IGNITION SYSTEM of Lamborghini Lamborghini Huracan Evo Coupe

View All

Lamborghini Huracan Evo Coupe - IGNITION SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4S8971713A	HARNESS FOR ENGINE COMPARTMENT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10464802	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT001999	CABLE TIE WITH TERMINAL SOCKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	5M0971838	CABLE TIE WITH TERMINAL SOCKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91123701	CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90833202	HEXAGON BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10646101	CABLE TIES	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	79905115B	IGNITION COIL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7L905142	PROTECTIVE CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7L905116B	PROTECTIVE CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6H905601C	SPARK PLUG 'LONGLIFE'	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	7L905377F	KNOCK SENSOR WITH WIRING HARNESS	Enquire	To Order
	6E905377J	KNOCK SENSOR WITH WIRING HARNESS	Enquire	To Order
	6E905377K	KNOCK SENSOR WITH WIRING HARNESS	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	N01024425	HEXAGON BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0937539B	BRACKET	Enquire	To Order
	4S0937540B	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0937113A	HOUSING FOR CONTROL UNITS	Enquire	To Order
	4S0937114A	HOUSING FOR CONTROL UNITS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0937507	RELAY PLATE	Enquire	To Order
	4S0937503	RELAY PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0937555A	COVER	Enquire	To Order
	4S0937554A	COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90739704	PANEL SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10653201	HEX COLLARED BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10196103	OVAL SOCKET HEAD BOLT WITH HEX DRIVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4C907601K	IMPULSE SENDER	Enquire	To Order
	4C907601K	IMPULSE SENDER	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4S8971713A	HARNESS FOR ENGINE COMPARTMENT	4S8971713A HARNESS FOR ENGINE COMPARTMENT	-	1	Enquire
2	N10464802	OVAL HEXAGON SOCKET HEAD BOLT	N10464802 OVAL HEXAGON SOCKET HEAD BOLT 4X12	-	3	Enquire
3	WHT001999	CABLE TIE WITH TERMINAL SOCKET	WHT001999 CABLE TIE WITH TERMINAL SOCKET 4,6X200 3,0-6,0MM OUTER	-	12	Enquire
4	5M0971838	CABLE TIE WITH TERMINAL SOCKET	5M0971838 CABLE TIE WITH TERMINAL SOCKET 4,6X200MM	-	12	Enquire
5	N91123701	CLAMP	N91123701 CLAMP 1-40X15	-	2	Enquire
6	N90833202	HEXAGON BOLT	N90833202 HEXAGON BOLT M6X22	-	2	Enquire
7	N10646101	CABLE TIES	N10646101 CABLE TIES	-	2	Enquire
8	79905115B	IGNITION COIL	79905115B IGNITION COIL	-	10	Enquire
9	7L905142	PROTECTIVE CAP	7L905142 PROTECTIVE CAP UPPER	-	10	Enquire
10	7L905116B	PROTECTIVE CAP	7L905116B PROTECTIVE CAP LOWER	-	10	Enquire
11	6H905601C	SPARK PLUG 'LONGLIFE' ARRIVING SOON	6H905601C SPARK PLUG 'LONGLIFE' ARRIVING SOON	-	10	Enquire
12	7L905377F	KNOCK SENSOR WITH WIRING HARNESS	7L905377F KNOCK SENSOR WITH WIRING HARNESS BROWN - CYLINDER 6-8-590MM BROWN	-	1	Enquire
12	6E905377J	KNOCK SENSOR WITH WIRING HARNESS	6E905377J KNOCK SENSOR WITH WIRING HARNESS GREEN - CYLINDER 4,5-GREEN 465MM 3 PIN	-	1	Enquire
12	6E905377K	KNOCK SENSOR WITH WIRING HARNESS	6E905377K KNOCK SENSOR WITH WIRING HARNESS GREY - CYLINDER 9, 10_-GREY 480MM	-	1	Enquire
12	7L905377E	KNOCK SENSOR WITH WIRING HARNESS	7L905377E KNOCK SENSOR WITH WIRING HARNESS ORANGE - CYLINDER 1- 3 _-565MM ORANGE	-	1	Enquire
13	N01024425	HEXAGON BOLT	N01024425 HEXAGON BOLT M8X30-M8X30	-	1	Enquire
14	4S0937539B	BRACKET	4S0937539B BRACKET LEFT	-	1	Enquire
14	4S0937540B	BRACKET	4S0937540B BRACKET RIGHT	-	1	Enquire
15	4S0937113A	HOUSING FOR CONTROL UNITS	4S0937113A HOUSING FOR CONTROL UNITS LEFT	-	1	Enquire
15	4S0937114A	HOUSING FOR CONTROL UNITS	4S0937114A HOUSING FOR CONTROL UNITS RIGHT	-	1	Enquire
16	4S0937507	RELAY PLATE	4S0937507 RELAY PLATE LEFT	-	1	Enquire
16	4S0937503	RELAY PLATE	4S0937503 RELAY PLATE RIGHT	-	1	Enquire
17	4S0937555A	COVER	4S0937555A COVER LEFT	-	1	Enquire
17	4S0937554A	COVER	4S0937554A COVER RIGHT	-	1	Enquire
18	N90739704	PANEL SCREW	N90739704 PANEL SCREW TP5X22-5X22	-	2	Enquire
19	N10653201	HEX COLLARED BOLT	N10653201 HEX COLLARED BOLT M6X16-M6X16	-	2	Enquire
20	N10196103	OVAL SOCKET HEAD BOLT WITH HEX DRIVE	N10196103 OVAL SOCKET HEAD BOLT WITH HEX DRIVE M6X16-M6X18	-	4	Enquire
21	4C907601K	IMPULSE SENDER	4C907601K IMPULSE SENDER M6X16	-	4	Enquire
21	4C907601K	IMPULSE SENDER	4C907601K IMPULSE SENDER	-	4	Enquire
