COOLING SYSTEM: NOURICE AND LINES of Maserati Maserati GranCabrio M189 FOLGORE AUTOMATIC 4WD BEV 560 kW

View All

Maserati GranCabrio M189 FOLGORE AUTOMATIC 4WD BEV 560 kW - COOLING SYSTEM: NOURICE AND LINES

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	670159393	EXPANSION TANK	Enquire	To Order
	670293099	EXPANSION TANK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675002254	PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670301691	flexible hose tank inlet	Enquire	To Order
	670293105	flexible hose tank inlet	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670159414	sleeve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670159553	hose	Enquire	To Order
	670293112	sleeve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670301690	sleeve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670301688	sleeve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670301689	hose	Enquire	To Order
	670293111	HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670306293	HOSE WATER TO INVERTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670301685	hose	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670301686	hose	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670301708	hose	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670159560	hose	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670159561	HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670306294	HOSE FLEX FROM COOLER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670213190	cooling module cable assembl	Enquire	To Order
	670220697	cooling module cable assembl	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000575	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670311868	ELECTRIC PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670213736	ADDITIONAL ELECTRIC WATER PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670159396	STAFFA POMPA	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670159402	STAFFA PER VALVOLA A 3 VIE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670216785	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670179826	3-WAY UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670159395	STAFFA POMPA	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000054	FLEXIBLE PAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000129	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675001127	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675002241	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670159633	BRACKET	Enquire	To Order
	670293108	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000969	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000182	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675001119	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670159789	HOSE	Enquire	To Order
	670293102	HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000369	COLLARD.13-14	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670216808	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16MB344CP	BODY HARNESS REAR BASE	$1,966.82	To Order

Photo	Part No	Description	Price (each)	Stock
	675000794	NUT	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	670159393	EXPANSION TANK	670159393 EXPANSION TANK EU CN US JP ME KO N0;	-	1	Enquire
1	670293099	EXPANSION TANK	670293099 EXPANSION TANK AU UK JRH IN N8 UK3 GB;	-	1	Enquire
2	675002254	PLUG	675002254 PLUG	-	1	Enquire
3	670301691	flexible hose tank inlet	670301691 flexible hose tank inlet EU CN US JP ME KO N0;	-	1	Enquire
3	670293105	flexible hose tank inlet	670293105 flexible hose tank inlet AU UK JRH IN N8 UK3 GB;	-	1	Enquire
5	670159414	sleeve	670159414 sleeve	-	1	Enquire
6	670159553	hose	670159553 hose EU CN US JP ME KO N0;	-	1	Enquire
6	670293112	sleeve	670293112 sleeve AU UK JRH IN N8 UK3 GB;	-	1	Enquire
7	670301690	sleeve	670301690 sleeve	-	1	Enquire
8	670301688	sleeve	670301688 sleeve	-	1	Enquire
9	670301689	hose	670301689 hose EU CN US JP ME KO N0;	-	1	Enquire
9	670293111	HOSE	670293111 HOSE AU UK JRH IN N8 UK3 GB;	-	1	Enquire
10	670306293	HOSE WATER TO INVERTER	670306293 HOSE WATER TO INVERTER	-	1	Enquire
11	670301685	hose	670301685 hose	-	1	Enquire
12	670301686	hose	670301686 hose	-	1	Enquire
13	670301708	hose	670301708 hose	-	1	Enquire
14	670159560	hose	670159560 hose	-	1	Enquire
15	670159561	HOSE	670159561 HOSE	-	1	Enquire
16	670306294	HOSE FLEX FROM COOLER	670306294 HOSE FLEX FROM COOLER	-	1	Enquire
17	670213190	cooling module cable assembl	670213190 cooling module cable assembl EU CN US JP ME KO N0;	-	1	Enquire
17	670220697	cooling module cable assembl	670220697 cooling module cable assembl AU UK JRH IN N8 UK3 GB;	-	1	Enquire
18	675000575	COLLAR	675000575 COLLAR	-	1	Enquire
19	670311868	ELECTRIC PUMP	670311868 ELECTRIC PUMP	-	1	Enquire
20	670213736	ADDITIONAL ELECTRIC WATER PUMP	670213736 ADDITIONAL ELECTRIC WATER PUMP	-	2	Enquire
21	670159396	STAFFA POMPA	670159396 STAFFA POMPA	-	1	Enquire
22	670159402	STAFFA PER VALVOLA A 3 VIE	670159402 STAFFA PER VALVOLA A 3 VIE	-	1	Enquire
23	670216785	BRACKET	670216785 BRACKET EU CN US JP ME KO N0;	-	1	Enquire
24	670179826	3-WAY UNION	670179826 3-WAY UNION	-	2	Enquire
25	670159395	STAFFA POMPA	670159395 STAFFA POMPA	-	1	Enquire
26	675000054	FLEXIBLE PAD	675000054 FLEXIBLE PAD	-	7	Enquire
27	675000129	SPACER	675000129 SPACER	-	7	Enquire
28	675001127	SCREW	675001127 SCREW	-	10	Enquire
29	675002241	NUT	675002241 NUT	-	2	Enquire
30	670159633	BRACKET	670159633 BRACKET EU CN US JP ME KO N0;	-	1	Enquire
30	670293108	BRACKET	670293108 BRACKET AU UK JRH IN N8 UK3 GB;	-	1	Enquire
31	675000969	NUT	675000969 NUT	-	2	Enquire
32	675000182	NUT	675000182 NUT	-	2	Enquire
33	675001119	SCREW	675001119 SCREW	-	3	Enquire
34	670159789	HOSE	670159789 HOSE EU CN US JP ME KO N0;	-	1	Enquire
34	670293102	HOSE	670293102 HOSE AU UK JRH IN N8 UK3 GB;	-	1	Enquire
35	675000369	COLLARD.13-14	675000369 COLLARD.13-14	-	1	Enquire
36	670216808	CLIP	670216808 CLIP	-	1	Enquire
37	16MB344CP	BODY HARNESS REAR BASE	16MB344CP BODY HARNESS REAR BASE EU CN US JP ME KO N0;	$1,966.82	1
38	675000794	NUT	675000794 NUT	-	15	Enquire
