AIR-CONDITIONING SYSTEM WITH ELECTRONIC REGULATION of Lamborghini Lamborghini Urus (2019-2022)

View All

Lamborghini Urus (2019-2022) - AIR-CONDITIONING SYSTEM WITH ELECTRONIC REGULATION (820.01.00)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4M1820024	BLOWER HOUSING	Enquire	To Order
	4M2820024	BLOWER HOUSING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1819229	SEAL	Enquire	To Order
	4M2819229	SEAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1819587	DAMPING MAT	Enquire	To Order
	4M2819587	DAMPING MAT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1820021C	FAN MOTOR WITH WHEEL	Enquire	To Order
	4M2820021B	FAN MOTOR WITH WHEEL	Enquire	To Order
	4M2820021C	FAN MOTOR WITH WHEEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1819422	COVER	Enquire	To Order
	4M2819422	COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1820023B	EVAPORATOR HOUSING WITH EVAPORATOR	Enquire	To Order
	4M2820023B	EVAPORATOR HOUSING WITH EVAPORATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0898037A	SUNDRY PARTS SET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4D0260749B	SEAL RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4E0260749B	SEAL RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0816679	EXPANSION VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0898333A	REPAIR SET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0820560	SPACER PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8K0820539	TEMPERATURE SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0820751	GROMMET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0820356	AIR DISTRIBUTION HOUSING	Enquire	To Order
	4M0820356A	AIR DISTRIBUTION HOUSING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0819422	COVER	Enquire	To Order
	4M0819422A	COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0820511A	SERVOMOTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0898037C	HEAT EXCHANGER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0819593	FILLER PIECE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1898037	1 SET: PIPES FOR HEAT EXCHANGER	Enquire	To Order
	4M2898037	1 SET: PIPES FOR HEAT EXCHANGER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0898037B	SUNDRY PARTS SET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0898001	REPAIR SET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8K0898540A	1 SET TENSIONING SPRINGS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8K0898540	1 SET SECURING BOLTS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6Q0820539	TEMPERATURE SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0898967	REPAIR SET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1898333	REPAIR SET	Enquire	To Order
	4M1898333A	REPAIR SET	Enquire	To Order
	4M2898333	REPAIR SET	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	4M0898333	REPAIR SET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8W0819699	DOUBLE GROMMET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0819439B	ODOUR AND ALLERGEN FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0260113A	WATER DRAINAGE HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91237801	HEXAGON SOCKET HEAD PANEL BOLT	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4M1820024	BLOWER HOUSING	4M1820024 BLOWER HOUSING LHD- LHD	-	1	Enquire
1	4M2820024	BLOWER HOUSING	4M2820024 BLOWER HOUSING RHD- RHD	-	1	Enquire
2	4M1819229	SEAL	4M1819229 SEAL LHD- LHD	-	1	Enquire
2	4M2819229	SEAL	4M2819229 SEAL RHD- RHD	-	1	Enquire
3	4M1819587	DAMPING MAT	4M1819587 DAMPING MAT LHD- LHD	-	1	Enquire
