Lamborghini Revuelto Coupe - AXLE (505.01.00)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	47B505431A	FRONT WHEEL CARRIER SX	Enquire	To Order
	47B505432A	HUB CARRIER	Enquire	To Order
	16HA257CP	PRESSURE SENSOR PIPE - LH	$223.40	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	47B505311	BRACCIO SOSPENS.	Enquire	To Order
	47B505312	TRACK CONTROL ARM RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0407203C	BALANCING PLATE	Enquire	To Order
	4S0407203D	BALANCING PLATE	Enquire	To Order
	4S0407203E	BALANCING PLATE	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	47B941287C	RETAINING PART	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B941453	BRACKET	Enquire	To Order
	47B941454	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B611841	BRACKET	Enquire	To Order
	47B611842	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B611845	BRACKET,BRAKE HOSE	Enquire	To Order
	47B611846	BRACKET,BRAKE HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470941273A	POSITION SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B599511	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B501397A	ACTUATOR	Enquire	To Order
	47B501398A	ACTUATOR	Enquire	To Order
	47B501397B	LB74X REAR WHEEL STEERING ACTUATOR LEFT	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	47B505323	BRACCIO SOSPENS.	Enquire	To Order
	47B505324	TRACK CONTROL ARM RH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT011216	SHAFT SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10728502	HEX COLLARED BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT004898	HEXAGON COLLAR NUT SELF-LOCKING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10714801	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91055501	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10434301	SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N01118312	HEXAGON NUT, SELF-LOCKING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91207701	TORX LENS FLANGE SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10628301	HEX COLLARED BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10640501	HEXAGON FLANGE M12X1.5X80	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10106403	HEXAGON COLLAR NUT SELF LOCKING M12 X 1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8E0407643A	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10741402	HEXAGON SOCKET FLAT HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B927803	SPEED SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91096701	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	47B505431A	FRONT WHEEL CARRIER SX	47B505431A FRONT WHEEL CARRIER SX UNTIL VIN LA02923-LEFT REAR	-	1	Enquire
1	47B505432A	HUB CARRIER	47B505432A HUB CARRIER UNTIL VIN LA02923-RIGHT REAR	-	1	Enquire
1	16HA257CP	PRESSURE SENSOR PIPE - LH	16HA257CP PRESSURE SENSOR PIPE - LH FROM VIN LA02924-LEFT REAR	$223.40	1
1	16HA258CP	PRESSURE SENSOR PIPE - RH	16HA258CP PRESSURE SENSOR PIPE - RH FROM VIN LA02924-RIGHT REAR	$223.40	1
6	47B505311	BRACCIO SOSPENS.	47B505311 BRACCIO SOSPENS. LEFT LOWER	-	1	Enquire
6	47B505312	TRACK CONTROL ARM RH	47B505312 TRACK CONTROL ARM RH RIGHT LOWER	-	1	Enquire
7	4S0407203C	BALANCING PLATE	4S0407203C BALANCING PLATE 1MM	-	1	Enquire
