Lamborghini Murcielago LP640 Roadster - Electrohydraulic Abs Cu

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Electrohydraulic Abs Cu of Lamborghini Lamborghini Murcielago LP640 Roadster Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
002 410614517
ABS CONTROL UNIT 		$6,256.72 1
003 410614128
FLEXIBLE SUPPORT 		$55.91 1
004 410614125
FLEXIBLE SUPPORT 		$13.97 2
005 N01100637
NUT M6 		$0.33 (95.5% off) 3
006 WHT003213
WASHER 		$1.34 (81.3% off) 3
007 N10517304
SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK. 		$1.55 (78.4% off) 2
008 N90179103
WASHER 18X8,4X2,5 		$1.55 3
009 N0152785
WASHER 		$0.40 2
010 410614187
JOURNAL 		$13.97 2
011 400972081C
FLEXIBLE SUPPORT 		$18.41 3
012 N01118312
HEXAGON NUT, SELF-LOCKING 		$2.04 3
013 413614138A
SUPPORT 		$250.66 1
014 N10536103
SCREW M8X16 		$0.98 (86.5% off) 1
015 410614143A
BRACKET 		$114.65 1
017 191611715
HOSE BRACKET 		$2.08 (70.9% off) 1
018 413611761C
LEFT FRONT FLEXIBLE HOSE 		$175.39 1
019 413614739B
HOSE 		$256.05 1
020 413611762B
RIGHT FRONT FLEXIBLE HOSE 		$120.57 1
021 413611763C
LEFT REAR FLEXIBLE HOSE 		$182.81 1
022 413614740B
HOSE 		$218.42 1
023 413611764C
RIGHT REAR FLEXIBLE HOSE 		$124.46 1
