 		- - Enquire
19 54107198066
SPACER HOLDER 		- - Enquire
20 54107198067
Pivot lever, wind deflector 		- - Enquire