7	4S0407203D	BALANCING PLATE	4S0407203D BALANCING PLATE 2MM	-	1	Enquire
7	4S0407203E	BALANCING PLATE	4S0407203E BALANCING PLATE 3MM	-	1	Enquire
7	4S0407203G	BALANCING PLATE	4S0407203G BALANCING PLATE 0,5MM	-	1	Enquire
7	4S0407203H	BALANCING PLATE	4S0407203H BALANCING PLATE 1,5MM	-	1	Enquire
8	47B941287C	RETAINING PART	47B941287C RETAINING PART	-	1	Enquire
9	47B941453	BRACKET	47B941453 BRACKET LEFT	-	1	Enquire
9	47B941454	BRACKET	47B941454 BRACKET RIGHT	-	1	Enquire
10	47B611841	BRACKET	47B611841 BRACKET LEFT	-	1	Enquire
10	47B611842	BRACKET	47B611842 BRACKET RIGHT	-	1	Enquire
11	47B611845	BRACKET,BRAKE HOSE	47B611845 BRACKET,BRAKE HOSE LEFT	-	1	Enquire
11	47B611846	BRACKET,BRAKE HOSE	47B611846 BRACKET,BRAKE HOSE RIGHT	-	1	Enquire
12	470941273A	POSITION SENSOR	470941273A POSITION SENSOR	-	1	Enquire
13	47B599511	BRACKET	47B599511 BRACKET	-	1	Enquire
14	47B501397A	ACTUATOR	47B501397A ACTUATOR LEFT	-	1	Enquire
14	47B501398A	ACTUATOR	47B501398A ACTUATOR RIGHT	-	1	Enquire
14	47B501397B	LB74X REAR WHEEL STEERING ACTUATOR LEFT	47B501397B LB74X REAR WHEEL STEERING ACTUATOR LEFT LEFT	-	1	Enquire
14	47B501398B	LB74X REAR WHEEL STEERING ACTUATOR RIGHT	47B501398B LB74X REAR WHEEL STEERING ACTUATOR RIGHT RIGHT	-	1	Enquire
16	47B505323	BRACCIO SOSPENS.	47B505323 BRACCIO SOSPENS. LEFT UPPER	-	1	Enquire
16	47B505324	TRACK CONTROL ARM RH	47B505324 TRACK CONTROL ARM RH RIGHT UPPER	-	1	Enquire
17	WHT011216	SHAFT SCREW	WHT011216 SHAFT SCREW	-	1	Enquire
18	N10728502	HEX COLLARED BOLT	N10728502 HEX COLLARED BOLT M10X40	-	1	Enquire
19	WHT004898	HEXAGON COLLAR NUT SELF-LOCKING	WHT004898 HEXAGON COLLAR NUT SELF-LOCKING M14X1,5	-	1	Enquire
20	N10714801	OVAL HEXAGON SOCKET HEAD BOLT	N10714801 OVAL HEXAGON SOCKET HEAD BOLT M6X18	-	1	Enquire
21	N91055501	OVAL HEXAGON SOCKET HEAD BOLT	N91055501 OVAL HEXAGON SOCKET HEAD BOLT M5X12	-	1	Enquire
22	N10434301	SOCKET HEAD BOLT	N10434301 SOCKET HEAD BOLT M5X10 N 104 343 FQA-TEIL	-	1	Enquire
23	N01118312	HEXAGON NUT, SELF-LOCKING	N01118312 HEXAGON NUT, SELF-LOCKING M6	-	1	Enquire
24	N91207701	TORX LENS FLANGE SCREW	N91207701 TORX LENS FLANGE SCREW M5X25	-	1	Enquire
25	N10628301	HEX COLLARED BOLT	N10628301 HEX COLLARED BOLT M12X1,5X90	-	1	Enquire
26	N10640501	HEXAGON FLANGE M12X1.5X80	N10640501 HEXAGON FLANGE M12X1.5X80	-	1	Enquire
27	N10106403	HEXAGON COLLAR NUT SELF LOCKING M12 X 1.5	N10106403 HEXAGON COLLAR NUT SELF LOCKING M12 X 1.5 M12X1,5	-	1	Enquire
28	8E0407643A	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	8E0407643A SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD UNTIL VIN LA00858 CHANGE THE SCREW ON ALL 4 HALF- SHAFTS-M16X1,5X72	-	1	Enquire
29	N10741402	HEXAGON SOCKET FLAT HEAD BOLT	N10741402 HEXAGON SOCKET FLAT HEAD BOLT M6X14	-	1	Enquire
32	RY6313W030BF	H/LAMP LHS LHD	RY6313W030BF H/LAMP LHS LHD LEFT	-	1	Enquire
32	RY6323942EEW	DR RH PASS COUPE SAT	RY6323942EEW DR RH PASS COUPE SAT RIGHT	-	1	Enquire
33	RY63280B63EA	SIDE STRAKE LH	RY63280B63EA SIDE STRAKE LH LEFT	-	1	Enquire
33	RY63L116A95EBW	STWG BOX ASSY	RY63L116A95EBW STWG BOX ASSY RIGHT	-	1	Enquire
34	47B927803	SPEED SENSOR	47B927803 SPEED SENSOR	-	1	Enquire
35	N91096701	OVAL HEXAGON SOCKET HEAD BOLT	N91096701 OVAL HEXAGON SOCKET HEAD BOLT M6X16	-	1	Enquire
