MAIN WIRING

Find Your Part

Maserati Quattroporte (2008-2012) 4.2 - MAIN WIRING

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
270728 ENGINE COMPARTMENT WIRING HARNESS $3,596.08 To Order
Photo Part No Description Price (each) Stock
270734 BOOT COMPARTMENT WIRING HARNESS $2,593.45 To Order
Photo Part No Description Price (each) Stock
251189 DASHBOARD CABLE $537.54 To Order
Photo Part No Description Price (each) Stock
270731 PASSENGER COMPARTMENT WIRING HARNESS $2,633.62 To Order
Photo Part No Description Price (each) Stock
243957 DRIVER DOOR WIRING HARNESS $226.08 To Order
243958 PASSENGER DOOR WIRING HARNESS $209.99 To Order
Photo Part No Description Price (each) Stock
200536 REAR DOOR WIRING HARNESS $212.72 To Order
Photo Part No Description Price (each) Stock
231400 BOOT WIRING HARNESS $181.44 To Order
Photo Part No Description Price (each) Stock
212487 FUEL PUMP CABLE $717.98 To Order
Photo Part No Description Price (each) Stock
239100 FRONT BUMPER WIRING HARNESS $903.86 To Order
Photo Part No Description Price (each) Stock
196809 DRIVER DOOR PANEL WIRING HARNESS $149.55 To Order
214128 PASSENGER DOOR PANEL WIRING HARNESS $57.10 To Order
Photo Part No Description Price (each) Stock
196810 REAR DOOR PANEL WIRING HARNESS $149.55 To Order
Photo Part No Description Price (each) Stock
226397 ROOF WIRING HARNESS $311.60 To Order
Photo Part No Description Price (each) Stock
177553 CLAMP $1.97 To Order
Photo Part No Description Price (each) Stock
251758 WIRING HARNESS GUIDE $8.06 To Order
Photo Part No Description Price (each) Stock
10448890 BRACKET WITH SHEATH $1.97 To Order
Photo Part No Description Price (each) Stock
16284934 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
177553 CLAMP $1.97 To Order
Photo Part No Description Price (each) Stock
208522 CLAMP $1.97 To Order
Photo Part No Description Price (each) Stock
213023 REAR BONNET OPENING CABLE GROMMET $71.25 To Order
Photo Part No Description Price (each) Stock
69590100 CLIP $8.47 To Order
Photo Part No Description Price (each) Stock
14039614 NUT $1.54 To Order
Photo Part No Description Price (each) Stock
67885100 CLIP $2.83 To Order
View All
MAIN WIRING of Maserati Maserati Quattroporte (2008-2012) 4.2 Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 270728
ENGINE COMPARTMENT WIRING HARNESS
Valid for cars with new solution of aqs sensor (See draw. 8.49 pos. 16) - Valid for TPMS 2,5 system 		$3,596.08 1
2 270734
BOOT COMPARTMENT WIRING HARNESS
Valid for TPMS 2,5 system 		$2,593.45 1
3 251189
DASHBOARD CABLE 		$537.54 1
4 270731
PASSENGER COMPARTMENT WIRING HARNESS
Valid for TPMS 2,5 system 		$2,633.62 1
5 243957
DRIVER DOOR WIRING HARNESS 		$226.08 1
5 243958
PASSENGER DOOR WIRING HARNESS 		$209.99 1
7 200536
REAR DOOR WIRING HARNESS 		$212.72 2
8 231400
BOOT WIRING HARNESS 		$181.44 1
9 212487
FUEL PUMP CABLE 		$717.98 1
10 239100
FRONT BUMPER WIRING HARNESS 		$903.86 1
11 196809
DRIVER DOOR PANEL WIRING HARNESS 		$149.55 1
11 214128
PASSENGER DOOR PANEL WIRING HARNESS 		$57.10 1
12 196810
REAR DOOR PANEL WIRING HARNESS 		$149.55 2
13 226397
ROOF WIRING HARNESS 		$311.60 1
14 177553
CLAMP 		$1.97 -
15 251758
WIRING HARNESS GUIDE 		$8.06 1
16 10448890
BRACKET WITH SHEATH 		$1.97 6
17 16284934
SCREW 		- 6 Enquire
18 177553
CLAMP 		$1.97 1
19 208522
CLAMP 		$1.97 1
20 213023
REAR BONNET OPENING CABLE GROMMET 		$71.25 1
21 69590100
CLIP 		$8.47 2
22 14039614
NUT 		$1.54 2
23 67885100
CLIP 		$2.83 2
