Name: REAR LID REAR
Rating: 4.1 (1 reviews)

REAR LID REAR of Lamborghini Lamborghini Urus S

View All

Lamborghini Urus S - REAR LID REAR (827.01.00)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4ML827025A	REAR LID	$8,467.73	To Order

Photo	Part No	Description	Price (each)	Stock
	8U0827299F	LID HINGE	$71.92	To Order
	8U0827300F	LID HINGE	$71.92	To Order

Photo	Part No	Description	Price (each)	Stock
	4ML827705A	SEAL	$207.66	To Order

Photo	Part No	Description	Price (each)	Stock
	4ML827605	BRACKET	$58.27	To Order
	4ML827606	BRACKET	$58.27	To Order

Photo	Part No	Description	Price (each)	Stock
	4M8827603	BRACKET FOR DRIVE	$14.52	To Order
	4M8827604	BRACKET FOR DRIVE	$14.52	To Order

Photo	Part No	Description	Price (each)	Stock
	4ML827851J	GAS FILLED STRUT	$581.99	To Order

Photo	Part No	Description	Price (each)	Stock
	8W9827507A	LOCK STRIKER	$91.54	To Order

Photo	Part No	Description	Price (each)	Stock
	N90511505	HEXAGON COLLAR NUT SELF-LOCKING	$2.29	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT005287	HEXAGON FLANGE SCREW	$0.58	To Order

Photo	Part No	Description	Price (each)	Stock
	N90969903	HEX SOCKET HEAD LOCATING BOLT	$0.98	To Order

Photo	Part No	Description	Price (each)	Stock
	6V0827566	PUSH BUTTON FOR ELECTRIC LID LOCK ACTUATOR	$116.66	To Order
	760827566	PUSHBUTTON FOR ELECTRIC LID LOCK ACTUATOR WITH CAMERA	$573.93	To Order
	8W8827566E	PUSHBUTTON FOR ELECTRIC LID LOCK ACTUATOR WITH CAMERA	$573.93	To Order

Photo	Part No	Description	Price (each)	Stock
	4G0827310	CLIP	$0.58	To Order

Photo	Part No	Description	Price (each)	Stock
	8P4827951A	BUNGS	$1.47	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	4ML827025A	REAR LID	4ML827025A REAR LID REAR	$8,467.73	1
2	8U0827299F	LID HINGE	8U0827299F LID HINGE LEFT	$71.92	1
2	8U0827300F	LID HINGE	8U0827300F LID HINGE RIGHT	$71.92	1
3	4ML827705A	SEAL	4ML827705A SEAL	$207.66	1
4	4ML827605	BRACKET	4ML827605 BRACKET LEFT	$58.27	1
4	4ML827606	BRACKET	4ML827606 BRACKET RIGHT	$58.27	1
6	4M8827603	BRACKET FOR DRIVE	4M8827603 BRACKET FOR DRIVE LEFT	$14.52	1
6	4M8827604	BRACKET FOR DRIVE	4M8827604 BRACKET FOR DRIVE RIGHT	$14.52	1
7	4ML827851J	GAS FILLED STRUT	4ML827851J GAS FILLED STRUT SEE REPAIR MANUAL FOR SW AND RECORD VERSION - REPLACE THE COUPLE	$581.99	2
8	8W9827507A	LOCK STRIKER	8W9827507A LOCK STRIKER	$91.54	1
9	N90511505	HEXAGON COLLAR NUT SELF-LOCKING	N90511505 HEXAGON COLLAR NUT SELF-LOCKING M8	$2.29	4
10	WHT005287	HEXAGON FLANGE SCREW	WHT005287 HEXAGON FLANGE SCREW M6X28	$0.58	4
11	N90969903	HEX SOCKET HEAD LOCATING BOLT	N90969903 HEX SOCKET HEAD LOCATING BOLT M6X25	$0.98	8
12	6V0827566	PUSH BUTTON FOR ELECTRIC LID LOCK ACTUATOR	6V0827566 PUSH BUTTON FOR ELECTRIC LID LOCK ACTUATOR WITHOUT CAMERA SYSTEMS/ ACCIDENT SENSORS	$116.66	1
12	760827566	PUSHBUTTON FOR ELECTRIC LID LOCK ACTUATOR WITH CAMERA	760827566 PUSHBUTTON FOR ELECTRIC LID LOCK ACTUATOR WITH CAMERA WITH FRONT AND REAR VIEW CAMERA SYSTEM AND TWO SIDE CAMERAS-REAR	$573.93	1
12	8W8827566E	PUSHBUTTON FOR ELECTRIC LID LOCK ACTUATOR WITH CAMERA	8W8827566E PUSHBUTTON FOR ELECTRIC LID LOCK ACTUATOR WITH CAMERA WITH REAR VIEW CAMERA SYSTEM-REAR	$573.93	1
13	4G0827310	CLIP	4G0827310 CLIP	$0.58	2
14	8P4827951A	BUNGS	8P4827951A BUNGS	$1.47	3
