A/C UNIT: ENGINE COMPARTMENT DEVICES of Maserati Maserati GranTurismo (2012-2016) Sport Auto

View All

Maserati GranTurismo (2012-2016) Sport Auto - A/C UNIT: ENGINE COMPARTMENT DEVICES

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	228388	Air Conditioning Condenser	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	239419	BRACKET	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12643724	Washer 6.15-18x1.5	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	239421	BRACKET	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12644424	WASHER 6.15-15 X 1	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	239420	BRACKET	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12643724	Washer 6.15-18x1.5	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	239422	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	12644424	WASHER 6.15-15 X 1	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	84696800	PIPE FROM CONDENSER TO SHIELD	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	80375900	PIPE FROM COMPRESSOR TO CONDENSER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	81252500	PIPE FROM COMPRESSOR TO SHIELD JOINT	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	284728	AIR CONDITIONING DELPHI COMPRESSOR	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	141496	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	175428	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14307224	SCREW	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	11186374	WASHERD.10-20X2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	227256	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67063200	CLIP	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	65628200	AIR CONDITIONING PRESSURE SWITCH	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	68392000	O.R. GASKET	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	68392100	O-Ring	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	66309700	O.R. GASKET	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	68392700	O-Ring	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	68392800	O.R. GASKET	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	66309800	O.R. GASKET	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	66309600	O-RING	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	67085400	O Ring D18	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	82068100	O-Ring D.25	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	68199800	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16297627	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	233192	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254649	DEHYDRATOR FILTER	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	251239	O.R. GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	251238	PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	251237	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	254356	DEHYDRATING FILTER KIT	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	186196	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80964400	FLANGE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80964500	GASKET FOR FLANGE	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	254356	DEHYDRATING FILTER KIT	Enquire	IN STOCK

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	228388	Air Conditioning Condenser IN STOCK	228388 Air Conditioning Condenser IN STOCK	-	1	Enquire
2	239419	BRACKET IN STOCK	239419 BRACKET R.H. Upper IN STOCK	-	1	Enquire
3	14039614	NUT IN STOCK	14039614 NUT IN STOCK	-	1	Enquire
4	12643724	Washer 6.15-18x1.5 ARRIVING SOON	12643724 Washer 6.15-18x1.5 ARRIVING SOON	-	1	Enquire
5	239421	BRACKET IN STOCK	239421 BRACKET L.H. Upper IN STOCK	-	1	Enquire
6	14039614	NUT IN STOCK	14039614 NUT IN STOCK	-	2	Enquire
7	12644424	WASHER 6.15-15 X 1 IN STOCK	12644424 WASHER 6.15-15 X 1 IN STOCK	-	2	Enquire
8	239420	BRACKET IN STOCK	239420 BRACKET R.H. Lower IN STOCK	-	1	Enquire
9	14039614	NUT IN STOCK	14039614 NUT IN STOCK	-	1	Enquire
10	12643724	Washer 6.15-18x1.5 ARRIVING SOON	12643724 Washer 6.15-18x1.5 ARRIVING SOON	-	1	Enquire
11	239422	BRACKET	239422 BRACKET L.H. Lower	-	1	Enquire
12	14039614	NUT IN STOCK	14039614 NUT IN STOCK	-	2	Enquire
13	12644424	WASHER 6.15-15 X 1 IN STOCK	12644424 WASHER 6.15-15 X 1 IN STOCK	-	2	Enquire
14	84696800	PIPE FROM CONDENSER TO SHIELD IN STOCK	84696800 PIPE FROM CONDENSER TO SHIELD IN STOCK	-	1	Enquire
15	80375900	PIPE FROM COMPRESSOR TO CONDENSER IN STOCK	80375900 PIPE FROM COMPRESSOR TO CONDENSER IN STOCK	-	1	Enquire
16	81252500	PIPE FROM COMPRESSOR TO SHIELD JOINT ARRIVING SOON	81252500 PIPE FROM COMPRESSOR TO SHIELD JOINT ARRIVING SOON	-	1	Enquire
17	284728	AIR CONDITIONING DELPHI COMPRESSOR IN STOCK	284728 AIR CONDITIONING DELPHI COMPRESSOR If ordered for engine # lower than 196384 or for this engine # :196387-196388-196392-196389-196391-196239-196400-196402-196399-196394-196393, also take P/N 271881 IN STOCK	-	1	Enquire
18	141496	SPACER	141496 SPACER	-	1	Enquire
19	175428	SCREW	175428 SCREW	-	1	Enquire
20	14307224	SCREW IN STOCK	14307224 SCREW M8X90 IN STOCK	-	2	Enquire
21	11186374	WASHERD.10-20X2	11186374 WASHERD.10-20X2 D.10-20X2	-	3	Enquire
22	227256	BRACKET	227256 BRACKET	-	1	Enquire
23	67063200	CLIP IN STOCK	67063200 CLIP IN STOCK	-	1	Enquire
24	65628200	AIR CONDITIONING PRESSURE SWITCH IN STOCK	65628200 AIR CONDITIONING PRESSURE SWITCH IN STOCK	-	1	Enquire
25	68392000	O.R. GASKET IN STOCK	68392000 O.R. GASKET IN STOCK	-	2	Enquire
26	68392100	O-Ring IN STOCK	68392100 O-Ring IN STOCK	-	2	Enquire
27	66309700	O.R. GASKET IN STOCK	66309700 O.R. GASKET IN STOCK	-	1	Enquire
28	68392700	O-Ring IN STOCK	68392700 O-Ring IN STOCK	-	1	Enquire
29	68392800	O.R. GASKET IN STOCK	68392800 O.R. GASKET IN STOCK	-	1	Enquire
30	66309800	O.R. GASKET IN STOCK	66309800 O.R. GASKET IN STOCK	-	1	Enquire
31	66309600	O-RING IN STOCK	66309600 O-RING IN STOCK	-	1	Enquire
32	67085400	O Ring D18 IN STOCK	67085400 O Ring D18 IN STOCK	-	1	Enquire
33	82068100	O-Ring D.25	82068100 O-Ring D.25	-	1	Enquire
34	68199800	BRACKET	68199800 BRACKET	-	1	Enquire
35	16297627	SCREW	16297627 SCREW	-	1	Enquire
36	233192	BRACKET	233192 BRACKET	-	1	Enquire
37	248334	SCREW M6 X 14MM IN STOCK	248334 SCREW M6 X 14MM IN STOCK	-	1	Enquire
38	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D.6.4-12X2.4	-	1	Enquire
39	254649	DEHYDRATOR FILTER IN STOCK	254649 DEHYDRATOR FILTER IN STOCK	-	1	Enquire
41	251239	O.R. GASKET	251239 O.R. GASKET	-	2	Enquire
42	251238	PLATE	251238 PLATE	-	1	Enquire
43	251237	SCREW	251237 SCREW	-	1	Enquire
44	254356	DEHYDRATING FILTER KIT IN STOCK	254356 DEHYDRATING FILTER KIT IN STOCK	-	1	Enquire
45	186196	SCREW	186196 SCREW	-	2	Enquire
46	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D. 6,40-12X 0,5	-	2	Enquire
47	80964400	FLANGE	80964400 FLANGE	-	1	Enquire
48	80964500	GASKET FOR FLANGE IN STOCK	80964500 GASKET FOR FLANGE IN STOCK	-	1	Enquire
49	14039614	NUT IN STOCK	14039614 NUT IN STOCK	-	2	Enquire
51	254356	DEHYDRATING FILTER KIT IN STOCK	254356 DEHYDRATING FILTER KIT IN STOCK	-	1	Enquire