3	4M2819587	DAMPING MAT	4M2819587 DAMPING MAT RHD- RHD	-	1	Enquire
4	4M1820021C	FAN MOTOR WITH WHEEL	4M1820021C FAN MOTOR WITH WHEEL LHD- LHD	-	1	Enquire
4	4M2820021B	FAN MOTOR WITH WHEEL	4M2820021B FAN MOTOR WITH WHEEL RHD- RHD	-	1	Enquire
4	4M2820021C	FAN MOTOR WITH WHEEL	4M2820021C FAN MOTOR WITH WHEEL RHD- RHD	-	1	Enquire
5	4M1819422	COVER	4M1819422 COVER LHD- LHD	-	1	Enquire
5	4M2819422	COVER	4M2819422 COVER RHD- RHD	-	1	Enquire
6	4M1820023B	EVAPORATOR HOUSING WITH EVAPORATOR	4M1820023B EVAPORATOR HOUSING WITH EVAPORATOR LHD- LHD	-	1	Enquire
6	4M2820023B	EVAPORATOR HOUSING WITH EVAPORATOR	4M2820023B EVAPORATOR HOUSING WITH EVAPORATOR RHD- RHD	-	1	Enquire
7	4M0898037A	SUNDRY PARTS SET	4M0898037A SUNDRY PARTS SET	-	1	Enquire
8	4D0260749B	SEAL RING	4D0260749B SEAL RING 7 -6X2,5	-	1	Enquire
9	4E0260749B	SEAL RING	4E0260749B SEAL RING 13 -7X2,5	-	1	Enquire
10	4M0816679	EXPANSION VALVE	4M0816679 EXPANSION VALVE	-	1	Enquire
11	4M0898333A	REPAIR SET	4M0898333A REPAIR SET	-	1	Enquire
12	4M0820560	SPACER PLATE	4M0820560 SPACER PLATE	-	1	Enquire
13	8K0820539	TEMPERATURE SENSOR	8K0820539 TEMPERATURE SENSOR	-	1	Enquire
14	4M0820751	GROMMET	4M0820751 GROMMET	-	1	Enquire
15	4M0820356	AIR DISTRIBUTION HOUSING	4M0820356 AIR DISTRIBUTION HOUSING	-	1	Enquire
15	4M0820356A	AIR DISTRIBUTION HOUSING	4M0820356A AIR DISTRIBUTION HOUSING WITH CONTROLS IN REAR	-	1	Enquire
17	4M0819422	COVER	4M0819422 COVER W/O AUXILIARY HEATER	-	1	Enquire
17	4M0819422A	COVER	4M0819422A COVER WITH AUXILIARY HEATER	-	1	Enquire
18	4M0820511A	SERVOMOTOR	4M0820511A SERVOMOTOR	-	1	Enquire
19	4M0898037C	HEAT EXCHANGER	4M0898037C HEAT EXCHANGER	-	1	Enquire
20	4M0819593	FILLER PIECE	4M0819593 FILLER PIECE WITHOUT AUXILIARY HEATER	-	1	Enquire
21	4M1898037	1 SET: PIPES FOR HEAT EXCHANGER	4M1898037 1 SET: PIPES FOR HEAT EXCHANGER LHD- LHD	-	1	Enquire
21	4M2898037	1 SET: PIPES FOR HEAT EXCHANGER	4M2898037 1 SET: PIPES FOR HEAT EXCHANGER RHD- RHD	-	1	Enquire
22	4M0898037B	SUNDRY PARTS SET	4M0898037B SUNDRY PARTS SET	-	1	Enquire
23	4M0898001	REPAIR SET	4M0898001 REPAIR SET	-	1	Enquire
24	8K0898540A	1 SET TENSIONING SPRINGS	8K0898540A 1 SET TENSIONING SPRINGS	-	1	Enquire
25	8K0898540	1 SET SECURING BOLTS	8K0898540 1 SET SECURING BOLTS 4X16	-	1	Enquire
26	6Q0820539	TEMPERATURE SENSOR	6Q0820539 TEMPERATURE SENSOR	-	1	Enquire
27	4M0898967	REPAIR SET	4M0898967 REPAIR SET	-	1	Enquire
28	4M1898333	REPAIR SET	4M1898333 REPAIR SET LHD - 3+2 ZONES- LHD	-	1	Enquire
28	4M1898333A	REPAIR SET	4M1898333A REPAIR SET LHD - 3 ZONES- LHD	-	1	Enquire
28	4M2898333	REPAIR SET	4M2898333 REPAIR SET RHD - 3+2 ZONES- RHD	-	1	Enquire
28	4M2898333A	REPAIR SET	4M2898333A REPAIR SET RHD - 3 ZONES- RHD	-	1	Enquire
29	4M0898333	REPAIR SET	4M0898333 REPAIR SET	-	1	Enquire
30	8W0819699	DOUBLE GROMMET	8W0819699 DOUBLE GROMMET	-	1	Enquire
32	4M0819439B	ODOUR AND ALLERGEN FILTER	4M0819439B ODOUR AND ALLERGEN FILTER	-	1	Enquire
34	4M0260113A	WATER DRAINAGE HOSE	4M0260113A WATER DRAINAGE HOSE	-	2	Enquire
35	N91237801	HEXAGON SOCKET HEAD PANEL BOLT	N91237801 HEXAGON SOCKET HEAD PANEL BOLT 6X18 -5	-	5	Enquire

AIR-CONDITIONING SYSTEM WITH ELECTRONIC REGULATION (820.01.00)

EXTERNAL TEMPERATURE SENSOR (820.02.00)

Haven't found what you're looking for?

Original Parts Tuning Parts Need help? Call us

View Cart / Checkout

Air-Conditioning System With Electronic Regulation

Lamborghini Urus (2019-2022)

Illustration Number: 820.01.00

Lamborghini Urus (2019-2022) - AIR-CONDITIONING SYSTEM WITH ELECTRONIC REGULATION (820.01.00)
