Name: Seat front electrical system drives
Rating: 4.7 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	52107309647	Drive, longitudinal seat adjustment left	$405.33	To Order
	52107321956	Drive, longitudinal seat adjustment rght	$405.33	To Order

Photo	Part No	Description	Price (each)	Stock
	52107309659	Drive, seat angle adjustment left	$405.33	To Order
	52107309660	Drive, seat angle adjustment right	$405.33	To Order

Photo	Part No	Description	Price (each)	Stock
	52107309657	Drive, seat height adjustment left	$405.33	To Order
	52107309658	Drive, seat height adjustment right	$405.33	To Order

Photo	Part No	Description	Price (each)	Stock
	52107309653	Drive, backrest angle adjustment, left	$337.75	To Order
	52107309654	Drive, backrest angle adjustment, right	$337.75	To Order

Photo	Part No	Description	Price (each)	Stock
	52107309648	set of fittings for seat drive	$48.64	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	52107309647	Drive, longitudinal seat adjustment left	52107309647 Drive, longitudinal seat adjustment left	$405.33	1
1	52107321956	Drive, longitudinal seat adjustment rght	52107321956 Drive, longitudinal seat adjustment rght	$405.33	1
2	52107309659	Drive, seat angle adjustment left	52107309659 Drive, seat angle adjustment left	$405.33	1
2	52107309660	Drive, seat angle adjustment right	52107309660 Drive, seat angle adjustment right	$405.33	1
3	52107309657	Drive, seat height adjustment left	52107309657 Drive, seat height adjustment left	$405.33	1
3	52107309658	Drive, seat height adjustment right	52107309658 Drive, seat height adjustment right	$405.33	1
4	52107357163	Micro switch left	52107357163 Micro switch left	$113.99	1
4	52107357164	Micro switch right	52107357164 Micro switch right	$113.99	1
5	52107309653	Drive, backrest angle adjustment, left	52107309653 Drive, backrest angle adjustment, left	$337.75	1
5	52107309654	Drive, backrest angle adjustment, right	52107309654 Drive, backrest angle adjustment, right	$337.75	1
6	52107309648	set of fittings for seat drive	52107309648 set of fittings for seat drive	$48.64	2
