Electrical System 2

Lamborghini Murcielago LP640

Find Your Part

Lamborghini Murcielago LP640 - Electrical System 2

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Electrical System 2 of Lamborghini Lamborghini Murcielago LP640 Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 7L133741
SUPPORT 		- 1 Enquire
002 WHT002961
WASHER 		- 1 Enquire
003 N90319404
SCREW 		- 1 Enquire
004 410959433DR
GFA CONTROL UNIT (SUPPLY VIN - TO BE PROGRAMMED) 		- 1 Enquire
005 N01118312
HEXAGON NUT, SELF-LOCKING 		- 2 Enquire
006 WHT001197A
WASHER 		- 3 Enquire
007 400972081B
FLEXIBLE SUPPORT 		- 2 Enquire
008 410937101D
ANTI-THEFT CONTROL UNIT AND REMOTE CONTROL (433MHZ) 		- 1 Enquire
009 410959655
AIRBAG CONTROL UNIT + SENSOR 		- 1 Enquire
010 418959875
POWER WINDOW CONTROL UNIT 		- 1 Enquire
011 N01508213
HEXAGON COLLAR NUT 		- 2 Enquire
012 410971946
CONNECTOR 		- 1 Enquire
013 413857260
BRACKET 		- 1 Enquire
014 413971457
SUPPORT 		- 1 Enquire
015 410951287A
BRACKET 		- 1 Enquire
016 N01508213
HEXAGON COLLAR NUT 		- 2 Enquire
017 N0206253
CLAMP 		- 2 Enquire
018 N01100637
NUT M6 		- 3 Enquire
019 WHT001197A
WASHER 		- 3 Enquire
020 N01508213
HEXAGON COLLAR NUT 		- 2 Enquire
021 410953359
SUPPORT 		- 1 Enquire
022 WHT003112
NUT M5 		- 2 Enquire
023 410953227A
RELAY (SIDE TURN INDICATOR LIGHT) 		- 1 Enquire
024 WHT003112
NUT M5 		- 2 Enquire
