For High-Voltage Battery

Lamborghini Revuelto Coupe

Illustration Number: 907.03.00

Find Your Part

Lamborghini Revuelto Coupe - FOR HIGH-VOLTAGE BATTERY (907.03.00)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
FOR HIGH-VOLTAGE BATTERY of Lamborghini Lamborghini Revuelto Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 9Y0915681AL
CHARGER 7,2KW OBC
INCLUDES 2 X REF.6-7,2 KW 		- 1 Enquire
2 4M0907171A
CONVERTER
INCLUDES 1X REF6 		- 1 Enquire
2 4M0907171B
CONVERTER 		- 1 Enquire
3 47B907102C
BRACKET 		- 1 Enquire
4 47B915345B
BRACKET 		- 1 Enquire
5 47B915345C
BRACKET 		- 1 Enquire
6 RY5354279L23AD
RR W/ARCH LINER LH 		- 1 Enquire
6 12E010001G
STICKER HV KENNZEICHNUNG
WARRANTY 		- 1 Enquire
6 12E010001D
LABEL HV KENNZEICHNUNG 		- 1 Enquire
7 47C907102C
BRACKET
RHD 		- 1 Enquire
7 47A907102H
BRACKET
LHD 		- 1 Enquire
8 47C907102D
STAFFA OBC
RHD 		- 1 Enquire
8 47A907102
BRACKET
LHD 		- 1 Enquire
9 N01508210
HEXAGON COLLAR NUT
M6 		- 1 Enquire
10 N90737107
OVAL HEXAGON SOCKET HEAD BOLT
M6X12 		- 1 Enquire
11 N90737803
HEXAGON SOCKET FLAT HEAD BOLT
M6X14 		- 1 Enquire
12 N90969901
HEX SOCKET HEAD LOCATING BOLT
M6X25 		- 1 Enquire
13 N10751101
OVAL HEXAGON SOCKET HEAD BOLT
M6X20 		- 1 Enquire
14 12E010001G
STICKER HV KENNZEICHNUNG 		- 1 Enquire
15 N90450201
PROTECTIVE CAP
10X12 		- 1 Enquire
